loadmf6filemodule Module Reference

This module contains the LoadMf6FileModule. More...

Data Types
type	staticsatype
	Fortran workaround for allocatable arrays of pointers; wraps a StructArray pointer for deferred TS linking. More...
type	loadmf6filetype
	Static parser based input loader. More...

Functions/Subroutines
subroutine	load (this, parser, mf6_input, nc_vars, filename, iout)
	load all static input blocks More...
subroutine	init (this, parser, mf6_input, filename, iout)
	init More...
subroutine	load_block (this, iblk)
	load a single block More...
subroutine	finalize (this)
	finalize More...
subroutine	block_post_process (this, iblk)
	Post parse block handling. More...
recursive subroutine	parse_block (this, iblk, recursive_call)
	parse block More...
subroutine	parse_io_tag (this, iblk, pkgtype, which, tag)
recursive subroutine	parse_record_tag (this, iblk, inidt, recursive_call)
subroutine	load_tag (this, iblk, idt)
	load input keyword Load input associated with tag key into the memory manager. More...
type(inputparamdefinitiontype) function	block_index_dfn (this, iblk)
subroutine	parse_structarray_block (this, iblk)
	parse a structured array record into memory manager More...
integer(i4b) function	ts_sa_count (this)
	Return number of saved static StructArrays with deferred TS strlocs. More...
type(structarraytype) function, pointer	get_ts_sa (this, n)
	Return the n-th saved static StructArray pointer. More...
subroutine	load_keyword_type (parser, idt, memoryPath, iout)
	load type keyword More...
subroutine	load_string_type (parser, idt, memoryPath, iout)
	load type string More...
subroutine	load_io_tag (parser, idt, memoryPath, which, iout)
	load io tag More...
subroutine	load_auxvar_names (parser, idt, memoryPath, iout)
	load aux variable names More...
subroutine	load_integer_type (parser, idt, memoryPath, iout)
	load type integer More...
subroutine	load_integer1d_type (parser, idt, mf6_input, mshape, export, nc_vars, input_fname, iout)
	load type 1d integer More...
subroutine	load_integer2d_type (parser, idt, mf6_input, mshape, export, nc_vars, input_fname, iout)
	load type 2d integer More...
subroutine	load_integer3d_type (parser, idt, mf6_input, mshape, export, nc_vars, input_fname, iout)
	load type 3d integer More...
subroutine	load_double_type (parser, idt, memoryPath, iout)
	load type double More...
subroutine	load_double1d_type (parser, idt, mf6_input, mshape, export, nc_vars, input_fname, iout)
	load type 1d double More...
subroutine	load_double2d_type (parser, idt, mf6_input, mshape, export, nc_vars, input_fname, iout)
	load type 2d double More...
subroutine	load_double3d_type (parser, idt, mf6_input, mshape, export, nc_vars, input_fname, iout)
	load type 3d double More...
integer(i4b) function, public	read_control_record (parser, oc_inunit, iout)
subroutine	save_ts_sa (this)
	Save structarray pointer for deferred TS linking. More...
subroutine	cleanup (this)
	Clean up saved static structarrays. More...

Detailed Description

This module contains the input data model routines for loading static data from a MODFLOW 6 input file using the block parser.

Function/Subroutine Documentation

block_index_dfn()

type(inputparamdefinitiontype) function loadmf6filemodule::block_index_dfn	(	class(loadmf6filetype)	this,
		integer(i4b), intent(in)	iblk
	)

Returns

input data type object describing this record

Definition at line 531 of file LoadMf6File.f90.

    class(LoadMf6FileType) :: this
    integer(I4B), intent(in) :: iblk
    type(InputParamDefinitionType) :: idt !< input data type object describing this record
    character(len=LENVARNAME) :: varname
    integer(I4B) :: ilen
    character(len=3) :: block_suffix = 'NUM'

    ! assign first column as the block number
    ilen = len_trim(this%mf6_input%block_dfns(iblk)%blockname)

    if (ilen > (lenvarname - len(block_suffix))) then
      varname = &
        this%mf6_input%block_dfns(iblk)% &
        blockname(1:(lenvarname - len(block_suffix)))//block_suffix
    else
      varname = trim(this%mf6_input%block_dfns(iblk)%blockname)//block_suffix
    end if

    idt%component_type = trim(this%mf6_input%component_type)
    idt%subcomponent_type = trim(this%mf6_input%subcomponent_type)
    idt%blockname = trim(this%mf6_input%block_dfns(iblk)%blockname)
    idt%tagname = varname
    idt%mf6varname = varname
    idt%datatype = 'INTEGER'

block_post_process()

subroutine loadmf6filemodule::block_post_process	(	class(loadmf6filetype)	this,
		integer(i4b), intent(in)	iblk
	)

Definition at line 211 of file LoadMf6File.f90.

    use sourcecommonmodule, only: set_model_shape
    class(LoadMf6FileType) :: this
    integer(I4B), intent(in) :: iblk
    type(InputParamDefinitionType), pointer :: idt
    integer(I4B) :: iparam
    integer(I4B), pointer :: intptr

    ! update state based on read tags
    do iparam = 1, size(this%block_tags)
      select case (this%mf6_input%block_dfns(iblk)%blockname)
      case ('OPTIONS')
        if (this%block_tags(iparam) == 'AUXILIARY') then
          this%iauxiliary = 1
        else if (this%block_tags(iparam) == 'BOUNDNAMES') then
          this%inamedbound = 1
        else if (this%block_tags(iparam) == 'READASARRAYS') then
          this%readasarrays = .true.
        else if (this%block_tags(iparam) == 'READARRAYGRID') then
          this%readarraygrid = .true.
        else if (this%block_tags(iparam) == 'TS6_FILENAME') then
          this%ts_active = .true.
        else if (this%block_tags(iparam) == 'EXPORT_ARRAY_ASCII') then
          this%export = .true.
        end if
      case default
      end select
    end do

    ! update input context allocations based on dfn set and input
    select case (this%mf6_input%block_dfns(iblk)%blockname)
    case ('OPTIONS')
      ! allocate naux and set to 0 if not allocated
      do iparam = 1, size(this%mf6_input%param_dfns)
        idt => this%mf6_input%param_dfns(iparam)
        if (idt%blockname == 'OPTIONS' .and. &
            idt%tagname == 'AUXILIARY') then
          if (this%iauxiliary == 0) then
            call mem_allocate(intptr, 'NAUX', this%mf6_input%mempath)
            intptr = 0
          end if
          exit
        end if
      end do
    case ('DIMENSIONS')
      ! set model shape if discretization dimensions have been read
      if (this%mf6_input%pkgtype(1:3) == 'DIS') then
        call set_model_shape(this%mf6_input%pkgtype, this%filename, &
                             this%mf6_input%component_mempath, &
                             this%mf6_input%mempath, this%mshape)
      end if
    case default
    end select

Here is the call graph for this function:

cleanup()

subroutine loadmf6filemodule::cleanup ( class(loadmf6filetype), intent(inout)  this )

private

Called from destroy() of dynamic loaders.

Definition at line 1273 of file LoadMf6File.f90.

    use structarraymodule, only: destructstructarray
    class(LoadMf6FileType), intent(inout) :: this
    integer(I4B) :: n
    do n = 1, size(this%ts_sas)
      if (associated(this%ts_sas(n)%sa)) then
        call destructstructarray(this%ts_sas(n)%sa)
        nullify (this%ts_sas(n)%sa)
      end if
    end do
    deallocate (this%ts_sas)

Here is the call graph for this function:

finalize()

subroutine loadmf6filemodule::finalize

(

class(loadmf6filetype)

this

)

init / finalize are only used when load_block() will be called

Definition at line 195 of file LoadMf6File.f90.

    use structarraymodule, only: destructstructarray
    class(LoadMf6FileType) :: this
    ! cleanup
    if (associated(this%structarray)) then
      ! destroy the structured array reader
      call destructstructarray(this%structarray)
    end if
    ! close logging block
    call idm_log_close(this%mf6_input%component_name, &
                       this%mf6_input%subcomponent_name, this%iout)

Here is the call graph for this function:

get_ts_sa()

type(structarraytype) function, pointer loadmf6filemodule::get_ts_sa ( class(loadmf6filetype), intent(in)  this, integer(i4b), intent(in)  n  )

private

Definition at line 677 of file LoadMf6File.f90.

    class(LoadMf6FileType), intent(in) :: this
    integer(I4B), intent(in) :: n
    type(StructArrayType), pointer :: sa
    sa => this%ts_sas(n)%sa

init()

subroutine loadmf6filemodule::init	(	class(loadmf6filetype)	this,
		type(blockparsertype), intent(inout), target	parser,
		type(modflowinputtype), intent(in)	mf6_input,
		character(len=*), intent(in)	filename,
		integer(i4b), intent(in)	iout
	)

init / finalize are only used when load_block() will be called

Definition at line 129 of file LoadMf6File.f90.

    use memorymanagermodule, only: get_isize
    class(LoadMf6FileType) :: this
    type(BlockParserType), target, intent(inout) :: parser
    type(ModflowInputType), intent(in) :: mf6_input
    character(len=*), intent(in) :: filename
    integer(I4B), intent(in) :: iout
    integer(I4B) :: isize

    this%parser => parser
    this%mf6_input = mf6_input
    this%filename = filename
    this%ts_active = .false.
    this%export = .false.
    this%readasarrays = .false.
    this%readarraygrid = .false.
    this%inamedbound = 0
    this%iauxiliary = 0
    this%iout = iout

    call get_isize('MODEL_SHAPE', mf6_input%component_mempath, isize)
    if (isize > 0) then
      call mem_setptr(this%mshape, 'MODEL_SHAPE', mf6_input%component_mempath)
    end if

    ! init ts stuctarray list
    allocate (this%ts_sas(0))

    ! log lst file header
    call idm_log_header(this%mf6_input%component_name, &
                        this%mf6_input%subcomponent_name, this%iout)

Here is the call graph for this function:

load()

subroutine loadmf6filemodule::load ( class(loadmf6filetype)  this, type(blockparsertype), intent(inout), target  parser, type(modflowinputtype), intent(in)  mf6_input, type(ncpackagevarstype), intent(in), pointer  nc_vars, character(len=*), intent(in)  filename, integer(i4b), intent(in)  iout  )

private

Invoke this routine to load all static input blocks in single call.

Definition at line 96 of file LoadMf6File.f90.

    use memorymanagermodule, only: get_isize
    class(LoadMf6FileType) :: this
    type(BlockParserType), target, intent(inout) :: parser
    type(ModflowInputType), intent(in) :: mf6_input
    type(NCPackageVarsType), pointer, intent(in) :: nc_vars
    character(len=*), intent(in) :: filename
    integer(I4B), intent(in) :: iout
    integer(I4B) :: iblk

    ! initialize static load
    call this%init(parser, mf6_input, filename, iout)

    ! set netcdf vars
    this%nc_vars => nc_vars

    ! process blocks
    do iblk = 1, size(this%mf6_input%block_dfns)
      ! don't load dynamic input data
      if (this%mf6_input%block_dfns(iblk)%blockname == 'PERIOD') exit
      ! load the block
      call this%load_block(iblk)
    end do

    ! finalize static load
    call this%finalize()

Here is the call graph for this function:

load_auxvar_names()

subroutine loadmf6filemodule::load_auxvar_names	(	type(blockparsertype), intent(inout)	parser,
		type(inputparamdefinitiontype), intent(in)	idt,
		character(len=*), intent(in)	memoryPath,
		integer(i4b), intent(in)	iout
	)

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	memorypath	memorypath to put loaded information
[in]	iout	unit number for output

Definition at line 758 of file LoadMf6File.f90.

    use constantsmodule, only: lenauxname, linelength, lenpackagename
    use inputoutputmodule, only: urdaux
    use characterstringmodule, only: characterstringtype
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    character(len=*), intent(in) :: memoryPath !< memorypath to put loaded information
    integer(I4B), intent(in) :: iout !< unit number for output
    character(len=:), allocatable :: line
    character(len=LENAUXNAME), dimension(:), allocatable :: caux
    integer(I4B) :: lloc
    integer(I4B) :: istart
    integer(I4B) :: istop
    integer(I4B) :: i
    character(len=LENPACKAGENAME) :: text = ''
    integer(I4B), pointer :: intvar
    type(CharacterStringType), dimension(:), &
      pointer, contiguous :: acharstr1d !< variable for allocation
    call mem_allocate(intvar, idt%shape, memorypath)
    intvar = 0
    call parser%GetRemainingLine(line)
    lloc = 1
    call urdaux(intvar, parser%iuactive, iout, lloc, &
                istart, istop, caux, line, text)
    call mem_allocate(acharstr1d, lenauxname, intvar, idt%mf6varname, memorypath)
    do i = 1, intvar
      acharstr1d(i) = caux(i)
    end do
    deallocate (line)
    deallocate (caux)

Here is the call graph for this function:

Here is the caller graph for this function:

load_block()

subroutine loadmf6filemodule::load_block	(	class(loadmf6filetype)	this,
		integer(i4b), intent(in)	iblk
	)

Assumed in order load of single (next) block. If a StructArray object is allocated to load this block it persists until this routine (or finalize) is called again.

Definition at line 170 of file LoadMf6File.f90.

    use structarraymodule, only: destructstructarray
    class(LoadMf6FileType) :: this
    integer(I4B), intent(in) :: iblk

    ! reset structarray if it was created for previous block
    if (associated(this%structarray)) then
      ! destroy the structured array reader
      call destructstructarray(this%structarray)
    end if

    allocate (this%block_tags(0))
    ! load the block
    call this%parse_block(iblk, .false.)
    ! post process block
    call this%block_post_process(iblk)
    ! cleanup
    deallocate (this%block_tags)

Here is the call graph for this function:

load_double1d_type()

subroutine loadmf6filemodule::load_double1d_type ( type(blockparsertype), intent(inout)  parser, type(inputparamdefinitiontype), intent(in)  idt, type(modflowinputtype), intent(in)  mf6_input, integer(i4b), dimension(:), intent(in), pointer, contiguous  mshape, logical(lgp), intent(in)  export, type(ncpackagevarstype), intent(in), pointer  nc_vars, character(len=*), intent(in)  input_fname, integer(i4b), intent(in)  iout  )

private

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	mf6_input	description of input
[in]	mshape	model shape
[in]	export	export to ascii layer files
[in]	input_fname	ascii input file name
[in]	iout	unit number for output

Definition at line 994 of file LoadMf6File.f90.

    use sourcecommonmodule, only: get_shape_from_string, get_layered_shape
    use loadncinputmodule, only: netcdf_read_array
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    type(ModflowInputType), intent(in) :: mf6_input !< description of input
    integer(I4B), dimension(:), contiguous, pointer, intent(in) :: mshape !< model shape
    logical(LGP), intent(in) :: export !< export to ascii layer files
    type(NCPackageVarsType), pointer, intent(in) :: nc_vars
    character(len=*), intent(in) :: input_fname !< ascii input file name
    integer(I4B), intent(in) :: iout !< unit number for output
    real(DP), dimension(:), pointer, contiguous :: dbl1d
    integer(I4B) :: nlay
    integer(I4B) :: nvals
    integer(I4B), dimension(:), allocatable :: array_shape
    integer(I4B), dimension(:), allocatable :: layer_shape
    character(len=LINELENGTH) :: keyword

    ! Check if it is a full grid sized array (NODES)
    if (idt%shape == 'NODES') then
      nvals = product(mshape)
    else
      call get_shape_from_string(idt%shape, array_shape, mf6_input%mempath)
      nvals = array_shape(1)
    end if

    ! allocate memory for the array
    call mem_allocate(dbl1d, nvals, idt%mf6varname, mf6_input%mempath)

    ! read keyword
    keyword = ''
    call parser%GetStringCaps(keyword)

    ! check for "NETCDF" and "LAYERED"
    if (keyword == 'NETCDF') then
      call netcdf_read_array(dbl1d, mshape, idt, mf6_input, nc_vars, &
                             input_fname, iout)
    else if (keyword == 'LAYERED' .and. idt%layered) then
      call get_layered_shape(mshape, nlay, layer_shape)
      call read_dbl1d_layered(parser, dbl1d, idt%mf6varname, nlay, layer_shape)
    else
      call read_dbl1d(parser, dbl1d, idt%mf6varname)
    end if

    ! log information on the loaded array to the list file
    call idm_log_var(dbl1d, idt%tagname, mf6_input%mempath, iout)

    ! create export file for griddata parameters if optioned
    if (export) then
      if (idt%blockname == 'GRIDDATA') then
        call idm_export(dbl1d, idt%tagname, mf6_input%mempath, idt%shape, iout)
      end if
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

load_double2d_type()

subroutine loadmf6filemodule::load_double2d_type	(	type(blockparsertype), intent(inout)	parser,
		type(inputparamdefinitiontype), intent(in)	idt,
		type(modflowinputtype), intent(in)	mf6_input,
		integer(i4b), dimension(:), intent(in), pointer, contiguous	mshape,
		logical(lgp), intent(in)	export,
		type(ncpackagevarstype), intent(in), pointer	nc_vars,
		character(len=*), intent(in)	input_fname,
		integer(i4b), intent(in)	iout
	)

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	mf6_input	description of input
[in]	mshape	model shape
[in]	export	export to ascii layer files
[in]	input_fname	ascii input file name
[in]	iout	unit number for output

Definition at line 1052 of file LoadMf6File.f90.

    use sourcecommonmodule, only: get_shape_from_string, get_layered_shape
    use loadncinputmodule, only: netcdf_read_array
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    type(ModflowInputType), intent(in) :: mf6_input !< description of input
    integer(I4B), dimension(:), contiguous, pointer, intent(in) :: mshape !< model shape
    logical(LGP), intent(in) :: export !< export to ascii layer files
    type(NCPackageVarsType), pointer, intent(in) :: nc_vars
    character(len=*), intent(in) :: input_fname !< ascii input file name
    integer(I4B), intent(in) :: iout !< unit number for output
    real(DP), dimension(:, :), pointer, contiguous :: dbl2d
    integer(I4B) :: nlay
    integer(I4B) :: nsize1, nsize2
    integer(I4B), dimension(:), allocatable :: array_shape
    integer(I4B), dimension(:), allocatable :: layer_shape
    character(len=LINELENGTH) :: keyword

    ! determine the array shape from the input data definition (idt%shape),
    ! which looks like "NCOL, NROW, NLAY"
    call get_shape_from_string(idt%shape, array_shape, mf6_input%mempath)
    nsize1 = array_shape(1)
    nsize2 = array_shape(2)

    ! create a new 3d memory managed variable
    call mem_allocate(dbl2d, nsize1, nsize2, idt%mf6varname, mf6_input%mempath)

    ! read keyword
    keyword = ''
    call parser%GetStringCaps(keyword)

    ! check for "NETCDF" and "LAYERED"
    if (keyword == 'NETCDF') then
      call netcdf_read_array(dbl2d, mshape, idt, mf6_input, nc_vars, &
                             input_fname, iout)
    else if (keyword == 'LAYERED' .and. idt%layered) then
      call get_layered_shape(mshape, nlay, layer_shape)
      call read_dbl2d_layered(parser, dbl2d, idt%mf6varname, nlay, layer_shape)
    else
      call read_dbl2d(parser, dbl2d, idt%mf6varname)
    end if

    ! log information on the loaded array to the list file
    call idm_log_var(dbl2d, idt%tagname, mf6_input%mempath, iout)

    ! create export file for griddata parameters if optioned
    if (export) then
      if (idt%blockname == 'GRIDDATA') then
        call idm_export(dbl2d, idt%tagname, mf6_input%mempath, idt%shape, iout)
      end if
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

load_double3d_type()

subroutine loadmf6filemodule::load_double3d_type	(	type(blockparsertype), intent(inout)	parser,
		type(inputparamdefinitiontype), intent(in)	idt,
		type(modflowinputtype), intent(in)	mf6_input,
		integer(i4b), dimension(:), intent(in), pointer, contiguous	mshape,
		logical(lgp), intent(in)	export,
		type(ncpackagevarstype), intent(in), pointer	nc_vars,
		character(len=*), intent(in)	input_fname,
		integer(i4b), intent(in)	iout
	)

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	mf6_input	description of input
[in]	mshape	model shape
[in]	export	export to ascii layer files
[in]	input_fname	ascii input file name
[in]	iout	unit number for output

Definition at line 1108 of file LoadMf6File.f90.

    use sourcecommonmodule, only: get_shape_from_string, get_layered_shape
    use loadncinputmodule, only: netcdf_read_array
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    type(ModflowInputType), intent(in) :: mf6_input !< description of input
    integer(I4B), dimension(:), contiguous, pointer, intent(in) :: mshape !< model shape
    logical(LGP), intent(in) :: export !< export to ascii layer files
    type(NCPackageVarsType), pointer, intent(in) :: nc_vars
    character(len=*), intent(in) :: input_fname !< ascii input file name
    integer(I4B), intent(in) :: iout !< unit number for output
    real(DP), dimension(:, :, :), pointer, contiguous :: dbl3d
    integer(I4B) :: nlay
    integer(I4B) :: nsize1, nsize2, nsize3
    integer(I4B), dimension(:), allocatable :: array_shape
    integer(I4B), dimension(:), allocatable :: layer_shape
    real(DP), dimension(:), pointer, contiguous :: dbl1d_ptr
    character(len=LINELENGTH) :: keyword

    ! determine the array shape from the input data definition (idt%shape),
    ! which looks like "NCOL, NROW, NLAY"
    call get_shape_from_string(idt%shape, array_shape, mf6_input%mempath)
    nsize1 = array_shape(1)
    nsize2 = array_shape(2)
    nsize3 = array_shape(3)

    ! create a new 3d memory managed variable
    call mem_allocate(dbl3d, nsize1, nsize2, nsize3, idt%mf6varname, &
                      mf6_input%mempath)

    ! read keyword
    keyword = ''
    call parser%GetStringCaps(keyword)

    ! check for "NETCDF" and "LAYERED"
    if (keyword == 'NETCDF') then
      call netcdf_read_array(dbl3d, mshape, idt, mf6_input, nc_vars, &
                             input_fname, iout)
    else if (keyword == 'LAYERED' .and. idt%layered) then
      call get_layered_shape(mshape, nlay, layer_shape)
      call read_dbl3d_layered(parser, dbl3d, idt%mf6varname, nlay, &
                              layer_shape)
    else
      dbl1d_ptr(1:nsize1 * nsize2 * nsize3) => dbl3d(:, :, :)
      call read_dbl1d(parser, dbl1d_ptr, idt%mf6varname)
    end if

    ! log information on the loaded array to the list file
    call idm_log_var(dbl3d, idt%tagname, mf6_input%mempath, iout)

    ! create export file for griddata parameters if optioned
    if (export) then
      if (idt%blockname == 'GRIDDATA') then
        call idm_export(dbl3d, idt%tagname, mf6_input%mempath, idt%shape, iout)
      end if
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

load_double_type()

subroutine loadmf6filemodule::load_double_type	(	type(blockparsertype), intent(inout)	parser,
		type(inputparamdefinitiontype), intent(in)	idt,
		character(len=*), intent(in)	memoryPath,
		integer(i4b), intent(in)	iout
	)

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	memorypath	memorypath to put loaded information
[in]	iout	unit number for output

Definition at line 981 of file LoadMf6File.f90.

    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    character(len=*), intent(in) :: memoryPath !< memorypath to put loaded information
    integer(I4B), intent(in) :: iout !< unit number for output
    real(DP), pointer :: dblvar
    call mem_allocate(dblvar, idt%mf6varname, memorypath)
    dblvar = parser%GetDouble()
    call idm_log_var(dblvar, idt%tagname, memorypath, iout)

Here is the caller graph for this function:

load_integer1d_type()

subroutine loadmf6filemodule::load_integer1d_type ( type(blockparsertype), intent(inout)  parser, type(inputparamdefinitiontype), intent(in)  idt, type(modflowinputtype), intent(in)  mf6_input, integer(i4b), dimension(:), intent(in), pointer, contiguous  mshape, logical(lgp), intent(in)  export, type(ncpackagevarstype), intent(in), pointer  nc_vars, character(len=*), intent(in)  input_fname, integer(i4b), intent(in)  iout  )

private

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	mf6_input	description of input
[in]	mshape	model shape
[in]	export	export to ascii layer files
[in]	input_fname	ascii input file name
[in]	iout	unit number for output

Definition at line 805 of file LoadMf6File.f90.

    use sourcecommonmodule, only: get_shape_from_string, get_layered_shape
    use loadncinputmodule, only: netcdf_read_array
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    type(ModflowInputType), intent(in) :: mf6_input !< description of input
    integer(I4B), dimension(:), contiguous, pointer, intent(in) :: mshape !< model shape
    logical(LGP), intent(in) :: export !< export to ascii layer files
    type(NCPackageVarsType), pointer, intent(in) :: nc_vars
    character(len=*), intent(in) :: input_fname !< ascii input file name
    integer(I4B), intent(in) :: iout !< unit number for output
    integer(I4B), dimension(:), pointer, contiguous :: int1d
    integer(I4B) :: nlay
    integer(I4B) :: nvals
    integer(I4B), dimension(:), allocatable :: array_shape
    integer(I4B), dimension(:), allocatable :: layer_shape
    character(len=LINELENGTH) :: keyword

    ! Check if it is a full grid sized array (NODES), otherwise use
    ! idt%shape to construct shape from variables in memoryPath
    if (idt%shape == 'NODES') then
      nvals = product(mshape)
    else
      call get_shape_from_string(idt%shape, array_shape, mf6_input%mempath)
      nvals = array_shape(1)
    end if

    ! allocate memory for the array
    call mem_allocate(int1d, nvals, idt%mf6varname, mf6_input%mempath)

    ! read keyword
    keyword = ''
    call parser%GetStringCaps(keyword)

    ! check for "NETCDF" and "LAYERED"
    if (keyword == 'NETCDF') then
      call netcdf_read_array(int1d, mshape, idt, mf6_input, nc_vars, &
                             input_fname, iout)
    else if (keyword == 'LAYERED' .and. idt%layered) then
      call get_layered_shape(mshape, nlay, layer_shape)
      call read_int1d_layered(parser, int1d, idt%mf6varname, nlay, layer_shape)
    else
      call read_int1d(parser, int1d, idt%mf6varname)
    end if

    ! log information on the loaded array to the list file
    call idm_log_var(int1d, idt%tagname, mf6_input%mempath, iout)

    ! create export file for griddata parameters if optioned
    if (export) then
      if (idt%blockname == 'GRIDDATA') then
        call idm_export(int1d, idt%tagname, mf6_input%mempath, idt%shape, iout)
      end if
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

load_integer2d_type()

subroutine loadmf6filemodule::load_integer2d_type	(	type(blockparsertype), intent(inout)	parser,
		type(inputparamdefinitiontype), intent(in)	idt,
		type(modflowinputtype), intent(in)	mf6_input,
		integer(i4b), dimension(:), intent(in), pointer, contiguous	mshape,
		logical(lgp), intent(in)	export,
		type(ncpackagevarstype), intent(in), pointer	nc_vars,
		character(len=*), intent(in)	input_fname,
		integer(i4b), intent(in)	iout
	)

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	mf6_input	description of input
[in]	mshape	model shape
[in]	export	export to ascii layer files
[in]	input_fname	ascii input file name
[in]	iout	unit number for output

Definition at line 864 of file LoadMf6File.f90.

    use sourcecommonmodule, only: get_shape_from_string, get_layered_shape
    use loadncinputmodule, only: netcdf_read_array
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    type(ModflowInputType), intent(in) :: mf6_input !< description of input
    integer(I4B), dimension(:), contiguous, pointer, intent(in) :: mshape !< model shape
    logical(LGP), intent(in) :: export !< export to ascii layer files
    type(NCPackageVarsType), pointer, intent(in) :: nc_vars
    character(len=*), intent(in) :: input_fname !< ascii input file name
    integer(I4B), intent(in) :: iout !< unit number for output
    integer(I4B), dimension(:, :), pointer, contiguous :: int2d
    integer(I4B) :: nlay
    integer(I4B) :: nsize1, nsize2
    integer(I4B), dimension(:), allocatable :: array_shape
    integer(I4B), dimension(:), allocatable :: layer_shape
    character(len=LINELENGTH) :: keyword

    ! determine the array shape from the input data definition (idt%shape),
    ! which looks like "NCOL, NROW, NLAY"
    call get_shape_from_string(idt%shape, array_shape, mf6_input%mempath)
    nsize1 = array_shape(1)
    nsize2 = array_shape(2)

    ! create a new 3d memory managed variable
    call mem_allocate(int2d, nsize1, nsize2, idt%mf6varname, mf6_input%mempath)

    ! read keyword
    keyword = ''
    call parser%GetStringCaps(keyword)

    ! check for "NETCDF" and "LAYERED"
    if (keyword == 'NETCDF') then
      call netcdf_read_array(int2d, mshape, idt, mf6_input, nc_vars, &
                             input_fname, iout)
    else if (keyword == 'LAYERED' .and. idt%layered) then
      call get_layered_shape(mshape, nlay, layer_shape)
      call read_int2d_layered(parser, int2d, idt%mf6varname, nlay, layer_shape)
    else
      call read_int2d(parser, int2d, idt%mf6varname)
    end if

    ! log information on the loaded array to the list file
    call idm_log_var(int2d, idt%tagname, mf6_input%mempath, iout)

    ! create export file for griddata parameters if optioned
    if (export) then
      if (idt%blockname == 'GRIDDATA') then
        call idm_export(int2d, idt%tagname, mf6_input%mempath, idt%shape, iout)
      end if
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

load_integer3d_type()

subroutine loadmf6filemodule::load_integer3d_type	(	type(blockparsertype), intent(inout)	parser,
		type(inputparamdefinitiontype), intent(in)	idt,
		type(modflowinputtype), intent(in)	mf6_input,
		integer(i4b), dimension(:), intent(in), pointer, contiguous	mshape,
		logical(lgp), intent(in)	export,
		type(ncpackagevarstype), intent(in), pointer	nc_vars,
		character(len=*), intent(in)	input_fname,
		integer(i4b), intent(in)	iout
	)

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	mf6_input	description of input
[in]	mshape	model shape
[in]	export	export to ascii layer files
[in]	input_fname	ascii input file name
[in]	iout	unit number for output

Definition at line 920 of file LoadMf6File.f90.

    use sourcecommonmodule, only: get_shape_from_string, get_layered_shape
    use loadncinputmodule, only: netcdf_read_array
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    type(ModflowInputType), intent(in) :: mf6_input !< description of input
    integer(I4B), dimension(:), contiguous, pointer, intent(in) :: mshape !< model shape
    logical(LGP), intent(in) :: export !< export to ascii layer files
    type(NCPackageVarsType), pointer, intent(in) :: nc_vars
    character(len=*), intent(in) :: input_fname !< ascii input file name
    integer(I4B), intent(in) :: iout !< unit number for output
    integer(I4B), dimension(:, :, :), pointer, contiguous :: int3d
    integer(I4B) :: nlay
    integer(I4B) :: nsize1, nsize2, nsize3
    integer(I4B), dimension(:), allocatable :: array_shape
    integer(I4B), dimension(:), allocatable :: layer_shape
    integer(I4B), dimension(:), pointer, contiguous :: int1d_ptr
    character(len=LINELENGTH) :: keyword

    ! determine the array shape from the input data definition (idt%shape),
    ! which looks like "NCOL, NROW, NLAY"
    call get_shape_from_string(idt%shape, array_shape, mf6_input%mempath)
    nsize1 = array_shape(1)
    nsize2 = array_shape(2)
    nsize3 = array_shape(3)

    ! create a new 3d memory managed variable
    call mem_allocate(int3d, nsize1, nsize2, nsize3, idt%mf6varname, &
                      mf6_input%mempath)

    ! read keyword
    keyword = ''
    call parser%GetStringCaps(keyword)

    ! check for "NETCDF" and "LAYERED"
    if (keyword == 'NETCDF') then
      call netcdf_read_array(int3d, mshape, idt, mf6_input, nc_vars, &
                             input_fname, iout)
    else if (keyword == 'LAYERED' .and. idt%layered) then
      call get_layered_shape(mshape, nlay, layer_shape)
      call read_int3d_layered(parser, int3d, idt%mf6varname, nlay, &
                              layer_shape)
    else
      int1d_ptr(1:nsize1 * nsize2 * nsize3) => int3d(:, :, :)
      call read_int1d(parser, int1d_ptr, idt%mf6varname)
    end if

    ! log information on the loaded array to the list file
    call idm_log_var(int3d, idt%tagname, mf6_input%mempath, iout)

    ! create export file for griddata parameters if optioned
    if (export) then
      if (idt%blockname == 'GRIDDATA') then
        call idm_export(int3d, idt%tagname, mf6_input%mempath, idt%shape, iout)
      end if
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

load_integer_type()

subroutine loadmf6filemodule::load_integer_type	(	type(blockparsertype), intent(inout)	parser,
		type(inputparamdefinitiontype), intent(in)	idt,
		character(len=*), intent(in)	memoryPath,
		integer(i4b), intent(in)	iout
	)

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	memorypath	memorypath to put loaded information
[in]	iout	unit number for output

Definition at line 792 of file LoadMf6File.f90.

    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    character(len=*), intent(in) :: memoryPath !< memorypath to put loaded information
    integer(I4B), intent(in) :: iout !< unit number for output
    integer(I4B), pointer :: intvar
    call mem_allocate(intvar, idt%mf6varname, memorypath)
    intvar = parser%GetInteger()
    call idm_log_var(intvar, idt%tagname, memorypath, idt%datatype, iout)

Here is the caller graph for this function:

load_io_tag()

subroutine loadmf6filemodule::load_io_tag	(	type(blockparsertype), intent(inout)	parser,
		type(inputparamdefinitiontype), intent(in)	idt,
		character(len=*), intent(in)	memoryPath,
		character(len=*), intent(in)	which,
		integer(i4b), intent(in)	iout
	)

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	memorypath	memorypath to put loaded information
[in]	iout	unit number for output

Definition at line 724 of file LoadMf6File.f90.

    use memorymanagermodule, only: mem_allocate, mem_reallocate, &
                                   mem_setptr, get_isize
    use characterstringmodule, only: characterstringtype
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    character(len=*), intent(in) :: memoryPath !< memorypath to put loaded information
    character(len=*), intent(in) :: which
    integer(I4B), intent(in) :: iout !< unit number for output
    character(len=LINELENGTH) :: cstr
    type(CharacterStringType), dimension(:), pointer, contiguous :: charstr1d
    integer(I4B) :: ilen, isize, idx
    ilen = linelength
    if (which == 'FILEIN') then
      call get_isize(idt%mf6varname, memorypath, isize)
      if (isize < 0) then
        call mem_allocate(charstr1d, ilen, 1, idt%mf6varname, memorypath)
        idx = 1
      else
        call mem_setptr(charstr1d, idt%mf6varname, memorypath)
        call mem_reallocate(charstr1d, ilen, isize + 1, idt%mf6varname, &
                            memorypath)
        idx = isize + 1
      end if
      call parser%GetString(cstr, (.not. idt%preserve_case))
      charstr1d(idx) = cstr
    else if (which == 'FILEOUT') then
      call load_string_type(parser, idt, memorypath, iout)
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

load_keyword_type()

subroutine loadmf6filemodule::load_keyword_type ( type(blockparsertype), intent(inout)  parser, type(inputparamdefinitiontype), intent(in)  idt, character(len=*), intent(in)  memoryPath, integer(i4b), intent(in)  iout  )

private

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	memorypath	memorypath to put loaded information
[in]	iout	unit number for output

Definition at line 686 of file LoadMf6File.f90.

    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    character(len=*), intent(in) :: memoryPath !< memorypath to put loaded information
    integer(I4B), intent(in) :: iout !< unit number for output
    integer(I4B), pointer :: intvar
    call mem_allocate(intvar, idt%mf6varname, memorypath)
    intvar = 1
    call idm_log_var(intvar, idt%tagname, memorypath, idt%datatype, iout)

Here is the caller graph for this function:

load_string_type()

subroutine loadmf6filemodule::load_string_type ( type(blockparsertype), intent(inout)  parser, type(inputparamdefinitiontype), intent(in)  idt, character(len=*), intent(in)  memoryPath, integer(i4b), intent(in)  iout  )

private

Parameters

[in,out]	parser	block parser
[in]	idt	input data type object describing this record
[in]	memorypath	memorypath to put loaded information
[in]	iout	unit number for output

Definition at line 699 of file LoadMf6File.f90.

    use constantsmodule, only: lenbigline
    type(BlockParserType), intent(inout) :: parser !< block parser
    type(InputParamDefinitionType), intent(in) :: idt !< input data type object describing this record
    character(len=*), intent(in) :: memoryPath !< memorypath to put loaded information
    integer(I4B), intent(in) :: iout !< unit number for output
    character(len=LINELENGTH), pointer :: cstr
    character(len=LENBIGLINE), pointer :: bigcstr
    integer(I4B) :: ilen
    select case (idt%shape)
    case ('LENBIGLINE')
      ilen = lenbigline
      call mem_allocate(bigcstr, ilen, idt%mf6varname, memorypath)
      call parser%GetString(bigcstr, (.not. idt%preserve_case))
      call idm_log_var(bigcstr, idt%tagname, memorypath, iout)
    case default
      ilen = linelength
      call mem_allocate(cstr, ilen, idt%mf6varname, memorypath)
      call parser%GetString(cstr, (.not. idt%preserve_case))
      call idm_log_var(cstr, idt%tagname, memorypath, iout)
    end select

Here is the caller graph for this function:

load_tag()

subroutine loadmf6filemodule::load_tag	(	class(loadmf6filetype)	this,
		integer(i4b), intent(in)	iblk,
		type(inputparamdefinitiontype), intent(in), pointer	idt
	)

Parameters

[in]

idt

input data type object describing this record

Definition at line 463 of file LoadMf6File.f90.

    use featureflagsmodule, only: developmode
    use arrayhandlersmodule, only: expandarray
    class(LoadMf6FileType) :: this
    integer(I4B), intent(in) :: iblk
    type(InputParamDefinitionType), pointer, intent(in) :: idt !< input data type object describing this record
    character(len=LINELENGTH) :: dev_msg

    ! check if input param is developmode
    if (idt%developmode) then
      dev_msg = 'Input tag "'//trim(idt%tagname)// &
        &'" read from file "'//trim(this%filename)// &
        &'" is still under development. Install the &
        &nightly build or compile from source with IDEVELOPMODE = 1.'
      call developmode(dev_msg, this%iout)
    end if

    ! allocate and load data type
    select case (idt%datatype)
    case ('KEYWORD')
      call load_keyword_type(this%parser, idt, this%mf6_input%mempath, this%iout)
      ! check/set as dev option
      if (idt%tagname(1:4) == 'DEV_' .and. &
          this%mf6_input%block_dfns(iblk)%blockname == 'OPTIONS') then
        call this%parser%DevOpt()
      end if
    case ('STRING')
      if (idt%shape == 'NAUX') then
        call load_auxvar_names(this%parser, idt, this%mf6_input%mempath, &
                               this%iout)
      else
        call load_string_type(this%parser, idt, this%mf6_input%mempath, this%iout)
      end if
    case ('INTEGER')
      call load_integer_type(this%parser, idt, this%mf6_input%mempath, this%iout)
    case ('INTEGER1D')
      call load_integer1d_type(this%parser, idt, this%mf6_input, this%mshape, &
                               this%export, this%nc_vars, this%filename, &
                               this%iout)
    case ('INTEGER2D')
      call load_integer2d_type(this%parser, idt, this%mf6_input, this%mshape, &
                               this%export, this%nc_vars, this%filename, &
                               this%iout)
    case ('INTEGER3D')
      call load_integer3d_type(this%parser, idt, this%mf6_input, this%mshape, &
                               this%export, this%nc_vars, this%filename, &
                               this%iout)
    case ('DOUBLE')
      call load_double_type(this%parser, idt, this%mf6_input%mempath, this%iout)
    case ('DOUBLE1D')
      call load_double1d_type(this%parser, idt, this%mf6_input, this%mshape, &
                              this%export, this%nc_vars, this%filename, this%iout)
    case ('DOUBLE2D')
      call load_double2d_type(this%parser, idt, this%mf6_input, this%mshape, &
                              this%export, this%nc_vars, this%filename, this%iout)
    case ('DOUBLE3D')
      call load_double3d_type(this%parser, idt, this%mf6_input, this%mshape, &
                              this%export, this%nc_vars, this%filename, this%iout)
    case default
      write (errmsg, '(a,a)') 'Failure reading data for tag: ', trim(idt%tagname)
      call store_error(errmsg)
      call this%parser%StoreErrorUnit()
    end select

    call expandarray(this%block_tags)
    this%block_tags(size(this%block_tags)) = trim(idt%tagname)

Here is the call graph for this function:

parse_block()

recursive subroutine loadmf6filemodule::parse_block	(	class(loadmf6filetype)	this,
		integer(i4b), intent(in)	iblk,
		logical(lgp), intent(in)	recursive_call
	)

Parameters

[in]

recursive_call

true if recursive call

Definition at line 269 of file LoadMf6File.f90.

    use memorytypemodule, only: memorytype
    use memorymanagermodule, only: get_from_memorystore
    class(LoadMf6FileType) :: this
    integer(I4B), intent(in) :: iblk
    logical(LGP), intent(in) :: recursive_call !< true if recursive call
    logical(LGP) :: isblockfound
    logical(LGP) :: endOfBlock
    logical(LGP) :: supportOpenClose
    integer(I4B) :: ierr
    logical(LGP) :: found, required
    type(MemoryType), pointer :: mt
    character(len=LINELENGTH) :: tag
    type(InputParamDefinitionType), pointer :: idt

    ! disu vertices/cell2d blocks are contingent on NVERT dimension
    if (this%mf6_input%pkgtype == 'DISU6' .or. &
        this%mf6_input%pkgtype == 'DISV1D6' .or. &
        this%mf6_input%pkgtype == 'DISV2D6') then
      if (this%mf6_input%block_dfns(iblk)%blockname == 'VERTICES' .or. &
          this%mf6_input%block_dfns(iblk)%blockname == 'CELL2D') then
        call get_from_memorystore('NVERT', this%mf6_input%mempath, mt, found, &
                                  .false.)
        if (.not. found) return
        if (mt%intsclr == 0) return
      end if
    end if

    ! block open/close support
    supportopenclose = (this%mf6_input%block_dfns(iblk)%blockname /= 'GRIDDATA')

    ! parser search for block
    required = this%mf6_input%block_dfns(iblk)%required .and. .not. recursive_call
    call this%parser%GetBlock(this%mf6_input%block_dfns(iblk)%blockname, &
                              isblockfound, ierr, &
                              supportopenclose=supportopenclose, &
                              blockrequired=required)
    ! process block
    if (isblockfound) then
      if (this%mf6_input%block_dfns(iblk)%aggregate) then
        ! process block recarray type, set of variable 1d/2d types
        call this%parse_structarray_block(iblk)
      else
        do
          ! process each line in block
          call this%parser%GetNextLine(endofblock)
          if (endofblock) exit
          ! process line as tag(s)
          call this%parser%GetStringCaps(tag)
          idt => get_param_definition_type( &
                 this%mf6_input%param_dfns, &
                 this%mf6_input%component_type, &
                 this%mf6_input%subcomponent_type, &
                 this%mf6_input%block_dfns(iblk)%blockname, &
                 tag, this%filename)
          if (idt%in_record) then
            call this%parse_record_tag(iblk, idt, .false.)
          else
            call this%load_tag(iblk, idt)
          end if
        end do
      end if
    end if

    ! recurse if block is reloadable and was just read
    if (this%mf6_input%block_dfns(iblk)%block_variable) then
      if (isblockfound) then
        call this%parse_block(iblk, .true.)
      end if
    end if

Here is the call graph for this function:

parse_io_tag()

subroutine loadmf6filemodule::parse_io_tag	(	class(loadmf6filetype)	this,
		integer(i4b), intent(in)	iblk,
		character(len=*), intent(in)	pkgtype,
		character(len=*), intent(in)	which,
		character(len=*), intent(in)	tag
	)

Definition at line 341 of file LoadMf6File.f90.

    use arrayhandlersmodule, only: expandarray
    class(LoadMf6FileType) :: this
    integer(I4B), intent(in) :: iblk
    character(len=*), intent(in) :: pkgtype
    character(len=*), intent(in) :: which
    character(len=*), intent(in) :: tag
    type(InputParamDefinitionType), pointer :: idt !< input data type object describing this record
    ! matches, read and load file name
    idt => &
      get_param_definition_type(this%mf6_input%param_dfns, &
                                this%mf6_input%component_type, &
                                this%mf6_input%subcomponent_type, &
                                this%mf6_input%block_dfns(iblk)%blockname, &
                                tag, this%filename)
    ! load io tag
    call load_io_tag(this%parser, idt, this%mf6_input%mempath, which, this%iout)
    call expandarray(this%block_tags)
    this%block_tags(size(this%block_tags)) = trim(idt%tagname)

Here is the call graph for this function:

parse_record_tag()

recursive subroutine loadmf6filemodule::parse_record_tag	(	class(loadmf6filetype)	this,
		integer(i4b), intent(in)	iblk,
		type(inputparamdefinitiontype), intent(in), pointer	inidt,
		logical(lgp), intent(in)	recursive_call
	)

Parameters

[in]

recursive_call

true if recursive call

Definition at line 362 of file LoadMf6File.f90.

    use definitionselectmodule, only: split_record_dfn_tag1, &
                                      split_record_dfn_tag2, &
                                      idt_datatype
    class(LoadMf6FileType) :: this
    integer(I4B), intent(in) :: iblk
    type(InputParamDefinitionType), pointer, intent(in) :: inidt
    logical(LGP), intent(in) :: recursive_call !< true if recursive call
    type(InputParamDefinitionType), pointer :: idt
    character(len=40), dimension(:), allocatable :: words
    integer(I4B) :: n, istart, nwords
    character(len=LINELENGTH) :: tag

    nullify (idt)
    istart = 1

    if (recursive_call) then
      call split_record_dfn_tag1(this%mf6_input%param_dfns, &
                                 this%mf6_input%component_type, &
                                 this%mf6_input%subcomponent_type, &
                                 inidt%tagname, nwords, words)
      call this%load_tag(iblk, inidt)
      istart = 3
    else
      call this%parser%GetStringCaps(tag)
      if (tag /= '') then
        call split_record_dfn_tag2(this%mf6_input%param_dfns, &
                                   this%mf6_input%component_type, &
                                   this%mf6_input%subcomponent_type, &
                                   inidt%tagname, tag, nwords, words)
        if (nwords == 4 .and. &
            (tag == 'FILEIN' .or. &
             tag == 'FILEOUT')) then
          call this%parse_io_tag(iblk, words(2), words(3), words(4))
          nwords = 0
        else
          idt => get_param_definition_type( &
                 this%mf6_input%param_dfns, &
                 this%mf6_input%component_type, &
                 this%mf6_input%subcomponent_type, &
                 this%mf6_input%block_dfns(iblk)%blockname, &
                 tag, this%filename)
          ! avoid namespace collisions (CIM)
          if (tag /= 'PRINT_FORMAT') call this%load_tag(iblk, inidt)
          call this%load_tag(iblk, idt)
          istart = 4
        end if
      else
        call this%load_tag(iblk, inidt)
        nwords = 0
      end if
    end if

    if (istart > 1 .and. nwords == 0) then
      write (errmsg, '(5a)') &
        '"', trim(this%mf6_input%block_dfns(iblk)%blockname), &
        '" block input record that includes keyword "', trim(inidt%tagname), &
        '" is not properly formed.'
      call store_error(errmsg)
      call this%parser%StoreErrorUnit()
    end if

    do n = istart, nwords
      idt => get_param_definition_type( &
             this%mf6_input%param_dfns, &
             this%mf6_input%component_type, &
             this%mf6_input%subcomponent_type, &
             this%mf6_input%block_dfns(iblk)%blockname, &
             words(n), this%filename)
      if (idt_datatype(idt) == 'RECORD') then
        call this%parser%GetStringCaps(tag)
        idt => get_param_definition_type( &
               this%mf6_input%param_dfns, &
               this%mf6_input%component_type, &
               this%mf6_input%subcomponent_type, &
               this%mf6_input%block_dfns(iblk)%blockname, &
               tag, this%filename)
        call this%parse_record_tag(iblk, idt, .true.)
        exit
      else
        if (idt%tagname /= 'FORMAT') then
          call this%parser%GetStringCaps(tag)
          if (tag == '') then
            exit
          else if (idt%tagname /= tag) then
            write (errmsg, '(5a)') 'Expecting record input tag "', &
              trim(idt%tagname), '" but instead found "', trim(tag), '".'
            call store_error(errmsg)
            call this%parser%StoreErrorUnit()
          end if
        end if
        call this%load_tag(iblk, idt)
      end if
    end do

    if (allocated(words)) deallocate (words)

Here is the call graph for this function:

parse_structarray_block()

subroutine loadmf6filemodule::parse_structarray_block ( class(loadmf6filetype)  this, integer(i4b), intent(in)  iblk  )

private

A structarray is similar to a numpy recarray. It it used to load a list of data in which each column in the list may be a different type. Each column in the list is stored as a 1d vector.

Definition at line 566 of file LoadMf6File.f90.

    use structarraymodule, only: structarraytype, constructstructarray
    use loadcontextmodule, only: loadcontexttype
    class(LoadMf6FileType) :: this
    integer(I4B), intent(in) :: iblk
    type(LoadContextType) :: ctx
    character(len=LINELENGTH), dimension(:), allocatable :: param_names
    type(InputParamDefinitionType), pointer :: idt !< input data type object describing this record
    type(InputParamDefinitionType), target :: blockvar_idt
    integer(I4B) :: blocknum
    integer(I4B), pointer :: nrow
    integer(I4B) :: nrows, nrowsread
    integer(I4B) :: ibinary, oc_inunit
    integer(I4B) :: icol, iparam
    integer(I4B) :: ncol, nparam

    ! initialize load context
    call ctx%init(this%mf6_input, blockname= &
                  this%mf6_input%block_dfns(iblk)%blockname)
    ! set in scope params for load
    call ctx%tags(param_names, nparam, this%filename)
    ! set input definition for this block
    idt => &
      get_aggregate_definition_type(this%mf6_input%aggregate_dfns, &
                                    this%mf6_input%component_type, &
                                    this%mf6_input%subcomponent_type, &
                                    this%mf6_input%block_dfns(iblk)%blockname)
    ! if block is reloadable read the block number
    if (this%mf6_input%block_dfns(iblk)%block_variable) then
      blocknum = this%parser%GetInteger()
    else
      blocknum = 0
    end if

    ! set ncol
    ncol = nparam
    ! add col if block is reloadable
    if (blocknum > 0) ncol = ncol + 1
    ! use shape to set the max num of rows
    if (idt%shape /= '') then
      call mem_setptr(nrow, idt%shape, this%mf6_input%mempath)
      nrows = nrow
    else
      nrows = -1
    end if

    ! create a structured array
    this%structarray => constructstructarray(this%mf6_input, ncol, nrows, &
                                             blocknum, this%mf6_input%mempath, &
                                             this%mf6_input%component_mempath)
    ! create structarray vectors for each column
    do icol = 1, ncol
      ! if block is reloadable, block number is first column
      if (blocknum > 0) then
        if (icol == 1) then
          blockvar_idt = this%block_index_dfn(iblk)
          idt => blockvar_idt
          call this%structarray%mem_create_vector(icol, idt)
          ! continue as this column managed by internally SA object
          cycle
        end if
        ! set indexes (where first column is blocknum)
        iparam = icol - 1
      else
        ! set indexes (no blocknum column)
        iparam = icol
      end if
      ! set pointer to input definition for this 1d vector
      idt => &
        get_param_definition_type(this%mf6_input%param_dfns, &
                                  this%mf6_input%component_type, &
                                  this%mf6_input%subcomponent_type, &
                                  this%mf6_input%block_dfns(iblk)%blockname, &
                                  param_names(iparam), this%filename)
      ! allocate variable in memory manager
      call this%structarray%mem_create_vector(icol, idt)
    end do

    ! finish context setup after allocating vectors
    call ctx%allocate_arrays()

    ! read the block control record
    ibinary = read_control_record(this%parser, oc_inunit, this%iout)

    if (ibinary == 1) then
      ! read from binary
      nrowsread = this%structarray%read_from_binary(oc_inunit, this%iout)
      call this%parser%terminateblock()
      close (oc_inunit)
    else
      ! read from ascii
      nrowsread = this%structarray%read_from_parser(this%parser, this%ts_active, &
                                                    this%iout, this%filename)
      ! save structarray for deferred TS linking in df() if any strlocs were stored
      if (this%ts_active) call this%save_ts_sa()
    end if

    ! clean up
    call ctx%destroy()

Here is the call graph for this function:

read_control_record()

integer(i4b) function, public loadmf6filemodule::read_control_record	(	type(blockparsertype), intent(inout)	parser,
		integer(i4b), intent(inout)	oc_inunit,
		integer(i4b), intent(in)	iout
	)

Definition at line 1167 of file LoadMf6File.f90.

    use simmodule, only: store_error_unit
    use inputoutputmodule, only: urword
    use inputoutputmodule, only: openfile
    use openspecmodule, only: form, access
    use constantsmodule, only: linelength
    use blockparsermodule, only: blockparsertype
    type(BlockParserType), intent(inout) :: parser
    integer(I4B), intent(inout) :: oc_inunit
    integer(I4B), intent(in) :: iout
    integer(I4B) :: ibinary
    integer(I4B) :: lloc, istart, istop, idum, inunit, itmp, ierr
    integer(I4B) :: nunopn = 99
    character(len=:), allocatable :: line
    character(len=LINELENGTH) :: fname
    logical(LGP) :: exists
    real(DP) :: r
    character(len=*), parameter :: fmtocne = &
      &"('Specified OPEN/CLOSE file ',(A),' does not exist')"
    character(len=*), parameter :: fmtobf = &
      &"(1X,/1X,'OPENING BINARY FILE ON UNIT ',I0,':',/1X,A)"

    ! initialize oc_inunit and ibinary
    oc_inunit = 0
    ibinary = 0
    inunit = parser%getunit()

    ! Read to the first non-commented line
    lloc = 1
    call parser%line_reader%rdcom(inunit, iout, line, ierr)
    call urword(line, lloc, istart, istop, 1, idum, r, iout, inunit)

    if (line(istart:istop) == 'OPEN/CLOSE') then
      ! get filename
      call urword(line, lloc, istart, istop, 0, idum, r, &
                  iout, inunit)
      fname = line(istart:istop)
      ! check to see if file OPEN/CLOSE file exists
      inquire (file=fname, exist=exists)
      if (.not. exists) then
        write (errmsg, fmtocne) line(istart:istop)
        call store_error(errmsg)
        call store_error('Specified OPEN/CLOSE file does not exist')
        call store_error_unit(inunit)
      end if

      ! Check for (BINARY) keyword
      call urword(line, lloc, istart, istop, 1, idum, r, &
                  iout, inunit)

      if (line(istart:istop) == '(BINARY)') ibinary = 1
      ! Open the file depending on ibinary flag
      if (ibinary == 1) then
        oc_inunit = nunopn
        itmp = iout
        if (iout > 0) then
          itmp = 0
          write (iout, fmtobf) oc_inunit, trim(adjustl(fname))
        end if
        call openfile(oc_inunit, itmp, fname, 'OPEN/CLOSE', &
                      fmtarg_opt=form, accarg_opt=access)
      end if
    end if

    if (ibinary == 0) then
      call parser%line_reader%bkspc(parser%getunit())
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

save_ts_sa()

subroutine loadmf6filemodule::save_ts_sa

(

class(loadmf6filetype), intent(inout)

this

)

Saves the current structarray pointer when it contains TS string locs, then nullifies the pointer so load_block does not destroy it.

Definition at line 1241 of file LoadMf6File.f90.

    class(LoadMf6FileType), intent(inout) :: this
    type(StructVectorType), pointer :: svect
    type(StaticSAType), allocatable :: tmp(:)
    logical(LGP) :: has_ts
    integer(I4B) :: m, n

    ! check if any column has deferred TS strlocs
    has_ts = .false.
    do m = 1, this%structarray%count()
      svect => this%structarray%get(m)
      if (svect%idt%timeseries .and. svect%ts_strlocs%count() > 0) then
        has_ts = .true.
        exit
      end if
    end do

    if (has_ts) then
      n = size(this%ts_sas)
      allocate (tmp(n + 1))
      tmp(1:n) = this%ts_sas
      tmp(n + 1)%sa => this%structarray
      call move_alloc(tmp, this%ts_sas)
      ! nullify so load_block does not destroy the saved SA
      nullify (this%structarray)
    end if

ts_sa_count()

integer(i4b) function loadmf6filemodule::ts_sa_count

(

class(loadmf6filetype), intent(in)

this

)

Definition at line 669 of file LoadMf6File.f90.

    class(LoadMf6FileType), intent(in) :: this
    integer(I4B) :: n
    n = size(this%ts_sas)
