gwfvscmodule Module Reference

Data Types
type	concentrationpointer
type	gwfvsctype

Functions/Subroutines
real(dp) function	calc_visc (ivisc, viscref, dviscdc, cviscref, conc, a2, a3, a4)
	Generic function to calculate changes in fluid viscosity using a linear formulation. More...
subroutine, public	vsc_cr (vscobj, name_model, input_mempath, inunit, iout)
	@ brief Create a new package object More...
subroutine	vsc_df (this, dis, vsc_input)
	@ brief Define viscosity package options and dimensions More...
subroutine	vsc_ar (this, ibound)
	@ brief Allocate and read method for viscosity package More...
subroutine	vsc_ar_bnd (this, packobj)
	Activate viscosity in advanced packages. More...
subroutine	set_npf_pointers (this)
	Set pointers to NPF variables. More...
subroutine	vsc_rp (this)
	@ brief Read new period data in viscosity package More...
subroutine	vsc_ad (this)
	@ brief Advance the viscosity package More...
subroutine	vsc_ad_bnd (this, packobj, hnew)
	Advance the boundary packages when viscosity is active. More...
subroutine	vsc_ad_standard_bnd (packobj, hnew, visc, viscref, locelev, locvisc, locconc, dviscdc, cviscref, ivisc, a2, a3, a4, ctemp)
	advance ghb while accounting for viscosity More...
subroutine	vsc_ad_sfr (packobj, visc, viscref, elev, locvisc, locconc, dviscdc, cviscref, ivisc, a2, a3, a4, ctemp)
	Update sfr-related viscosity ratios. More...
subroutine	vsc_ad_lak (packobj, visc, viscref, elev, locvisc, locconc, dviscdc, cviscref, ivisc, a2, a3, a4, ctemp)
	Update lak-related viscosity ratios. More...
subroutine	vsc_ad_maw (packobj, visc, viscref, elev, locvisc, locconc, dviscdc, cviscref, ivisc, a2, a3, a4, ctemp)
	Update maw-related viscosity ratios. More...
real(dp) function	update_bnd_cond (bndvisc, viscref, spcfdcond)
	Apply viscosity to the conductance term. More...
real(dp) function	calc_vsc_ratio (viscref, bndvisc)
	calculate and return the viscosity ratio More...
real(dp) function	calc_bnd_viscosity (n, locvisc, locconc, viscref, dviscdc, cviscref, ctemp, ivisc, a2, a3, a4, auxvar)
	@ brief Calculate the boundary viscosity More...
subroutine	get_visc_ratio (this, n, m, gwhdn, gwhdm, viscratio)
	Calculate the viscosity ratio. More...
subroutine	calc_q_visc (this, cellid, viscratio)
	Account for viscosity in the aquiferhorizontal flow barriers. More...
subroutine	update_k_with_vsc (this)
	Appled the viscosity ratio (mu_o/mu) to the hydraulic conductivity. More...
subroutine	vsc_set_changed_at (this, kper, kstp)
	Mark K changes as having occurred at (kper, kstp) More...
subroutine	vsc_ot_dv (this, idvfl)
	@ brief Output viscosity package dependent-variable terms. More...
subroutine	vsc_da (this)
	@ brief Deallocate viscosity package memory More...
subroutine	source_dimensions (this)
	@ brief Source dimensions for package More...
subroutine	source_packagedata (this)
	@ brief source packagedata for package More...
subroutine	set_packagedata (this, input_data)
	Sets package data instead of reading from file. More...
subroutine	vsc_calcvisc (this)
	Calculate fluid viscosity. More...
subroutine	allocate_scalars (this)
	@ brief Allocate scalars More...
subroutine	allocate_arrays (this, nodes)
	@ brief Allocate arrays More...
subroutine	source_options (this)
	@ brief Source VSC options More...
subroutine	log_options (this, found, viscosityfile)
	@ brief log VSC options More...
subroutine	set_options (this, input_data)
	Sets options as opposed to reading them from a file. More...
subroutine	set_concentration_pointer (this, modelname, conc, icbund, istmpr)
	@ brief Set pointers to concentration(s) More...

Function/Subroutine Documentation

allocate_arrays()

subroutine gwfvscmodule::allocate_arrays	(	class(gwfvsctype)	this,
		integer(i4b), intent(in)	nodes
	)

Allocate and initialize arrays for the VSC package.

Definition at line 1167 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    integer(I4B), intent(in) :: nodes
    ! -- local
    integer(I4B) :: i
    !
    ! -- Allocate
    call mem_allocate(this%visc, nodes, 'VISC', this%memoryPath)
    call mem_allocate(this%ivisc, this%nviscspecies, 'IVISC', this%memoryPath)
    call mem_allocate(this%dviscdc, this%nviscspecies, 'DRHODC', &
                      this%memoryPath)
    call mem_allocate(this%cviscref, this%nviscspecies, 'CRHOREF', &
                      this%memoryPath)
    call mem_allocate(this%ctemp, this%nviscspecies, 'CTEMP', this%memoryPath)
    allocate (this%cmodelname(this%nviscspecies))
    allocate (this%cauxspeciesname(this%nviscspecies))
    allocate (this%modelconc(this%nviscspecies))
    !
    ! -- Initialize
    do i = 1, nodes
      this%visc(i) = this%viscref
    end do
    !
    ! -- Initialize nviscspecies arrays
    do i = 1, this%nviscspecies
      this%ivisc(i) = 1
      this%dviscdc(i) = dzero
      this%cviscref(i) = dzero
      this%ctemp(i) = dzero
      this%cmodelname(i) = ''
      this%cauxspeciesname(i) = ''
    end do

allocate_scalars()

subroutine gwfvscmodule::allocate_scalars ( class(gwfvsctype)  this )

private

Allocate and initialize scalars for the VSC package. The base model allocate scalars method is also called.

Definition at line 1127 of file gwf-vsc.f90.

    ! -- modules
    use constantsmodule, only: dzero, dten, dep3
    ! -- dummy
    class(GwfVscType) :: this
    !
    ! -- allocate scalars in NumericalPackageType
    call this%NumericalPackageType%allocate_scalars()
    !
    ! -- Allocate
    call mem_allocate(this%thermivisc, 'THERMIVISC', this%memoryPath)
    call mem_allocate(this%idxtmpr, 'IDXTMPR', this%memoryPath)
    call mem_allocate(this%ioutvisc, 'IOUTVISC', this%memoryPath)
    call mem_allocate(this%ireadelev, 'IREADELEV', this%memoryPath)
    call mem_allocate(this%iconcset, 'ICONCSET', this%memoryPath)
    call mem_allocate(this%viscref, 'VISCREF', this%memoryPath)
    call mem_allocate(this%a2, 'A2', this%memoryPath)
    call mem_allocate(this%a3, 'A3', this%memoryPath)
    call mem_allocate(this%a4, 'A4', this%memoryPath)
    !
    call mem_allocate(this%nviscspecies, 'NVISCSPECIES', this%memoryPath)
    !
    ! -- Initialize
    this%thermivisc = 0
    this%idxtmpr = 0
    this%ioutvisc = 0
    this%ireadelev = 0
    this%iconcset = 0
    this%viscref = dep3
    this%A2 = dten
    this%A3 = 248.37_dp
    this%A4 = 133.15_dp
    !
    this%nviscspecies = 0

calc_bnd_viscosity()

real(dp) function gwfvscmodule::calc_bnd_viscosity ( integer(i4b), intent(in)  n, integer(i4b), intent(in)  locvisc, integer(i4b), dimension(:), intent(in)  locconc, real(dp), intent(in)  viscref, real(dp), dimension(:), intent(in)  dviscdc, real(dp), dimension(:), intent(in)  cviscref, real(dp), dimension(:), intent(inout)  ctemp, integer(i4b), dimension(:), intent(in)  ivisc, real(dp), intent(in)  a2, real(dp), intent(in)  a3, real(dp), intent(in)  a4, real(dp), dimension(:, :), intent(in)  auxvar  )

private

Return the viscosity of the boundary package using one of the options in the following order of priority:

1. Assign as aux variable in column with name 'VISCOSITY'
2. Calculate using viscosity equation and nviscspecies aux columns
3. If neither of those, then assign as viscref !!

Definition at line 730 of file gwf-vsc.f90.

    ! -- modules
    ! -- dummy
    integer(I4B), intent(in) :: n
    integer(I4B), intent(in) :: locvisc
    real(DP), intent(in) :: a2, a3, a4
    integer(I4B), dimension(:), intent(in) :: ivisc
    integer(I4B), dimension(:), intent(in) :: locconc
    real(DP), intent(in) :: viscref
    real(DP), dimension(:), intent(in) :: dviscdc
    real(DP), dimension(:), intent(in) :: cviscref
    real(DP), dimension(:), intent(inout) :: ctemp
    real(DP), dimension(:, :), intent(in) :: auxvar
    ! -- Return
    real(DP) :: viscbnd
    ! -- local
    integer(I4B) :: i
    !
    ! -- assign boundary viscosity based on one of three options
    if (locvisc > 0) then
      ! -- assign viscosity to an aux column named 'VISCOSITY'
      viscbnd = auxvar(locvisc, n)
    else if (locconc(1) > 0) then
      ! -- calculate viscosity using one or more concentration auxcolumns
      do i = 1, size(locconc)
        ctemp(i) = dzero
        if (locconc(i) > 0) then
          ctemp(i) = auxvar(locconc(i), n)
        end if
      end do
      viscbnd = calc_visc(ivisc, viscref, dviscdc, cviscref, ctemp, a2, a3, a4)
    else
      ! -- neither of the above, so assign as viscref
      viscbnd = viscref
    end if

Here is the call graph for this function:

Here is the caller graph for this function:

calc_q_visc()

subroutine gwfvscmodule::calc_q_visc	(	class(gwfvsctype)	this,
		integer(i4b), intent(in)	cellid,
		real(dp), intent(inout)	viscratio
	)

Will return the viscosity associated with the upgradient node (cell) to the HFB package for adjusting the hydraulic characteristic (hydchr) of the barrier

Definition at line 801 of file gwf-vsc.f90.

    ! -- dummy variables
    class(GwfVscType) :: this
    integer(I4B), intent(in) :: cellid
    ! -- Return
    real(DP), intent(inout) :: viscratio
    ! -- local
    real(DP) :: visc
    !
    ! -- Retrieve viscosity for the passed node number
    visc = this%visc(cellid)
    !
    ! -- Calculate the viscosity ratio for the
    viscratio = calc_vsc_ratio(this%viscref, visc)

Here is the call graph for this function:

calc_visc()

real(dp) function gwfvscmodule::calc_visc ( integer(i4b), dimension(:), intent(in)  ivisc, real(dp), intent(in)  viscref, real(dp), dimension(:), intent(in)  dviscdc, real(dp), dimension(:), intent(in)  cviscref, real(dp), dimension(:), intent(in)  conc, real(dp), intent(in)  a2, real(dp), intent(in)  a3, real(dp), intent(in)  a4  )

private

Definition at line 100 of file gwf-vsc.f90.

    ! -- dummy
    integer(I4B), dimension(:), intent(in) :: ivisc
    real(DP), intent(in) :: viscref
    real(DP), dimension(:), intent(in) :: dviscdc
    real(DP), dimension(:), intent(in) :: cviscref
    real(DP), dimension(:), intent(in) :: conc
    real(DP), intent(in) :: a2, a3, a4
    ! -- return
    real(DP) :: visc
    ! -- local
    integer(I4B) :: nviscspec
    integer(I4B) :: i
    real(DP) :: mu_t
    real(DP) :: expon
    !
    nviscspec = size(dviscdc)
    visc = viscref
    !
    do i = 1, nviscspec
      if (ivisc(i) == 1) then
        visc = visc + dviscdc(i) * (conc(i) - cviscref(i))
      else
        expon = -1 * a3 * ((conc(i) - cviscref(i)) / &
                           ((conc(i) + a4) * (cviscref(i) + a4)))
        mu_t = viscref * a2**expon
        ! Order matters!! (This assumes we apply the temperature correction after
        ! accounting for solute concentrations)
        ! If a nonlinear correction is applied, then b/c it takes into account
        ! viscref, need to subtract it in this case
        ! At most, there will only ever be 1 nonlinear correction
        visc = (visc - viscref) + mu_t
      end if
      ! end if
    end do

Here is the caller graph for this function:

calc_vsc_ratio()

real(dp) function gwfvscmodule::calc_vsc_ratio ( real(dp), intent(in)  viscref, real(dp), intent(in)  bndvisc  )

private

Definition at line 712 of file gwf-vsc.f90.

    ! -- dummy
    real(DP), intent(in) :: viscref
    real(DP), intent(in) :: bndvisc
    ! -- local
    real(DP) :: viscratio
    !
    viscratio = viscref / bndvisc

Here is the caller graph for this function:

get_visc_ratio()

subroutine gwfvscmodule::get_visc_ratio ( class(gwfvsctype)  this, integer(i4b), intent(in)  n, integer(i4b), intent(in)  m, real(dp), intent(in)  gwhdn, real(dp), intent(in)  gwhdm, real(dp), intent(inout)  viscratio  )

private

Calculate the viscosity ratio applied to the hydraulic characteristic provided by the user. The viscosity ratio is applicable only when the hydraulic characteristic is specified as positive and will not be applied when the hydchr is negative

Definition at line 775 of file gwf-vsc.f90.

    ! -- modules
    use constantsmodule, only: done
    ! -- dummy
    class(GwfVscType) :: this
    integer(I4B), intent(in) :: n, m
    real(DP), intent(in) :: gwhdn, gwhdm
    real(DP), intent(inout) :: viscratio
    ! -- loca
    integer(I4B) :: cellid
    !
    viscratio = done
    if (gwhdm > gwhdn) then
      cellid = m
    else if (gwhdn >= gwhdm) then
      cellid = n
    end if
    call this%calc_q_visc(cellid, viscratio)

log_options()

subroutine gwfvscmodule::log_options	(	class(gwfvsctype), intent(inout)	this,
		type(gwfvscparamfoundtype), intent(in)	found,
		character(len=*), intent(in)	viscosityfile
	)

Definition at line 1282 of file gwf-vsc.f90.

    ! -- modules
    use gwfvscinputmodule, only: gwfvscparamfoundtype
    ! -- dummy variables
    class(GwfVscType), intent(inout) :: this
    type(GwfVscParamFoundType), intent(in) :: found
    character(len=*), intent(in) :: viscosityfile
    ! -- local variables
    ! -- formats
    character(len=*), parameter :: fmtfileout = &
      "(4x, 'VSC', 1x, a, 1x, 'Will be saved to file: ', &
      &a, ' opened on unit: ', I7)"
    character(len=*), parameter :: fmtlinear = &
      "(4x,'Viscosity will vary linearly with temperature &
      &change ')"
    character(len=*), parameter :: fmtnonlinear = &
      "(4x,'Viscosity will vary non-linearly with temperature &
      &change ')"

    write (this%iout, '(1x,a)') 'Processing VSC OPTIONS block'

    if (found%viscref) then
      write (this%iout, '(4x,a,1pg15.6)') &
        'Reference viscosity has been set to: ', this%viscref
    end if
    if (found%viscosityfile) then
      write (this%iout, fmtfileout) &
        'VISCOSITY', trim(viscosityfile), this%ioutvisc
    end if
    if (found%temp_specname) then
      write (this%iout, '(4x, a)') 'Temperature species name set to: '// &
        trim(this%name_temp_spec)
    end if
    if (found%thermal_form) then
      select case (this%thermivisc)
      case (1)
        write (this%iout, fmtlinear)
      case (2)
        write (this%iout, fmtnonlinear)
      end select
    end if
    if (found%thermal_a2) then
      if (this%thermivisc == 2) then
        write (this%iout, '(4x,a,1pg15.6)') &
          'A2 in nonlinear viscosity formulation has been set to: ', &
          this%a2
      else
        write (this%iout, '(4x,a,/,4x,a,/,4x,a)') 'THERMAL_A2 specified by user &
          &in VSC Package input file. LINEAR viscosity ', 'formulation also &
          &specified. THERMAL_A2 will not affect ', 'viscosity calculations.'
      end if
    end if
    if (found%thermal_a3) then
      if (this%thermivisc == 2) then
        write (this%iout, '(4x,a,1pg15.6)') &
          'A3 in nonlinear viscosity formulation has been set to: ', &
          this%a3
      else
        write (this%iout, '(4x,a,/,4x,a,/,4x,a)') 'THERMAL_A3 specified by user &
          &in VSC Package input file. LINEAR viscosity ', 'formulation also &
          &specified. THERMAL_A3 will not affect ', 'viscosity calculations.'
      end if
    end if
    if (found%thermal_a4) then
      if (this%thermivisc == 2) then
        write (this%iout, '(4x,a,1pg15.6)') &
          'A4 in nonlinear viscosity formulation has been set to: ', &
          this%a4
      else
        write (this%iout, '(4x,a,/,4x,a,/,4x,a)') 'THERMAL_A4 specified by user &
          &in VSC Package input file. LINEAR viscosity ', 'formulation also &
          &specified. THERMAL_A4 will not affect ', 'viscosity calculations.'
      end if
    end if

    write (this%iout, '(1x,a)') 'end of VSC options block'

set_concentration_pointer()

subroutine gwfvscmodule::set_concentration_pointer ( class(gwfvsctype)  this, character(len=lenmodelname), intent(in)  modelname, real(dp), dimension(:), pointer  conc, integer(i4b), dimension(:), pointer  icbund, integer(i4b), intent(in), optional  istmpr  )

private

Pass in a gwt model name, concentration array, and ibound, and store a pointer to these in the VSC package so that viscosity can be calculated from them. This routine is called from the gwfgwt exchange in the exg_ar() method.

Definition at line 1377 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    character(len=LENMODELNAME), intent(in) :: modelname
    real(DP), dimension(:), pointer :: conc
    integer(I4B), dimension(:), pointer :: icbund
    integer(I4B), optional, intent(in) :: istmpr
    ! -- local
    integer(I4B) :: i
    logical :: found
    !
    this%iconcset = 1
    found = .false.
    do i = 1, this%nviscspecies
      if (this%cmodelname(i) == modelname) then
        this%modelconc(i)%conc => conc
        this%modelconc(i)%icbund => icbund
        found = .true.
        exit
      end if
    end do

set_npf_pointers()

subroutine gwfvscmodule::set_npf_pointers

(

class(gwfvsctype)

this

)

Set array and variable pointers from the NPF package for access by VSC.

Definition at line 301 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    ! -- local
    character(len=LENMEMPATH) :: npfMemoryPath
    !
    ! -- Set pointers to other package variables
    ! -- NPF
    npfmemorypath = create_mem_path(this%name_model, 'NPF')
    call mem_setptr(this%k11, 'K11', npfmemorypath)
    call mem_setptr(this%k22, 'K22', npfmemorypath)
    call mem_setptr(this%k33, 'K33', npfmemorypath)
    call mem_setptr(this%k11input, 'K11INPUT', npfmemorypath)
    call mem_setptr(this%k22input, 'K22INPUT', npfmemorypath)
    call mem_setptr(this%k33input, 'K33INPUT', npfmemorypath)
    call mem_setptr(this%kchangeper, 'KCHANGEPER', npfmemorypath)
    call mem_setptr(this%kchangestp, 'KCHANGESTP', npfmemorypath)
    call mem_setptr(this%nodekchange, 'NODEKCHANGE', npfmemorypath)

Here is the call graph for this function:

set_options()

subroutine gwfvscmodule::set_options	(	class(gwfvsctype)	this,
		type(gwfvscinputdatatype), intent(in)	input_data
	)

Parameters

[in]

input_data

the input data to be set

Definition at line 1362 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    type(GwfVscInputDataType), intent(in) :: input_data !< the input data to be set
    !
    this%viscref = input_data%viscref

set_packagedata()

subroutine gwfvscmodule::set_packagedata	(	class(gwfvsctype)	this,
		type(gwfvscinputdatatype), intent(in)	input_data
	)

Parameters

	this	this vscoancy pkg
[in]	input_data	the input data to be set

Definition at line 1078 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this !< this vscoancy pkg
    type(GwfVscInputDataType), intent(in) :: input_data !< the input data to be set
    ! -- local
    integer(I4B) :: ispec
    !
    do ispec = 1, this%nviscspecies
      this%dviscdc(ispec) = input_data%dviscdc(ispec)
      this%cviscref(ispec) = input_data%cviscref(ispec)
      this%cmodelname(ispec) = input_data%cmodelname(ispec)
      this%cauxspeciesname(ispec) = input_data%cauxspeciesname(ispec)
    end do

source_dimensions()

subroutine gwfvscmodule::source_dimensions ( class(gwfvsctype), intent(inout)  this )

private

Definition at line 949 of file gwf-vsc.f90.

    ! -- modules
    use memorymanagerextmodule, only: mem_set_value
    use gwfvscinputmodule, only: gwfvscparamfoundtype
    ! -- dummy
    class(GwfVscType), intent(inout) :: this
    ! -- local
    type(GwfVscParamFoundType) :: found

    ! update defaults from input context
    call mem_set_value(this%nviscspecies, 'NVISCSPECIES', this%input_mempath, &
                       found%nviscspecies)

    ! log dimensions
    write (this%iout, '(/1x,a)') 'Processing VSC DIMENSIONS block'
    write (this%iout, '(4x,a,i0)') 'NVISCSPECIES = ', this%nviscspecies
    write (this%iout, '(1x,a)') 'End of VSC DIMENSIONS block'

    ! check dimension
    if (this%nviscspecies < 1) then
      call store_error('NVISCSPECIES must be greater than zero.')
      call store_error_filename(this%input_fname)
    end if

Here is the call graph for this function:

source_options()

subroutine gwfvscmodule::source_options ( class(gwfvsctype), intent(inout)  this )

private

Definition at line 1204 of file gwf-vsc.f90.

    ! -- modules
    use constantsmodule, only: lenvarname
    use memorymanagerextmodule, only: mem_set_value
    use openspecmodule, only: access, form
    use inputoutputmodule, only: getunit, openfile
    use gwfvscinputmodule, only: gwfvscparamfoundtype
    ! -- dummy
    class(GwfVscType), intent(inout) :: this
    ! -- local
    character(len=LENVARNAME), dimension(2) :: thermal_form = &
      &[character(len=LENVARNAME) :: 'LINEAR', 'NONLINEAR']
    character(len=linelength) :: viscosityfile
    type(GwfVscParamFoundType) :: found

    ! initialize variables
    viscosityfile = ''

    ! update defaults from input context
    call mem_set_value(this%viscref, 'VISCREF', this%input_mempath, &
                       found%viscref)
    call mem_set_value(viscosityfile, 'VISCOSITYFILE', this%input_mempath, &
                       found%viscosityfile)
    call mem_set_value(this%name_temp_spec, 'TEMP_SPECNAME', this%input_mempath, &
                       found%temp_specname)
    call mem_set_value(this%thermivisc, 'THERMAL_FORM', this%input_mempath, &
                       thermal_form, found%thermal_form)
    call mem_set_value(this%a2, 'THERMAL_A2', this%input_mempath, &
                       found%thermal_a2)
    call mem_set_value(this%a3, 'THERMAL_A3', this%input_mempath, &
                       found%thermal_a3)
    call mem_set_value(this%a4, 'THERMAL_A4', this%input_mempath, &
                       found%thermal_a4)

    ! fileout options
    if (found%viscosityfile) then
      this%ioutvisc = getunit()
      call openfile(this%ioutvisc, this%iout, viscosityfile, 'DATA(BINARY)', &
                    form, access, 'REPLACE')
    end if

    ! set warnings and errors
    if (this%thermivisc == 1) then
      if (this%a2 == 0.0) then
        write (errmsg, '(a)') 'LINEAR option selected for varying  &
          &viscosity with temperature, but A1, a surrogate for &
          &dVISC/dT, set equal to 0.0'
        call store_error(errmsg)
        call store_error_filename(this%input_fname)
      end if
    end if
    if (this%thermivisc > 1) then
      if (this%a2 == 0) then
        write (warnmsg, '(a)') 'NONLINEAR option selected for &
          &varying viscosity with temperature, but A2 set equal to &
          &zero which may lead to unintended values for viscosity'
        call store_warning(warnmsg)
      end if
      if (this%a3 == 0) then
        write (warnmsg, '(a)') 'NONLINEAR option selected for &
          &varying viscosity with temperature,, but A3 set equal to &
          &zero which may lead to unintended values for viscosity'
        call store_warning(warnmsg)
      end if
      if (this%a4 == 0) then
        write (warnmsg, '(a)') 'NONLINEAR option selected for &
          &varying viscosity with temperature, BUT A4 SET EQUAL TO &
          &zero which may lead to unintended values for viscosity'
        call store_warning(warnmsg)
      end if
    end if

    ! log options
    call this%log_options(found, viscosityfile)

Here is the call graph for this function:

source_packagedata()

subroutine gwfvscmodule::source_packagedata

(

class(gwfvsctype), intent(inout)

this

)

Definition at line 976 of file gwf-vsc.f90.

    ! -- modules
    use memorymanagermodule, only: mem_setptr
    use characterstringmodule, only: characterstringtype
    ! -- dummy
    class(GwfVscType), intent(inout) :: this
    integer(I4B), dimension(:), pointer, contiguous :: iviscspec
    type(CharacterStringType), dimension(:), pointer, &
      contiguous :: modelnames, auxspeciesnames
    real(DP), dimension(:), pointer, contiguous :: dviscdc, cviscref
    integer(I4B), dimension(:), allocatable :: itemp
    character(len=LINELENGTH) :: modelname, auxspeciesname, line
    character(len=10) :: c10
    character(len=16) :: c16
    integer(I4B) :: n
    ! -- format
    character(len=*), parameter :: fmterr = &
      "('Invalid value for IRHOSPEC (',i0,') detected in VSC Package. &
      &IRHOSPEC must be > 0 and <= NVISCSPECIES, and duplicate values &
      &are not allowed.')"

    ! initialize
    allocate (itemp(this%nviscspecies))
    itemp(:) = 0

    ! set input context pointers
    call mem_setptr(iviscspec, 'IVISCSPEC', this%input_mempath)
    call mem_setptr(dviscdc, 'DVISCDC', this%input_mempath)
    call mem_setptr(cviscref, 'CVISCREF', this%input_mempath)
    call mem_setptr(modelnames, 'MODELNAME', this%input_mempath)
    call mem_setptr(auxspeciesnames, 'AUXSPECIESNAME', this%input_mempath)

    ! process package data
    do n = 1, size(iviscspec)
      modelname = modelnames(n)
      auxspeciesname = auxspeciesnames(n)

      if (iviscspec(n) < 1 .or. iviscspec(n) > this%nviscspecies) then
        write (errmsg, fmterr) iviscspec(n)
        call store_error(errmsg)
      end if
      if (itemp(iviscspec(n)) /= 0) then
        write (errmsg, fmterr) iviscspec(n)
        call store_error(errmsg)
      end if
      itemp(iviscspec(n)) = 1
      !
      this%dviscdc(iviscspec(n)) = dviscdc(n)
      this%cviscref(iviscspec(n)) = cviscref(n)
      this%cmodelname(iviscspec(n)) = trim(modelname)
      this%cauxspeciesname(iviscspec(n)) = trim(auxspeciesname)
      !
      if (auxspeciesname == this%name_temp_spec) then
        if (this%idxtmpr > 0) then
          write (errmsg, '(a)') 'More than one species in VSC input identified &
            &as '//trim(this%name_temp_spec)//'. Only one species may be &
            &designated to represent temperature.'
          call store_error(errmsg)
        else
          this%idxtmpr = iviscspec(n)
          if (this%thermivisc == 2) then
            this%ivisc(iviscspec(n)) = 2
          end if
        end if
      end if
    end do

    ! Check for errors.
    if (count_errors() > 0) then
      call store_error_filename(this%input_fname)
    end if

    ! log package data
    write (this%iout, '(/,1x,a)') 'Processing VSC PACKAGEDATA block'

    ! write packagedata information
    write (this%iout, '(1x,a)') 'Summary of species information in VSC Package'
    write (this%iout, '(1a11,5a17)') &
      'Species', 'DVISCDC', 'CVISCREF', 'Model', 'AUXSPECIESNAME'
    do n = 1, this%nviscspecies
      write (c10, '(i0)') n
      line = ' '//adjustr(c10)

      write (c16, '(g15.6)') this%dviscdc(n)
      line = trim(line)//' '//adjustr(c16)
      write (c16, '(g15.6)') this%cviscref(n)
      line = trim(line)//' '//adjustr(c16)
      write (c16, '(a)') this%cmodelname(n)
      line = trim(line)//' '//adjustr(c16)
      write (c16, '(a)') this%cauxspeciesname(n)
      line = trim(line)//' '//adjustr(c16)
      write (this%iout, '(a)') trim(line)
    end do

    write (this%iout, '(1x,a)') 'End of VSC PACKAGEDATA block'

    ! deallocate
    deallocate (itemp)

Here is the call graph for this function:

update_bnd_cond()

real(dp) function gwfvscmodule::update_bnd_cond	(	real(dp), intent(in)	bndvisc,
		real(dp), intent(in)	viscref,
		real(dp), intent(in)	spcfdcond
	)

When the viscosity package is active apply the viscosity ratio to the active boundary package's conductance term.

Definition at line 695 of file gwf-vsc.f90.

    ! -- dummy
    real(DP), intent(in) :: viscref
    real(DP), intent(in) :: bndvisc
    real(DP), intent(in) :: spcfdcond
    ! -- local
    real(DP) :: vscratio
    real(DP) :: updatedcond
    !
    vscratio = calc_vsc_ratio(viscref, bndvisc)
    !
    ! -- calculate new conductance here
    updatedcond = vscratio * spcfdcond

Here is the call graph for this function:

Here is the caller graph for this function:

update_k_with_vsc()

subroutine gwfvscmodule::update_k_with_vsc ( class(gwfvsctype)  this )

private

This routine called after updating the viscosity values using the latest concentration and/or temperature values. The ratio mu_o/mu, reference viscosity divided by the updated viscosity value, is multiplied by K for each cell.

Definition at line 824 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    ! -- local
    integer(I4B) :: n
    real(DP) :: viscratio
    !
    ! -- For viscosity-based K's, apply change of K to K11 by starting with
    !    user-specified K values and not the K's leftover from the last viscosity
    !    update.
    do n = 1, this%dis%nodes
      call this%calc_q_visc(n, viscratio)
      this%k11(n) = this%k11input(n) * viscratio
      this%k22(n) = this%k22input(n) * viscratio
      this%k33(n) = this%k33input(n) * viscratio
      this%nodekchange(n) = 1
    end do
    !
    ! -- Flag kchange
    call this%vsc_set_changed_at(kper, kstp)

vsc_ad()

subroutine gwfvscmodule::vsc_ad

(

class(gwfvsctype)

this

)

Advance data in the VSC package. The method sets or advances time series, time array series, and observation data.

Definition at line 358 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    !
    ! -- update viscosity using the latest concentration/temperature
    call this%vsc_calcvisc()

vsc_ad_bnd()

subroutine gwfvscmodule::vsc_ad_bnd ( class(gwfvsctype)  this, class(bndtype), pointer  packobj, real(dp), dimension(:), intent(in)  hnew  )

private

Update the conductance values associate with inflow from a boundary when VSC package is active.

Definition at line 371 of file gwf-vsc.f90.

    ! -- modules
    use bndmodule, only: bndtype
    ! -- dummy
    class(GwfVscType) :: this
    class(BndType), pointer :: packobj
    real(DP), intent(in), dimension(:) :: hnew
    ! -- local
    integer(I4B) :: i, j
    integer(I4B) :: n, locvisc, locelev
    integer(I4B), dimension(:), allocatable :: locconc
    !
    ! -- initialize
    locvisc = 0
    locelev = 0
    allocate (locconc(this%nviscspecies))
    locconc(:) = 0
    !
    ! -- Add viscosity terms for conductance-dependent boundaries
    do n = 1, packobj%naux
      if (packobj%auxname(n) == 'VISCOSITY') then
        locvisc = n
      else if (packobj%auxname(n) == 'ELEVATION') then
        locelev = n
      end if
    end do
    !
    ! -- find aux columns for conc (or temp.) that affect viscosity
    do i = 1, this%nviscspecies
      locconc(i) = 0
      do j = 1, packobj%naux
        if (this%cauxspeciesname(i) == packobj%auxname(j)) then
          locconc(i) = j
          exit
        end if
      end do
      if (locconc(i) == 0) then
        ! -- one not found, so don't use and mark all as 0
        locconc(:) = 0
        exit
      end if
    end do
    !
    ! -- apply viscosity terms to inflow from boundary based on package type
    select case (packobj%filtyp)
    case ('GHB', 'DRN', 'RIV')
      !
      ! -- general head, drain, and river boundary
      call vsc_ad_standard_bnd(packobj, hnew, this%visc, this%viscref, &
                               locelev, locvisc, locconc, this%dviscdc, &
                               this%cviscref, this%ivisc, this%a2, this%a3, &
                               this%a4, this%ctemp)
    case ('LAK')
      !
      ! -- lake
      !  Update 'viscratios' internal to lak such that they are
      !  automatically applied in the LAK calc_cond() routine
      call vsc_ad_lak(packobj, this%visc, this%viscref, this%elev, locvisc, &
                      locconc, this%dviscdc, this%cviscref, this%ivisc, &
                      this%a2, this%a3, this%a4, this%ctemp)
    case ('SFR')
      !
      ! -- streamflow routing
      !  Update 'viscratios' internal to sfr such that they are
      !  automatically applied in the SFR calc_cond() routine
      call vsc_ad_sfr(packobj, this%visc, this%viscref, this%elev, locvisc, &
                      locconc, this%dviscdc, this%cviscref, this%ivisc, &
                      this%a2, this%a3, this%a4, this%ctemp)
    case ('MAW')
      !
      ! -- multi-aquifer well
      call vsc_ad_maw(packobj, this%visc, this%viscref, this%elev, locvisc, &
                      locconc, this%dviscdc, this%cviscref, this%ivisc, &
                      this%a2, this%a3, this%a4, this%ctemp)
    case ('UZF')
      !
      ! -- unsaturated-zone flow
    case default
      !
      ! -- nothing
    end select
    !
    ! -- deallocate
    deallocate (locconc)

Here is the call graph for this function:

vsc_ad_lak()

subroutine gwfvscmodule::vsc_ad_lak	(	class(bndtype), pointer	packobj,
		real(dp), dimension(:), intent(in)	visc,
		real(dp), intent(in)	viscref,
		real(dp), dimension(:), intent(in)	elev,
		integer(i4b), intent(in)	locvisc,
		integer(i4b), dimension(:), intent(in)	locconc,
		real(dp), dimension(:), intent(in)	dviscdc,
		real(dp), dimension(:), intent(in)	cviscref,
		integer(i4b), dimension(:), intent(in)	ivisc,
		real(dp), intent(in)	a2,
		real(dp), intent(in)	a3,
		real(dp), intent(in)	a4,
		real(dp), dimension(:), intent(inout)	ctemp
	)

When the viscosity package is active, update the viscosity ratio that is applied to the lakebed conductance calculated in the LAK package

Definition at line 587 of file gwf-vsc.f90.

    ! -- modules
    use bndmodule, only: bndtype
    use lakmodule, only: laktype
    class(BndType), pointer :: packobj
    ! -- dummy
    real(DP), intent(in) :: viscref
    real(DP), intent(in) :: a2, a3, a4
    integer(I4B), intent(in) :: locvisc
    integer(I4B), dimension(:), intent(in) :: locconc
    integer(I4B), dimension(:), intent(in) :: ivisc
    real(DP), dimension(:), intent(in) :: visc
    real(DP), dimension(:), intent(in) :: elev
    real(DP), dimension(:), intent(in) :: dviscdc
    real(DP), dimension(:), intent(in) :: cviscref
    real(DP), dimension(:), intent(inout) :: ctemp
    ! -- local
    integer(I4B) :: n
    integer(I4B) :: node
    real(DP) :: visclak
    !
    ! -- update viscosity ratios for updating hyd. cond (and conductance)
    select type (packobj)
    type is (laktype)
      do n = 1, packobj%nbound
        !
        ! -- get gwf node number
        node = packobj%nodelist(n)
        !
        ! -- Check if boundary cell is active, cycle if not
        if (packobj%ibound(node) <= 0) cycle
        !
        ! --
        !
        ! -- calculate the viscosity associated with the boundary
        visclak = calc_bnd_viscosity(n, locvisc, locconc, viscref, dviscdc, &
                                     cviscref, ctemp, ivisc, a2, a3, a4, &
                                     packobj%auxvar)
        !
        ! -- fill lak relative viscosity into column 1 of viscratios
        packobj%viscratios(1, n) = calc_vsc_ratio(viscref, visclak)
        !
        ! -- fill gwf relative viscosity into column 2 of viscratios
        packobj%viscratios(2, n) = calc_vsc_ratio(viscref, visc(node))
      end do
    end select

Here is the call graph for this function:

Here is the caller graph for this function:

vsc_ad_maw()

subroutine gwfvscmodule::vsc_ad_maw	(	class(bndtype), pointer	packobj,
		real(dp), dimension(:), intent(in)	visc,
		real(dp), intent(in)	viscref,
		real(dp), dimension(:), intent(in)	elev,
		integer(i4b), intent(in)	locvisc,
		integer(i4b), dimension(:), intent(in)	locconc,
		real(dp), dimension(:), intent(in)	dviscdc,
		real(dp), dimension(:), intent(in)	cviscref,
		integer(i4b), dimension(:), intent(in)	ivisc,
		real(dp), intent(in)	a2,
		real(dp), intent(in)	a3,
		real(dp), intent(in)	a4,
		real(dp), dimension(:), intent(inout)	ctemp
	)

When the viscosity package is active, update the viscosity ratio that is applied to the conductance calculated in the MAW package

Definition at line 641 of file gwf-vsc.f90.

    ! -- modules
    use bndmodule, only: bndtype
    use mawmodule, only: mawtype
    class(BndType), pointer :: packobj
    ! -- dummy
    real(DP), intent(in) :: viscref
    real(DP), intent(in) :: a2, a3, a4
    integer(I4B), intent(in) :: locvisc
    integer(I4B), dimension(:), intent(in) :: locconc
    integer(I4B), dimension(:), intent(in) :: ivisc
    real(DP), dimension(:), intent(in) :: visc
    real(DP), dimension(:), intent(in) :: elev
    real(DP), dimension(:), intent(in) :: dviscdc
    real(DP), dimension(:), intent(in) :: cviscref
    real(DP), dimension(:), intent(inout) :: ctemp
    ! -- local
    integer(I4B) :: n
    integer(I4B) :: node
    real(DP) :: viscmaw
    !
    ! -- update viscosity ratios for updating hyd. cond (and conductance)
    select type (packobj)
    type is (mawtype)
      do n = 1, packobj%nbound
        !
        ! -- get gwf node number
        node = packobj%nodelist(n)
        !
        ! -- Check if boundary cell is active, cycle if not
        if (packobj%ibound(node) <= 0) cycle
        !
        ! --
        !
        ! -- calculate the viscosity associated with the boundary
        viscmaw = calc_bnd_viscosity(n, locvisc, locconc, viscref, dviscdc, &
                                     cviscref, ctemp, ivisc, a2, a3, a4, &
                                     packobj%auxvar)
        !
        ! -- fill lak relative viscosity into column 1 of viscratios
        packobj%viscratios(1, n) = calc_vsc_ratio(viscref, viscmaw)
        !
        ! -- fill gwf relative viscosity into column 2 of viscratios
        packobj%viscratios(2, n) = calc_vsc_ratio(viscref, visc(node))
      end do
    end select

Here is the call graph for this function:

Here is the caller graph for this function:

vsc_ad_sfr()

subroutine gwfvscmodule::vsc_ad_sfr	(	class(bndtype), pointer	packobj,
		real(dp), dimension(:), intent(in)	visc,
		real(dp), intent(in)	viscref,
		real(dp), dimension(:), intent(in)	elev,
		integer(i4b), intent(in)	locvisc,
		integer(i4b), dimension(:), intent(in)	locconc,
		real(dp), dimension(:), intent(in)	dviscdc,
		real(dp), dimension(:), intent(in)	cviscref,
		integer(i4b), dimension(:), intent(in)	ivisc,
		real(dp), intent(in)	a2,
		real(dp), intent(in)	a3,
		real(dp), intent(in)	a4,
		real(dp), dimension(:), intent(inout)	ctemp
	)

When the viscosity package is active, update the viscosity ratio that is applied to the hydraulic conductivity specified in the SFR package

Definition at line 533 of file gwf-vsc.f90.

    ! -- modules
    use bndmodule, only: bndtype
    use sfrmodule, only: sfrtype
    class(BndType), pointer :: packobj
    ! -- dummy
    real(DP), intent(in) :: viscref
    real(DP), intent(in) :: a2, a3, a4
    integer(I4B), intent(in) :: locvisc
    integer(I4B), dimension(:), intent(in) :: locconc
    integer(I4B), dimension(:), intent(in) :: ivisc
    real(DP), dimension(:), intent(in) :: visc
    real(DP), dimension(:), intent(in) :: elev
    real(DP), dimension(:), intent(in) :: dviscdc
    real(DP), dimension(:), intent(in) :: cviscref
    real(DP), dimension(:), intent(inout) :: ctemp
    ! -- local
    integer(I4B) :: n
    integer(I4B) :: node
    real(DP) :: viscsfr
    !
    ! -- update viscosity ratios for updating hyd. cond (and conductance)
    select type (packobj)
    type is (sfrtype)
      do n = 1, packobj%nbound
        !
        ! -- get gwf node number
        node = packobj%nodelist(n)
        !
        ! -- Check if boundary cell is active, cycle if not
        if (packobj%ibound(node) <= 0) cycle
        !
        ! --
        !
        ! -- calculate the viscosity associated with the boundary
        viscsfr = calc_bnd_viscosity(n, locvisc, locconc, viscref, dviscdc, &
                                     cviscref, ctemp, ivisc, a2, a3, a4, &
                                     packobj%auxvar)
        !
        ! -- fill sfr relative viscosity into column 1 of viscratios
        packobj%viscratios(1, n) = calc_vsc_ratio(viscref, viscsfr)
        !
        ! -- fill gwf relative viscosity into column 2 of viscratios
        packobj%viscratios(2, n) = calc_vsc_ratio(viscref, visc(node))
      end do
    end select

Here is the call graph for this function:

Here is the caller graph for this function:

vsc_ad_standard_bnd()

subroutine gwfvscmodule::vsc_ad_standard_bnd	(	class(bndtype), pointer	packobj,
		real(dp), dimension(:), intent(in)	hnew,
		real(dp), dimension(:), intent(in)	visc,
		real(dp), intent(in)	viscref,
		integer(i4b), intent(in)	locelev,
		integer(i4b), intent(in)	locvisc,
		integer(i4b), dimension(:), intent(in)	locconc,
		real(dp), dimension(:), intent(in)	dviscdc,
		real(dp), dimension(:), intent(in)	cviscref,
		integer(i4b), dimension(:), intent(in)	ivisc,
		real(dp), intent(in)	a2,
		real(dp), intent(in)	a3,
		real(dp), intent(in)	a4,
		real(dp), dimension(:), intent(inout)	ctemp
	)

When flow enters from ghb boundary type, take into account the effects of viscosity on the user-specified conductance terms

Definition at line 462 of file gwf-vsc.f90.

    ! -- modules
    use bndmodule, only: bndtype
    use drnmodule, only: drntype
    use rivmodule, only: rivtype
    use ghbmodule, only: ghbtype
    class(BndType), pointer :: packobj
    ! -- dummy
    real(DP), intent(in), dimension(:) :: hnew
    real(DP), intent(in), dimension(:) :: visc
    real(DP), intent(in) :: a2, a3, a4
    real(DP), intent(in) :: viscref
    integer(I4B), intent(in) :: locelev
    integer(I4B), intent(in) :: locvisc
    integer(I4B), dimension(:), intent(in) :: locconc
    integer(I4B), dimension(:), intent(in) :: ivisc
    real(DP), dimension(:), intent(in) :: dviscdc
    real(DP), dimension(:), intent(in) :: cviscref
    real(DP), dimension(:), intent(inout) :: ctemp
    ! -- local
    integer(I4B) :: n
    integer(I4B) :: node
    real(DP) :: viscbnd
    !
    ! -- Process density terms for each GHB
    do n = 1, packobj%nbound
      node = packobj%nodelist(n)
      !
      ! -- Check if boundary cell is active, cycle if not
      if (packobj%ibound(node) <= 0) cycle
      !
      ! -- calculate the viscosity associated with the boundary
      viscbnd = calc_bnd_viscosity(n, locvisc, locconc, viscref, dviscdc, &
                                   cviscref, ctemp, ivisc, a2, a3, a4, &
                                   packobj%auxvar)
      !
      ! -- update boundary conductance based on viscosity effects
      select case (packobj%filtyp)
      case ('DRN')
        select type (packobj)
        type is (drntype)
          packobj%cond(n) = update_bnd_cond(viscbnd, viscref, &
                                            packobj%condinput(n))
        end select
      case ('GHB')
        select type (packobj)
        type is (ghbtype)
          packobj%cond(n) = update_bnd_cond(viscbnd, viscref, &
                                            packobj%condinput(n))
        end select
      case ('RIV')
        select type (packobj)
        type is (rivtype)
          packobj%cond(n) = update_bnd_cond(viscbnd, viscref, &
                                            packobj%condinput(n))
        end select
      case default
        packobj%bound(2, n) = update_bnd_cond(viscbnd, viscref, &
                                              packobj%condinput(n))
      end select
      !
    end do

Here is the call graph for this function:

Here is the caller graph for this function:

vsc_ar()

subroutine gwfvscmodule::vsc_ar ( class(gwfvsctype)  this, integer(i4b), dimension(:), pointer  ibound  )

private

Generic method to allocate and read static data for the viscosity package available within the GWF model type.

Definition at line 215 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    integer(I4B), dimension(:), pointer :: ibound
    !
    ! -- store pointers to arguments that were passed in
    this%ibound => ibound
    !
    ! -- Set pointers to npf variables
    call this%set_npf_pointers()

vsc_ar_bnd()

subroutine gwfvscmodule::vsc_ar_bnd ( class(gwfvsctype)  this, class(bndtype), pointer  packobj  )

private

Viscosity ar_bnd routine to activate viscosity in the advanced packages. This routine is called from gwf_ar() as it moves through each package

Definition at line 233 of file gwf-vsc.f90.

    ! -- modules
    use bndmodule, only: bndtype
    use drnmodule, only: drntype
    use ghbmodule, only: ghbtype
    use rivmodule, only: rivtype
    use lakmodule, only: laktype
    use sfrmodule, only: sfrtype
    use mawmodule, only: mawtype
    ! -- dummy
    class(GwfVscType) :: this
    class(BndType), pointer :: packobj
    !
    ! -- Add density terms based on boundary package type
    select case (packobj%filtyp)
    case ('DRN')
      !
      ! -- activate viscosity for the drain package
      select type (packobj)
      type is (drntype)
        call packobj%bnd_activate_viscosity()
      end select
    case ('GHB')
      !
      ! -- activate viscosity for the drain package
      select type (packobj)
      type is (ghbtype)
        call packobj%bnd_activate_viscosity()
      end select
    case ('RIV')
      !
      ! -- activate viscosity for the drain package
      select type (packobj)
      type is (rivtype)
        call packobj%bnd_activate_viscosity()
      end select
    case ('LAK')
      !
      ! -- activate viscosity for lake package
      select type (packobj)
      type is (laktype)
        call packobj%lak_activate_viscosity()
      end select
    case ('SFR')
      !
      ! -- activate viscosity for sfr package
      select type (packobj)
      type is (sfrtype)
        call packobj%sfr_activate_viscosity()
      end select
    case ('MAW')
      !
      ! -- activate viscosity for maw package
      select type (packobj)
      type is (mawtype)
        call packobj%maw_activate_viscosity()
      end select
    case default
      !
      ! -- nothing
    end select

vsc_calcvisc()

subroutine gwfvscmodule::vsc_calcvisc ( class(gwfvsctype)  this )

private

Calculates fluid viscosity based on concentration or temperature

Definition at line 1098 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    ! -- local
    integer(I4B) :: n
    integer(I4B) :: i
    !
    ! -- Calculate the viscosity using the specified concentration and/or
    !    temperature arrays
    do n = 1, this%dis%nodes
      do i = 1, this%nviscspecies
        if (this%modelconc(i)%icbund(n) == 0) then
          this%ctemp(i) = dzero
        else
          this%ctemp(i) = this%modelconc(i)%conc(n)
        end if
      end do
      !
      this%visc(n) = calc_visc(this%ivisc, this%viscref, this%dviscdc, &
                               this%cviscref, this%ctemp, this%a2, &
                               this%a3, this%a4)
    end do

Here is the call graph for this function:

vsc_cr()

subroutine, public gwfvscmodule::vsc_cr	(	type(gwfvsctype), pointer	vscobj,
		character(len=*), intent(in)	name_model,
		character(len=*), intent(in)	input_mempath,
		integer(i4b), intent(in)	inunit,
		integer(i4b), intent(in)	iout
	)

Create a new VSC Package object.

Definition at line 142 of file gwf-vsc.f90.

    ! -- dummy
    type(GwfVscType), pointer :: vscobj
    character(len=*), intent(in) :: name_model
    character(len=*), intent(in) :: input_mempath
    integer(I4B), intent(in) :: inunit
    integer(I4B), intent(in) :: iout
    !
    ! -- Create the object
    allocate (vscobj)
    !
    ! -- create name and memory path
    call vscobj%set_names(1, name_model, 'VSC', 'VSC', input_mempath)
    !
    ! -- Allocate scalars
    call vscobj%allocate_scalars()
    !
    ! -- Set variables
    vscobj%inunit = inunit
    vscobj%iout = iout

Here is the caller graph for this function:

vsc_da()

subroutine gwfvscmodule::vsc_da ( class(gwfvsctype)  this )

private

Deallocate viscosity package scalars and arrays.

Definition at line 904 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    !
    ! -- Deallocate arrays if package was active
    if (this%inunit > 0) then
      call mem_deallocate(this%visc)
      call mem_deallocate(this%ivisc)
      call mem_deallocate(this%dviscdc)
      call mem_deallocate(this%cviscref)
      call mem_deallocate(this%ctemp)
      deallocate (this%cmodelname)
      deallocate (this%cauxspeciesname)
      deallocate (this%modelconc)
    end if
    !
    ! -- Scalars
    call mem_deallocate(this%thermivisc)
    call mem_deallocate(this%idxtmpr)
    call mem_deallocate(this%ioutvisc)
    call mem_deallocate(this%ireadelev)
    call mem_deallocate(this%iconcset)
    call mem_deallocate(this%viscref)
    call mem_deallocate(this%nviscspecies)
    call mem_deallocate(this%a2)
    call mem_deallocate(this%a3)
    call mem_deallocate(this%a4)
    !
    ! -- Nullify pointers to other package variables
    nullify (this%k11)
    nullify (this%k22)
    nullify (this%k33)
    nullify (this%k11input)
    nullify (this%k22input)
    nullify (this%k33input)
    nullify (this%kchangeper)
    nullify (this%kchangestp)
    nullify (this%nodekchange)
    !
    ! -- deallocate parent
    call this%NumericalPackageType%da()

vsc_df()

subroutine gwfvscmodule::vsc_df ( class(gwfvsctype)  this, class(disbasetype), intent(in), pointer  dis, type(gwfvscinputdatatype), intent(in), optional  vsc_input  )

private

Define viscosity package options and dimensions

Parameters

	this	this viscosity package
[in]	dis	pointer to discretization
[in]	vsc_input	optional vsc input data, otherwise read from file

Definition at line 168 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this !< this viscosity package
    class(DisBaseType), pointer, intent(in) :: dis !< pointer to discretization
    type(GwfVscInputDataType), optional, intent(in) :: vsc_input !< optional vsc input data, otherwise read from file
    ! -- formats
    character(len=*), parameter :: fmtvsc = &
      "(1x,/1x,'VSC -- Viscosity Package, version 1, 11/15/2022', &
      &' input read from mempath: ', a, /)"
    !
    ! --print a message identifying the viscosity package
    write (this%iout, fmtvsc) this%input_mempath
    !
    ! -- store pointers to arguments that were passed in
    this%dis => dis
    !
    if (.not. present(vsc_input)) then
      !
      ! -- Read viscosity options
      call this%source_options()
      !
      ! -- Read viscosity dimensions
      call this%source_dimensions()
    else
      ! set from input data instead
      call this%set_options(vsc_input)
      this%nviscspecies = vsc_input%nviscspecies
    end if
    !
    ! -- Allocate arrays
    call this%allocate_arrays(dis%nodes)
    !
    if (.not. present(vsc_input)) then
      !
      ! -- Read viscosity packagedata
      call this%source_packagedata()
    else
      ! set from input data instead
      call this%set_packagedata(vsc_input)
    end if

vsc_ot_dv()

subroutine gwfvscmodule::vsc_ot_dv ( class(gwfvsctype)  this, integer(i4b), intent(in)  idvfl  )

private

Save calculated viscosity array to binary file

Definition at line 865 of file gwf-vsc.f90.

    ! -- dummy
    class(GwfVscType) :: this
    integer(I4B), intent(in) :: idvfl
    ! -- local
    character(len=1) :: cdatafmp = ' ', editdesc = ' '
    integer(I4B) :: ibinun
    integer(I4B) :: iprint
    integer(I4B) :: nvaluesp
    integer(I4B) :: nwidthp
    real(DP) :: dinact
    !
    ! -- Set unit number for viscosity output
    if (this%ioutvisc /= 0) then
      ibinun = 1
    else
      ibinun = 0
    end if
    if (idvfl == 0) ibinun = 0
    !
    ! -- save viscosity array
    if (ibinun /= 0) then
      iprint = 0
      dinact = dhnoflo
      !
      ! -- write viscosity to binary file
      if (this%ioutvisc /= 0) then
        ibinun = this%ioutvisc
        call this%dis%record_array(this%visc, this%iout, iprint, ibinun, &
                                   '       VISCOSITY', cdatafmp, nvaluesp, &
                                   nwidthp, editdesc, dinact)
      end if
    end if

vsc_rp()

subroutine gwfvscmodule::vsc_rp ( class(gwfvsctype)  this )

private

Method to read and prepare period data for the VSC package.

Definition at line 325 of file gwf-vsc.f90.

    ! -- modules
    use tdismodule, only: kstp, kper
    ! -- dummy
    class(GwfVscType) :: this
    ! -- local
    integer(I4B) :: i
    ! -- formats
    character(len=*), parameter :: fmtc = &
      "('Viscosity Package does not have a concentration set &
       &for species ',i0,'. One or more model names may be specified &
       &incorrectly in the PACKAGEDATA block or a GWF-GWT exchange may need &
       &to be activated.')"
    !
    ! -- Check to make sure all concentration pointers have been set
    if (kstp * kper == 1) then
      do i = 1, this%nviscspecies
        if (.not. associated(this%modelconc(i)%conc)) then
          write (errmsg, fmtc) i
          call store_error(errmsg)
        end if
      end do
      if (count_errors() > 0) then
        call store_error_filename(this%input_fname)
      end if
    end if

Here is the call graph for this function:

vsc_set_changed_at()

subroutine gwfvscmodule::vsc_set_changed_at ( class(gwfvsctype)  this, integer(i4b), intent(in)  kper, integer(i4b), intent(in)  kstp  )

private

Procedure called by VSC code when K updated due to viscosity changes. K values changed at (kper, kstp).

Definition at line 851 of file gwf-vsc.f90.

    ! -- dummy variables
    class(GwfVscType) :: this
    integer(I4B), intent(in) :: kper
    integer(I4B), intent(in) :: kstp
    !
    this%kchangeper = kper
    this%kchangestp = kstp
