tspssmmodule Module Reference

This module contains the TspSsm Module. More...

Data Types
type	tspssmtype
	Derived type for the SSM Package. More...

Functions/Subroutines
subroutine, public	ssm_cr (ssmobj, name_model, input_mempath, inunit, iout, fmi, eqnsclfac, depvartype)
	@ brief Create a new SSM package More...
subroutine	ssm_df (this)
	@ brief Define SSM Package More...
subroutine	ssm_ar (this, dis, ibound, cnew)
	@ brief Allocate and read SSM Package More...
subroutine	ssm_rp (this)
	@ brief Read and prepare this SSM Package More...
subroutine	ssm_ad (this)
	@ brief Advance the SSM Package More...
subroutine	ssm_term (this, ipackage, ientry, rrate, rhsval, hcofval, cssm, qssm)
	@ brief Calculate the SSM mass flow rate and hcof and rhs values More...
subroutine	get_ssm_conc (this, ipackage, ientry, nbound_flow, conc, lauxmixed)
	@ brief Provide bound concentration (or temperature) and mixed flag More...
subroutine	ssm_fc (this, matrix_sln, idxglo, rhs)
	@ brief Fill coefficients More...
subroutine	ssm_cq (this, flowja)
	@ brief Calculate flow More...
subroutine	ssm_bd (this, isuppress_output, model_budget)
	@ brief Calculate the global SSM budget terms More...
subroutine	ssm_ot_flow (this, icbcfl, ibudfl, icbcun)
	@ brief Output flows More...
subroutine	ssm_da (this)
	@ brief Deallocate More...
subroutine	allocate_scalars (this)
	@ brief Allocate scalars More...
subroutine	allocate_arrays (this)
	@ brief Allocate arrays More...
subroutine	source_options (this)
	Source input options. More...
subroutine	source_sources (this)
	Source sources input block. More...
subroutine	source_fileinput (this)
	Source fileinput input block. More...
subroutine	set_iauxpak (this, ip, packname, auxname)
	@ brief Set iauxpak array value for package ip More...
subroutine	set_ssmivec (this, ip, packname, filename)
	@ brief Set ssmivec array value for package ip More...
subroutine	pak_setup_outputtab (this)
	@ brief Setup the output table More...

Variables
character(len=lenftype)	ftype = 'SSM'
character(len=lenpackagename)	text = ' SOURCE-SINK MIX'

Detailed Description

This module contains the code for handling sources and sinks associated with groundwater flow model stress packages.

todo: need observations for SSM terms

Function/Subroutine Documentation

allocate_arrays()

subroutine tspssmmodule::allocate_arrays

(

class(tspssmtype)

this

)

Allocate array variables for this derived type

Parameters

this	TspSsmType object

Definition at line 710 of file tsp-ssm.f90.

    ! -- modules
    use memorymanagermodule, only: mem_allocate, mem_setptr
    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    ! -- local
    integer(I4B) :: nflowpack
    integer(I4B) :: i
    !
    ! -- Allocate
    nflowpack = this%fmi%nflowpack
    call mem_allocate(this%iauxpak, nflowpack, 'IAUXPAK', this%memoryPath)
    call mem_allocate(this%isrctype, nflowpack, 'ISRCTYPE', this%memoryPath)
    !
    ! -- Initialize
    do i = 1, nflowpack
      this%iauxpak(i) = 0
      this%isrctype(i) = 0
    end do
    !
    ! -- Allocate the ssmivec array
    allocate (this%ssmivec(nflowpack))

allocate_scalars()

subroutine tspssmmodule::allocate_scalars

(

class(tspssmtype)

this

)

Allocate scalar variables for this derived type

Parameters

this	TspSsmType object

Definition at line 690 of file tsp-ssm.f90.

    ! -- modules
    use memorymanagermodule, only: mem_allocate, mem_setptr
    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    !
    ! -- allocate scalars in NumericalPackageType
    call this%NumericalPackageType%allocate_scalars()
    !
    ! -- Allocate
    call mem_allocate(this%nbound, 'NBOUND', this%memoryPath)
    !
    ! -- Initialize
    this%nbound = 0

get_ssm_conc()

subroutine tspssmmodule::get_ssm_conc	(	class(tspssmtype)	this,
		integer(i4b), intent(in)	ipackage,
		integer(i4b), intent(in)	ientry,
		integer(i4b), intent(in)	nbound_flow,
		real(dp), intent(out)	conc,
		logical(lgp), intent(out)	lauxmixed
	)

SSM concentrations and temperatures can be provided in auxiliary variables or through separate SPC files. If not provided, the default concentration (or temperature) is zero. This single routine provides the SSM bound concentration (or temperature) based on these different approaches. The mixed flag indicates whether or not the boundary as a mixed type.

Parameters

	this	TspSsmType
[in]	ipackage	package number
[in]	ientry	bound number
[in]	nbound_flow	size of flow package bound list
[out]	conc	user-specified concentration/temperature for this bound
[out]	lauxmixed	user-specified flag for marking this as a mixed boundary

Definition at line 354 of file tsp-ssm.f90.

    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType
    integer(I4B), intent(in) :: ipackage !< package number
    integer(I4B), intent(in) :: ientry !< bound number
    integer(I4B), intent(in) :: nbound_flow !< size of flow package bound list
    real(DP), intent(out) :: conc !< user-specified concentration/temperature for this bound
    logical(LGP), intent(out) :: lauxmixed !< user-specified flag for marking this as a mixed boundary
    ! -- local
    integer(I4B) :: isrctype
    integer(I4B) :: iauxpos
    !
    conc = dzero
    lauxmixed = .false.
    isrctype = this%isrctype(ipackage)
    !
    select case (isrctype)
    case (1, 2)
      iauxpos = this%iauxpak(ipackage)
      conc = this%fmi%gwfpackages(ipackage)%auxvar(iauxpos, ientry)
      if (isrctype == 2) lauxmixed = .true.
    case (3, 4)
      conc = this%ssmivec(ipackage)%get_value(ientry, nbound_flow)
      if (isrctype == 4) lauxmixed = .true.
    end select

pak_setup_outputtab()

subroutine tspssmmodule::pak_setup_outputtab

(

class(tspssmtype), intent(inout)

this

)

Setup the output table by creating the column headers.

Definition at line 1023 of file tsp-ssm.f90.

    ! -- dummy
    class(TspSsmType), intent(inout) :: this
    ! -- local
    character(len=LINELENGTH) :: title
    character(len=LINELENGTH) :: text
    integer(I4B) :: ntabcol
    !
    ! -- allocate and initialize the output table
    if (this%iprflow /= 0) then
      !
      ! -- dimension table
      ntabcol = 6
      !if (this%inamedbound > 0) then
      !  ntabcol = ntabcol + 1
      !end if
      !
      ! -- initialize the output table object
      title = 'SSM PACKAGE ('//trim(this%packName)// &
              ') FLOW RATES'
      call table_cr(this%outputtab, this%packName, title)
      call this%outputtab%table_df(1, ntabcol, this%iout, transient=.true.)
      text = 'NUMBER'
      call this%outputtab%initialize_column(text, 10, alignment=tabcenter)
      text = 'CELLID'
      call this%outputtab%initialize_column(text, 20, alignment=tableft)
      text = 'BOUND Q'
      call this%outputtab%initialize_column(text, 15, alignment=tabcenter)
      text = 'SSM CONC'
      call this%outputtab%initialize_column(text, 15, alignment=tabcenter)
      text = 'RATE'
      call this%outputtab%initialize_column(text, 15, alignment=tabcenter)
      text = 'PACKAGE NAME'
      call this%outputtab%initialize_column(text, 16, alignment=tabcenter)
      !if (this%inamedbound > 0) then
      !  text = 'NAME'
      !  call this%outputtab%initialize_column(text, 20, alignment=TABLEFT)
      !end if
    end if

Here is the call graph for this function:

set_iauxpak()

subroutine tspssmmodule::set_iauxpak	(	class(tspssmtype), intent(inout)	this,
		integer(i4b), intent(in)	ip,
		character(len=*), intent(in)	packname,
		character(len=*), intent(in)	auxname
	)

The routine searches through the auxiliary names in package ip and sets iauxpak to the column number corresponding to the correct auxiliary column.

Parameters

[in,out]	this	TspSsmType
[in]	ip	package number
[in]	packname	name of package
[in]	auxname	name of aux

Definition at line 957 of file tsp-ssm.f90.

    ! -- dummy
    class(TspSsmType), intent(inout) :: this !< TspSsmType
    integer(I4B), intent(in) :: ip !< package number
    character(len=*), intent(in) :: packname !< name of package
    character(len=*), intent(in) :: auxname !< name of aux
    ! -- local
    logical :: auxfound
    integer(I4B) :: iaux
    !
    ! -- match package auxiliary
    auxfound = .false.
    do iaux = 1, this%fmi%gwfpackages(ip)%naux
      if (trim(this%fmi%gwfpackages(ip)%auxname(iaux)) == &
          trim(auxname)) then
        auxfound = .true.
        exit
      end if
    end do
    if (.not. auxfound) then
      write (errmsg, '(a, a)') &
        'Auxiliary name cannot be found: ', trim(auxname)
      call store_error(errmsg)
      call store_error_filename(this%input_fname)
    end if
    !
    ! -- set iauxpak and write message
    this%iauxpak(ip) = iaux
    write (this%iout, '(4x, a, i0, a, a)') 'USING AUX COLUMN ', &
      iaux, ' IN PACKAGE ', trim(packname)

Here is the call graph for this function:

set_ssmivec()

subroutine tspssmmodule::set_ssmivec	(	class(tspssmtype), intent(inout)	this,
		integer(i4b), intent(in)	ip,
		character(len=*), intent(in)	packname,
		character(len=*), intent(in)	filename
	)

This routine initializes the SPC input file.

Parameters

[in,out]	this	TspSsmType
[in]	ip	package number
[in]	packname	name of package
[in]	filename	package input file

Definition at line 993 of file tsp-ssm.f90.

    ! -- module
    use inputoutputmodule, only: openfile, getunit
    ! -- dummy
    class(TspSsmType), intent(inout) :: this !< TspSsmType
    integer(I4B), intent(in) :: ip !< package number
    character(len=*), intent(in) :: packname !< name of package
    character(len=*), intent(in) :: filename !< package input file
    ! -- local
    type(TspSpcType), pointer :: ssmiptr
    integer(I4B) :: inunit
    !
    ! -- open file
    inunit = getunit()
    call openfile(inunit, this%iout, filename, 'SPC', filstat_opt='OLD')
    !
    ! -- Create the SPC file object
    ssmiptr => this%ssmivec(ip)
    call ssmiptr%initialize(this%dis, ip, inunit, this%iout, this%name_model, &
                            trim(packname), this%depvartype)
    !
    write (this%iout, '(4x, a, a, a, a, a)') 'USING SPC INPUT FILE ', &
      trim(filename), ' TO SET ', trim(this%depvartype), &
      'S FOR PACKAGE ', trim(packname)

Here is the call graph for this function:

source_fileinput()

subroutine tspssmmodule::source_fileinput

(

class(tspssmtype)

this

)

Initialize an SPC input file reader for each input entry.

Definition at line 850 of file tsp-ssm.f90.

    ! -- modules
    !use KindModule, only: LGP
    use memorymanagermodule, only: mem_setptr, get_isize
    use characterstringmodule, only: characterstringtype
    ! -- dummy
    class(TspSsmType) :: this
    ! -- locals
    type(CharacterStringType), dimension(:), pointer, &
      contiguous :: pnames, ftypes, iotypes, fnames, conditions
    character(len=LINELENGTH) :: pname, ftype, iotype, fname, condition
    integer(I4B) :: n, ip, isize
    logical(LGP) :: found
    ! -- formats

    call get_isize('PNAME', this%input_mempath, isize)
    if (isize == -1) then
      write (this%iout, '(/1x,a)') &
        'OPTIONAL SSM FILEINPUT BLOCK INPUT NOT FOUND.'
      return
    end if

    ! set pointers to input context
    call mem_setptr(pnames, 'PNAME', this%input_mempath)
    call mem_setptr(ftypes, 'SPC6', this%input_mempath)
    call mem_setptr(iotypes, 'FILEIN', this%input_mempath)
    call mem_setptr(fnames, 'SPC6_FILENAME', this%input_mempath)
    call mem_setptr(conditions, 'MIXED', this%input_mempath)

    write (this%iout, '(/1x,a)') 'PROCESSING SSM FILEINPUT'
    do n = 1, size(pnames)

      pname = pnames(n)
      ftype = ftypes(n)
      iotype = iotypes(n)
      fname = fnames(n)
      condition = conditions(n)
      found = .false.

      do ip = 1, this%fmi%nflowpack
        if (trim(adjustl(this%fmi%gwfpackages(ip)%name)) == pname) then
          found = .true.
          exit
        end if
      end do

      if (.not. found) then
        write (errmsg, '(a,a)') 'Flow package cannot be found: ', &
          trim(pname)
        call store_error(errmsg)
        cycle
      end if

      ! -- Ensure package was not specified more than once in SOURCES block
      if (this%isrctype(ip) /= 0) then
        write (errmsg, '(a, a)') &
          'A package cannot be specified more than once in the SSM SOURCES &
          &block.  The following package was specified more than once: ', &
          trim(pname)
        call store_error(errmsg)
        cycle
      end if

      ! verify ftype
      if (ftype == 'SPC6') then
        write (this%iout, '(4x,a)') 'SPC6 SOURCE DETECTED:'
      else
        write (errmsg, '(a,a)') &
          'SRCTYPE must be SPC6. Found: ', trim(ftype)
        call store_error(errmsg)
        cycle
      end if

      ! verify iotype
      if (iotype /= 'FILEIN') then
        errmsg = 'SPC6 keyword must be followed by "FILEIN" '// &
                 'then by filename and optionally by <MIXED>.'
        call store_error(errmsg)
        cycle
      end if

      ! -- Use set_ssmivec to read file name and set up
      !    ssmi file object
      call this%set_ssmivec(ip, pname, fname)

      if (condition == 'MIXED') then
        this%isrctype(ip) = 4
        write (this%iout, '(4x,a,a)') 'ASSIGNED MIXED SSM TYPE TO PACKAGE ', &
          trim(pname)
      else
        this%isrctype(ip) = 3
      end if
    end do
    write (this%iout, '(1x,a)') 'END PROCESSING SSM FILEINPUT'

    ! -- terminate if errors
    if (count_errors() > 0) then
      call store_error_filename(this%input_fname)
    end if

Here is the call graph for this function:

source_options()

subroutine tspssmmodule::source_options

(

class(tspssmtype)

this

)

Definition at line 736 of file tsp-ssm.f90.

    ! -- modules
    !use KindModule, only: LGP
    use memorymanagerextmodule, only: mem_set_value
    use gwtssminputmodule, only: gwtssmparamfoundtype
    ! -- dummy
    class(TspSsmType) :: this
    ! -- locals
    type(GwtSsmParamFoundType) :: found
    ! -- formats
    character(len=*), parameter :: fmtiprflow = &
      "(4x,'SSM FLOW INFORMATION WILL BE PRINTED TO LISTING FILE &
      &WHENEVER ICBCFL IS NOT ZERO.')"
    character(len=*), parameter :: fmtisvflow = &
      "(4x,'CELL-BY-CELL FLOW INFORMATION WILL BE SAVED TO BINARY FILE &
      &WHENEVER ICBCFL IS NOT ZERO.')"
    !
    ! -- update defaults with idm sourced values
    call mem_set_value(this%iprflow, 'PRINT_FLOWS', this%input_mempath, &
                       found%print_flows)
    call mem_set_value(this%ipakcb, 'SAVE_FLOWS', this%input_mempath, &
                       found%save_flows)

    if (found%save_flows) this%ipakcb = -1

    ! log options
    write (this%iout, '(1x,a)') 'PROCESSING SSM OPTIONS'
    if (found%print_flows) write (this%iout, fmtiprflow)
    if (found%save_flows) write (this%iout, fmtisvflow)
    write (this%iout, '(1x,a)') 'END OF SSM OPTIONS'

source_sources()

subroutine tspssmmodule::source_sources

(

class(tspssmtype)

this

)

Definition at line 770 of file tsp-ssm.f90.

    ! -- modules
    !use KindModule, only: LGP
    use memorymanagermodule, only: mem_setptr
    use characterstringmodule, only: characterstringtype
    ! -- dummy
    class(TspSsmType) :: this
    ! -- locals
    type(CharacterStringType), dimension(:), pointer, &
      contiguous :: pnames, srctypes, auxnames
    character(len=LINELENGTH) :: pname, srctype, auxname
    integer(I4B) :: n, ip
    logical(LGP) :: found
    ! -- formats

    ! set pointers to input context
    call mem_setptr(pnames, 'PNAME_SOURCES', this%input_mempath)
    call mem_setptr(srctypes, 'SRCTYPE', this%input_mempath)
    call mem_setptr(auxnames, 'AUXNAME', this%input_mempath)

    write (this%iout, '(/1x,a)') 'PROCESSING SSM SOURCES'
    do n = 1, size(pnames)

      pname = pnames(n)
      srctype = srctypes(n)
      auxname = auxnames(n)
      found = .false.

      do ip = 1, this%fmi%nflowpack
        if (trim(adjustl(this%fmi%gwfpackages(ip)%name)) == pname) then
          found = .true.
          exit
        end if
      end do

      if (.not. found) then
        write (errmsg, '(a,a)') 'Flow package cannot be found: ', &
          trim(pname)
        call store_error(errmsg)
        cycle
      end if

      ! -- Ensure package was not specified more than once in SOURCES block
      if (this%isrctype(ip) /= 0) then
        write (errmsg, '(a, a)') &
          'A package cannot be specified more than once in the SSM SOURCES &
          &block.  The following package was specified more than once: ', &
          trim(pname)
        call store_error(errmsg)
        cycle
      end if

      if (srctype == 'AUX') then
        this%isrctype(ip) = 1
        write (this%iout, '(4x,a)') 'AUX SOURCE DETECTED.'
      else if (srctype == 'AUXMIXED') then
        this%isrctype(ip) = 2
        write (this%iout, '(4x,a)') 'AUXMIXED SOURCE DETECTED.'
      else
        write (errmsg, '(a, a)') &
          'SRCTYPE must be AUX or AUXMIXED.  Found: ', trim(srctype)
        call store_error(errmsg)
        cycle
      end if

      ! -- Find and store the auxiliary column
      call this%set_iauxpak(ip, srctype, auxname)
    end do
    write (this%iout, '(1x,a)') 'END PROCESSING SSM SOURCES'

    ! -- terminate if errors
    if (count_errors() > 0) then
      call store_error_filename(this%input_fname)
    end if

Here is the call graph for this function:

ssm_ad()

subroutine tspssmmodule::ssm_ad

(

class(tspssmtype)

this

)

This routine is called from gwt_ad(). It is called at the beginning of each time step. The total number of flow boundaries is counted and stored in thisnbound. Also, if any SPC input files are used to provide source and sink concentrations (or temperatures) and time series are referenced in those files, then ssm concenrations must be interpolated for the time step.

Parameters

this	TspSsmType object

Definition at line 212 of file tsp-ssm.f90.

    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    ! -- local
    integer(I4B) :: ip
    type(TspSpcType), pointer :: ssmiptr
    integer(I4B) :: i
    integer(I4B) :: node
    !
    ! -- Calculate total number of existing flow boundaries. It is possible
    !    that a node may equal zero.  In this case, the bound should be
    !    skipped and not written to ssm output.
    this%nbound = 0
    do ip = 1, this%fmi%nflowpack
      if (this%fmi%iatp(ip) /= 0) cycle
      do i = 1, this%fmi%gwfpackages(ip)%nbound
        node = this%fmi%gwfpackages(ip)%nodelist(i)
        if (node > 0) then
          this%nbound = this%nbound + 1
        end if
      end do
    end do
    !
    ! -- Call the ad method on any ssm input files so that values for
    !    time-series are interpolated
    do ip = 1, this%fmi%nflowpack
      if (this%fmi%iatp(ip) /= 0) cycle
      if (this%isrctype(ip) == 3 .or. this%isrctype(ip) == 4) then
        ssmiptr => this%ssmivec(ip)
        call ssmiptr%spc_ad(this%fmi%gwfpackages(ip)%nbound, &
                            this%fmi%gwfpackages(ip)%budtxt)
      end if
    end do

ssm_ar()

subroutine tspssmmodule::ssm_ar	(	class(tspssmtype)	this,
		class(disbasetype), intent(in), pointer	dis,
		integer(i4b), dimension(:), pointer, contiguous	ibound,
		real(dp), dimension(:), pointer, contiguous	cnew
	)

This routine is called from gwt_ar(). It allocates arrays, reads options and data, and sets up the output table.

Parameters

	this	TspSsmType object
[in]	dis	discretization package
	ibound	GWT model ibound
	cnew	GWT model dependent variable

Definition at line 130 of file tsp-ssm.f90.

    ! -- modules
    use memorymanagermodule, only: mem_setptr
    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    class(DisBaseType), pointer, intent(in) :: dis !< discretization package
    integer(I4B), dimension(:), pointer, contiguous :: ibound !< GWT model ibound
    real(DP), dimension(:), pointer, contiguous :: cnew !< GWT model dependent variable
    ! -- formats
    character(len=*), parameter :: fmtssm = &
      "(1x,/1x,'SSM -- SOURCE-SINK MIXING PACKAGE, VERSION 1, 8/25/2017', &
      &' INPUT READ FROM MEMPATH: ', A, //)"
    !
    ! -- print a message identifying the storage package.
    write (this%iout, fmtssm) this%input_mempath
    !
    ! -- store pointers to arguments that were passed in
    this%dis => dis
    this%ibound => ibound
    this%cnew => cnew
    !
    ! -- Check to make sure that there are flow packages
    if (this%fmi%nflowpack == 0) then
      write (errmsg, '(a)') 'SSM package does not detect any boundary flows &
                            &that require SSM terms.  Activate GWF-GWT (or &
                            &GWF-GWE, as appropriate) exchange or activate &
                            &FMI package and provide a budget file that &
                            &contains boundary flows.  If no boundary flows &
                            &are present in corresponding GWF model then this &
                            &SSM package should be removed.'
      call store_error(errmsg)
      call store_error_filename(this%input_fname)
    end if
    !
    ! -- Allocate arrays
    call this%allocate_arrays()
    !
    ! -- read ssm options
    call this%source_options()
    !
    ! -- read data blocks
    call this%source_sources()
    call this%source_fileinput()
    !
    ! -- setup the output table
    call this%pak_setup_outputtab()

Here is the call graph for this function:

ssm_bd()

subroutine tspssmmodule::ssm_bd	(	class(tspssmtype)	this,
		integer(i4b), intent(in)	isuppress_output,
		type(budgettype), intent(inout)	model_budget
	)

Calculate the global SSM budget terms using separate in and out entries for each flow package.

Parameters

	this	TspSsmType object
[in]	isuppress_output	flag to suppress output
[in,out]	model_budget	budget object for the GWT model

Definition at line 464 of file tsp-ssm.f90.

    ! -- modules
    use tdismodule, only: delt
    use budgetmodule, only: budgettype
    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    integer(I4B), intent(in) :: isuppress_output !< flag to suppress output
    type(BudgetType), intent(inout) :: model_budget !< budget object for the GWT model
    ! -- local
    character(len=LENBUDROWLABEL) :: rowlabel
    integer(I4B) :: ip
    integer(I4B) :: i
    integer(I4B) :: n
    real(DP) :: rate
    real(DP) :: rin
    real(DP) :: rout
    !
    ! -- do for each flow package, unless it is being handled by an advanced
    !    transport package
    do ip = 1, this%fmi%nflowpack
      !
      ! -- cycle if package is being managed as an advanced package
      if (this%fmi%iatp(ip) /= 0) cycle
      !
      ! -- Initialize the rate accumulators
      rin = dzero
      rout = dzero
      !
      ! -- do for each boundary
      do i = 1, this%fmi%gwfpackages(ip)%nbound
        n = this%fmi%gwfpackages(ip)%nodelist(i)
        if (n <= 0) cycle
        call this%ssm_term(ip, i, rrate=rate)
        if (rate < dzero) then
          rout = rout - rate
        else
          rin = rin + rate
        end if
        !
      end do
      !
      rowlabel = 'SSM_'//adjustl(trim(this%fmi%flowpacknamearray(ip)))
      call model_budget%addentry(rin, rout, delt, &
                                 this%fmi%gwfpackages(ip)%budtxt, &
                                 isuppress_output, rowlabel=rowlabel)
    end do

ssm_cq()

subroutine tspssmmodule::ssm_cq	(	class(tspssmtype)	this,
		real(dp), dimension(:), intent(inout), contiguous	flowja
	)

Calculate the resulting mass flow between the boundary and the connected GWT/GWE model cell. Update the diagonal position of the flowja array so that it ultimately contains the solute balance residual.

Parameters

	this	TspSsmType object
[in,out]	flowja	flow across each face in the model grid

Definition at line 429 of file tsp-ssm.f90.

    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    real(DP), dimension(:), contiguous, intent(inout) :: flowja !< flow across each face in the model grid
    ! -- local
    integer(I4B) :: ip
    integer(I4B) :: i
    integer(I4B) :: n
    integer(I4B) :: idiag
    real(DP) :: rate
    !
    ! -- do for each flow package
    do ip = 1, this%fmi%nflowpack
      !
      ! -- cycle if package is being managed as an advanced package
      if (this%fmi%iatp(ip) /= 0) cycle
      !
      ! -- do for each boundary
      do i = 1, this%fmi%gwfpackages(ip)%nbound
        n = this%fmi%gwfpackages(ip)%nodelist(i)
        if (n <= 0) cycle
        call this%ssm_term(ip, i, rrate=rate)
        idiag = this%dis%con%ia(n)
        flowja(idiag) = flowja(idiag) + rate
        !
      end do
      !
    end do

ssm_cr()

subroutine, public tspssmmodule::ssm_cr	(	type(tspssmtype), pointer	ssmobj,
		character(len=*), intent(in)	name_model,
		character(len=*), intent(in)	input_mempath,
		integer(i4b), intent(in)	inunit,
		integer(i4b), intent(in)	iout,
		type(tspfmitype), intent(in), target	fmi,
		real(dp), intent(in), pointer	eqnsclfac,
		character(len=lenvarname), intent(in)	depvartype
	)

Create a new SSM package by defining names, allocating scalars

Parameters

	ssmobj	TspSsmType object
[in]	name_model	name of the model
[in]	input_mempath	input mempath
[in]	inunit	fortran unit for input
[in]	iout	fortran unit for output
[in]	fmi	Transport FMI package
[in]	eqnsclfac	governing equation scale factor
[in]	depvartype	dependent variable type ('concentration' or 'temperature')

Definition at line 80 of file tsp-ssm.f90.

    ! -- dummy
    type(TspSsmType), pointer :: ssmobj !< TspSsmType object
    character(len=*), intent(in) :: name_model !< name of the model
    character(len=*), intent(in) :: input_mempath !< input mempath
    integer(I4B), intent(in) :: inunit !< fortran unit for input
    integer(I4B), intent(in) :: iout !< fortran unit for output
    type(TspFmiType), intent(in), target :: fmi !< Transport FMI package
    real(DP), intent(in), pointer :: eqnsclfac !< governing equation scale factor
    character(len=LENVARNAME), intent(in) :: depvartype !< dependent variable type ('concentration' or 'temperature')
    !
    ! -- Create the object
    allocate (ssmobj)
    !
    ! -- create name and memory path
    call ssmobj%set_names(1, name_model, 'SSM', 'SSM', input_mempath)
    !
    ! -- Allocate scalars
    call ssmobj%allocate_scalars()
    !
    ! -- Set variables
    ssmobj%inunit = inunit
    ssmobj%iout = iout
    ssmobj%fmi => fmi
    ssmobj%eqnsclfac => eqnsclfac
    !
    ! -- Store pointer to labels associated with the current model so that the
    !    package has access to the corresponding dependent variable type
    ssmobj%depvartype = depvartype

Here is the caller graph for this function:

ssm_da()

subroutine tspssmmodule::ssm_da

(

class(tspssmtype)

this

)

Deallocate the memory associated with this derived type

Parameters

this	TspSsmType object

Definition at line 644 of file tsp-ssm.f90.

    ! -- modules
    use memorymanagermodule, only: mem_deallocate
    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    ! -- local
    integer(I4B) :: ip
    type(TspSpcType), pointer :: ssmiptr
    !
    ! -- Deallocate the ssmi objects if package was active
    if (this%inunit > 0) then
      do ip = 1, size(this%ssmivec)
        if (this%isrctype(ip) == 3 .or. this%isrctype(ip) == 4) then
          ssmiptr => this%ssmivec(ip)
          call ssmiptr%spc_da()
        end if
      end do
      deallocate (this%ssmivec)
    end if
    !
    ! -- Deallocate arrays if package was active
    if (this%inunit > 0) then
      call mem_deallocate(this%iauxpak)
      call mem_deallocate(this%isrctype)
      this%ibound => null()
      this%fmi => null()
    end if
    !
    ! -- output table object
    if (associated(this%outputtab)) then
      call this%outputtab%table_da()
      deallocate (this%outputtab)
      nullify (this%outputtab)
    end if
    !
    ! -- Scalars
    call mem_deallocate(this%nbound)
    !
    ! -- deallocate parent
    call this%NumericalPackageType%da()

ssm_df()

subroutine tspssmmodule::ssm_df

(

class(tspssmtype)

this

)

This routine is called from gwt_df(), but does not do anything because df is typically used to set up dimensions. For the ssm package, the total number of ssm entries is defined by the flow model.

Parameters

this	TspSsmType object

Definition at line 118 of file tsp-ssm.f90.

    ! -- modules
    use memorymanagermodule, only: mem_setptr
    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object

ssm_fc()

subroutine tspssmmodule::ssm_fc	(	class(tspssmtype)	this,
		class(matrixbasetype), pointer	matrix_sln,
		integer(i4b), dimension(:), intent(in)	idxglo,
		real(dp), dimension(:), intent(inout)	rhs
	)

This routine adds the effects of the SSM to the matrix equations by updating the a matrix and right-hand side vector.

Definition at line 387 of file tsp-ssm.f90.

    ! -- dummy
    class(TspSsmType) :: this
    class(MatrixBaseType), pointer :: matrix_sln
    integer(I4B), intent(in), dimension(:) :: idxglo
    real(DP), intent(inout), dimension(:) :: rhs
    ! -- local
    integer(I4B) :: ip
    integer(I4B) :: i
    integer(I4B) :: n
    integer(I4B) :: idiag
    integer(I4B) :: nflowpack
    integer(I4B) :: nbound
    real(DP) :: hcofval
    real(DP) :: rhsval
    !
    ! -- do for each flow package
    nflowpack = this%fmi%nflowpack
    do ip = 1, nflowpack
      if (this%fmi%iatp(ip) /= 0) cycle
      !
      ! -- do for each entry in package (ip)
      nbound = this%fmi%gwfpackages(ip)%nbound
      do i = 1, nbound
        n = this%fmi%gwfpackages(ip)%nodelist(i)
        if (n <= 0) cycle
        call this%ssm_term(ip, i, rhsval=rhsval, hcofval=hcofval)
        idiag = idxglo(this%dis%con%ia(n))
        call matrix_sln%add_value_pos(idiag, hcofval)
        rhs(n) = rhs(n) + rhsval
        !
      end do
      !
    end do

ssm_ot_flow()

subroutine tspssmmodule::ssm_ot_flow	(	class(tspssmtype)	this,
		integer(i4b), intent(in)	icbcfl,
		integer(i4b), intent(in)	ibudfl,
		integer(i4b), intent(in)	icbcun
	)

Based on user-specified controls, print SSM mass flow rates to the GWT listing file and/or write the SSM mass flow rates to the GWT binary budget file.

Parameters

	this	TspSsmType object
[in]	icbcfl	flag for writing binary budget terms
[in]	ibudfl	flag for printing budget terms to list file
[in]	icbcun	fortran unit number for binary budget file

Definition at line 518 of file tsp-ssm.f90.

    ! -- modules
    use tdismodule, only: kstp, kper
    use constantsmodule, only: lenpackagename, lenboundname, lenauxname, dzero
    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    integer(I4B), intent(in) :: icbcfl !< flag for writing binary budget terms
    integer(I4B), intent(in) :: ibudfl !< flag for printing budget terms to list file
    integer(I4B), intent(in) :: icbcun !< fortran unit number for binary budget file
    ! -- local
    character(len=LINELENGTH) :: title
    integer(I4B) :: node, nodeu
    character(len=20) :: nodestr
    integer(I4B) :: maxrows
    integer(I4B) :: ip
    integer(I4B) :: i, n2, ibinun
    real(DP) :: rrate
    real(DP) :: qssm
    real(DP) :: cssm
    integer(I4B) :: naux
    real(DP), dimension(0) :: auxrow
    character(len=LENAUXNAME), dimension(0) :: auxname
    ! -- for observations
    character(len=LENBOUNDNAME) :: bname
    ! -- formats
    character(len=*), parameter :: fmttkk = &
      &"(1X,/1X,A,'   PERIOD ',I0,'   STEP ',I0)"
    !
    ! -- initialize
    naux = 0
    maxrows = 0
    if (ibudfl /= 0 .and. this%iprflow /= 0) then
      call this%outputtab%set_kstpkper(kstp, kper)
      do ip = 1, this%fmi%nflowpack
        if (this%fmi%iatp(ip) /= 0) cycle
        !
        ! -- do for each boundary
        do i = 1, this%fmi%gwfpackages(ip)%nbound
          node = this%fmi%gwfpackages(ip)%nodelist(i)
          if (node > 0) then
            maxrows = maxrows + 1
          end if
        end do
      end do
      if (maxrows > 0) then
        call this%outputtab%set_maxbound(maxrows)
      end if
      title = 'SSM PACKAGE ('//trim(this%packName)// &
              ') FLOW RATES'
      call this%outputtab%set_title(title)
    end if
    !
    ! -- Set unit number for binary output
    if (this%ipakcb < 0) then
      ibinun = icbcun
    else if (this%ipakcb == 0) then
      ibinun = 0
    else
      ibinun = this%ipakcb
    end if
    if (icbcfl == 0) ibinun = 0
    !
    ! -- If cell-by-cell flows will be saved as a list, write header.
    if (ibinun /= 0) then
      call this%dis%record_srcdst_list_header(text, this%name_model, &
                                              this%name_model, this%name_model, &
                                              this%packName, naux, auxname, &
                                              ibinun, this%nbound, this%iout)
    end if
    !
    ! -- If no boundaries, skip flow calculations.
    if (this%nbound > 0) then
      !
      ! -- Loop through each boundary calculating flow.
      do ip = 1, this%fmi%nflowpack
        if (this%fmi%iatp(ip) /= 0) cycle
        !
        ! -- do for each boundary
        do i = 1, this%fmi%gwfpackages(ip)%nbound
          !
          ! -- Calculate rate for this entry
          node = this%fmi%gwfpackages(ip)%nodelist(i)
          if (node <= 0) cycle
          call this%ssm_term(ip, i, rrate=rrate, qssm=qssm, cssm=cssm)
          !
          ! -- Print the individual rates if the budget is being printed
          !    and PRINT_FLOWS was specified (this%iprflow<0)
          if (ibudfl /= 0) then
            if (this%iprflow /= 0) then
              !
              ! -- set nodestr and write outputtab table
              nodeu = this%dis%get_nodeuser(node)
              call this%dis%nodeu_to_string(nodeu, nodestr)
              bname = this%fmi%gwfpackages(ip)%name
              call this%outputtab%add_term(i)
              call this%outputtab%add_term(trim(adjustl(nodestr)))
              call this%outputtab%add_term(qssm)
              call this%outputtab%add_term(cssm)
              call this%outputtab%add_term(rrate)
              call this%outputtab%add_term(bname)
            end if
          end if
          !
          ! -- If saving cell-by-cell flows in list, write flow
          if (ibinun /= 0) then
            n2 = i
            call this%dis%record_mf6_list_entry(ibinun, node, n2, rrate, &
                                                naux, auxrow, &
                                                olconv2=.false.)
          end if
          !
        end do
        !
      end do
    end if
    if (ibudfl /= 0) then
      if (this%iprflow /= 0) then
        write (this%iout, '(1x)')
      end if
    end if

ssm_rp()

subroutine tspssmmodule::ssm_rp

(

class(tspssmtype)

this

)

This routine is called from gwt_rp(). It is called at the beginning of each stress period. If any SPC input files are used to provide source and sink concentrations (or temperatures), then period blocks for the current stress period are read.

Parameters

this	TspSsmType object

Definition at line 185 of file tsp-ssm.f90.

    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType object
    ! -- local
    integer(I4B) :: ip
    type(TspSpcType), pointer :: ssmiptr
    ! -- formats
    !
    ! -- Call the rp method on any ssm input files
    do ip = 1, this%fmi%nflowpack
      if (this%fmi%iatp(ip) /= 0) cycle
      if (this%isrctype(ip) == 3 .or. this%isrctype(ip) == 4) then
        ssmiptr => this%ssmivec(ip)
        call ssmiptr%spc_rp()
      end if
    end do

ssm_term()

subroutine tspssmmodule::ssm_term	(	class(tspssmtype)	this,
		integer(i4b), intent(in)	ipackage,
		integer(i4b), intent(in)	ientry,
		real(dp), intent(out), optional	rrate,
		real(dp), intent(out), optional	rhsval,
		real(dp), intent(out), optional	hcofval,
		real(dp), intent(out), optional	cssm,
		real(dp), intent(out), optional	qssm
	)

This is the primary SSM routine that calculates the matrix coefficient and right-hand-side value for any package and package entry. It returns several different optional variables that are used throughout this package to update matrix terms, budget calculations, and output tables.

Parameters

	this	TspSsmType
[in]	ipackage	package number
[in]	ientry	bound number
[out]	rrate	calculated mass flow rate
[out]	rhsval	calculated rhs value
[out]	hcofval	calculated hcof value
[out]	cssm	calculated source concentration/temperature depending on flow direction
[out]	qssm	water flow rate into model cell from boundary package

Definition at line 254 of file tsp-ssm.f90.

    ! -- dummy
    class(TspSsmType) :: this !< TspSsmType
    integer(I4B), intent(in) :: ipackage !< package number
    integer(I4B), intent(in) :: ientry !< bound number
    real(DP), intent(out), optional :: rrate !< calculated mass flow rate
    real(DP), intent(out), optional :: rhsval !< calculated rhs value
    real(DP), intent(out), optional :: hcofval !< calculated hcof value
    real(DP), intent(out), optional :: cssm !< calculated source concentration/temperature depending on flow direction
    real(DP), intent(out), optional :: qssm !< water flow rate into model cell from boundary package
    ! -- local
    logical(LGP) :: lauxmixed
    integer(I4B) :: n
    integer(I4B) :: nbound_flow
    real(DP) :: qbnd
    real(DP) :: ctmp
    real(DP) :: omega
    real(DP) :: hcoftmp
    real(DP) :: rhstmp
    !
    ! -- retrieve node number, qbnd and iauxpos
    hcoftmp = dzero
    rhstmp = dzero
    ctmp = dzero
    qbnd = dzero
    nbound_flow = this%fmi%gwfpackages(ipackage)%nbound
    n = this%fmi%gwfpackages(ipackage)%nodelist(ientry)
    !
    ! -- If cell is active (ibound > 0) then calculate values
    if (this%ibound(n) > 0) then
      !
      ! -- retrieve qbnd and iauxpos
      qbnd = this%fmi%gwfpackages(ipackage)%get_flow(ientry)
      call this%get_ssm_conc(ipackage, ientry, nbound_flow, ctmp, lauxmixed)
      !
      ! -- assign values for hcoftmp, rhstmp, and ctmp for subsequent assignment
      !    of hcof, rhs, and rate
      if (.not. lauxmixed) then
        !
        ! -- If qbnd is positive, then concentration (or temperature) represents
        !    the inflow concentration (or temperature).  If qbnd is negative,
        !    then the outflow concentration (or temperature) is set equal to the
        !    simulated cell's concentration (or temperature).
        if (qbnd >= dzero) then
          omega = dzero ! rhs
        else
          ctmp = this%cnew(n)
          omega = done ! lhs
          if (ctmp < dzero) then
            omega = dzero ! concentration/temperature is negative, so set mass flux to zero
          end if
        end if
      else
        !
        ! -- lauxmixed value indicates that this is a mixed sink type where
        !    the concentration (or temperature) value represents the injected
        !    concentration (or temperature) if qbnd is positive. If qbnd is
        !    negative, then the withdrawn water is equal to the minimum of the
        !    aux concentration (or temperature) and the cell concentration
        !    (or temperature).
        if (qbnd >= dzero) then
          omega = dzero ! rhs (ctmp is aux value)
        else
          if (ctmp < this%cnew(n)) then
            omega = dzero ! rhs (ctmp is aux value)
          else
            omega = done ! lhs (ctmp is cell concentration)
            ctmp = this%cnew(n)
          end if
        end if
      end if
      !
      ! -- Add terms based on qbnd sign
      if (qbnd <= dzero) then
        hcoftmp = qbnd * omega * this%eqnsclfac
      else
        rhstmp = -qbnd * ctmp * (done - omega) * this%eqnsclfac
      end if
      !
      ! -- end of active ibound
    end if
    !
    ! -- set requested values
    if (present(hcofval)) hcofval = hcoftmp
    if (present(rhsval)) rhsval = rhstmp
    if (present(rrate)) rrate = hcoftmp * ctmp - rhstmp
    if (present(cssm)) cssm = ctmp
    if (present(qssm)) qssm = qbnd

Variable Documentation

ftype

character(len=lenftype) tspssmmodule::ftype = 'SSM'

Definition at line 28 of file tsp-ssm.f90.

  character(len=LENFTYPE) :: ftype = 'SSM'

text

character(len=lenpackagename) tspssmmodule::text = ' SOURCE-SINK MIX'

Definition at line 29 of file tsp-ssm.f90.

  character(len=LENPACKAGENAME) :: text = ' SOURCE-SINK MIX'
