tspspcmodule Module Reference

This module contains the TspSpc Module. More...

Data Types
type	tspspctype
	Derived type for managing SPC input. More...

Functions/Subroutines
subroutine	initialize (this, dis, id, input_mempath, iout, name_model, packNameFlow, dvn, input_fname)
	Initialize the SPC type. More...
subroutine	allocate_scalars (this)
	Allocate package scalars. More...
subroutine	allocate_arrays (this)
	Allocate package arrays. More...
real(dp) function	get_value (this, ientry, nbound_flow)
	Get the data value from this package. More...
subroutine	apply_input_values (this)
	Apply current input mempath values to dblvec, then echo them. More...
subroutine	spc_rp (this, nbound_flowpack, budtxt)
	Read and prepare stress period data. More...
subroutine	spc_ad (this, nbound_flowpack, budtxt)
	Advance. More...
subroutine	spc_da (this)
	Deallocate variables. More...
subroutine	check_flow_package (this, nbound_flowpack, budtxt)
	Check flow package consistency. More...

Variables
character(len=lenftype)	ftype = 'SPC'

Detailed Description

This module contains the code for reading and storing a generic input file of source and sink concentrations or temperatures.

Function/Subroutine Documentation

allocate_arrays()

subroutine tspspcmodule::allocate_arrays

(

class(tspspctype)

this

)

Parameters

this	TspSpcType object

Definition at line 163 of file TspSpc.f90.

    ! -- modules
    use memorymanagermodule, only: mem_allocate, mem_setptr
    ! -- dummy variables
    class(TspSpcType) :: this !< TspSpcType object
    ! -- local
    integer(I4B) :: i
    !
    if (this%readasarrays) then
      call mem_allocate(this%dblvec, this%maxbound, 'DBLVEC', this%memoryPath)
      do i = 1, this%maxbound
        this%dblvec(i) = dzero
      end do
    else
      ! list mode: alias into the loader's permanent, BNDNO-indexed array
      ! (allocated and DZERO-initialized by the loader)
      call mem_setptr(this%dblvec, trim(this%depvarname), this%input_mempath)
    end if

allocate_scalars()

subroutine tspspcmodule::allocate_scalars ( class(tspspctype)  this )

private

Parameters

this	TspSpcType object

Definition at line 142 of file TspSpc.f90.

    ! -- modules
    use memorymanagermodule, only: mem_allocate
    ! -- dummy variables
    class(TspSpcType) :: this !< TspSpcType object
    !
    call mem_allocate(this%id, 'ID', this%memoryPath)
    call mem_allocate(this%iout, 'IOUT', this%memoryPath)
    call mem_allocate(this%maxbound, 'MAXBOUND', this%memoryPath)
    call mem_allocate(this%iprpak, 'IPRPAK', this%memoryPath)
    call mem_allocate(this%readasarrays, 'READASARRAYS', this%memoryPath)
    !
    this%id = 0
    this%iout = 0
    this%maxbound = 0
    this%iprpak = 0
    this%readasarrays = .false.

apply_input_values()

subroutine tspspcmodule::apply_input_values ( class(tspspctype), intent(inout)  this )

private

Array mode copies the depvarname array into dblvec. List mode's dblvec is already a permanent, BNDNO-indexed alias into the input context, so there is nothing to copy.

Parameters

[in,out]

this

TspSpcType object

Definition at line 225 of file TspSpc.f90.

    ! -- dummy
    class(TspSpcType), intent(inout) :: this !< TspSpcType object
    ! -- local
    real(DP), dimension(:), pointer, contiguous :: val_arr
    integer(I4B) :: n
    ! -- formats
    character(len=*), parameter :: fmthdr = &
      &"(1X,/1X,'INPUT VALUES FOR ',A,' PACKAGE (PACKAGE ',A,')')"
    character(len=*), parameter :: fmtdvhdr = &
      &"(5X,'NO.',5X,A)"
    character(len=*), parameter :: fmtdvval = &
      &"(5X,I6,2X,G12.5)"
    !
    if (this%readasarrays) then
      call mem_setptr(val_arr, trim(this%depvarname), this%input_mempath)
      do n = 1, this%maxbound
        this%dblvec(n) = val_arr(n)
      end do
    end if
    if (this%iprpak /= 0) then
      write (this%iout, fmthdr) trim(this%depvarname), &
        trim(this%packNameFlow)
      write (this%iout, fmtdvhdr) trim(this%depvarname)
      do n = 1, this%maxbound
        write (this%iout, fmtdvval) n, this%dblvec(n)
      end do
    end if

check_flow_package()

subroutine tspspcmodule::check_flow_package	(	class(tspspctype), intent(inout)	this,
		integer(i4b), intent(in)	nbound_flowpack,
		character(len=*), intent(in)	budtxt
	)

Check that MAXBOUND is not less than nbound_flowpack and that readasarrays is consistent with the flow package type.

Parameters

[in,out]

this

TspSpcType object

Definition at line 330 of file TspSpc.f90.

    ! -- dummy
    class(TspSpcType), intent(inout) :: this !< TspSpcType object
    integer(I4B), intent(in) :: nbound_flowpack
    character(len=*), intent(in) :: budtxt
    !
    ! -- Check and make sure MAXBOUND is not less than nbound_flowpack
    if (this%maxbound < nbound_flowpack) then
      write (errmsg, '(a,a,a,i0,a,i0,a)') &
        'The SPC Package corresponding to flow package ', &
        trim(this%packNameFlow), &
        ' has MAXBOUND set less than the number of boundaries &
        &active in this package.  Found MAXBOUND equal ', &
        this%maxbound, &
        ' and number of flow boundaries (NBOUND) equal ', &
        nbound_flowpack, &
        '. Increase MAXBOUND in the SPC input file for this package.'
      call store_error(errmsg)
      call store_error_filename(this%input_fname)
    end if
    !
    ! -- If budtxt is RCHA or EVTA, then readasarrays must be used, otherwise
    !    readasarrays cannot be used
    select case (trim(adjustl(budtxt)))
    case ('RCHA')
      if (.not. this%readasarrays) then
        write (errmsg, '(a,a,a)') &
          'Array-based recharge must be used with array-based stress package &
          &concentrations.  GWF Package ', trim(this%packNameFlow), ' is being &
          &used with list-based SPC6 input.  Use array-based SPC6 input instead.'
        call store_error(errmsg)
        call store_error_filename(this%input_fname)
      end if
    case ('EVTA')
      if (.not. this%readasarrays) then
        write (errmsg, '(a,a,a)') &
          'Array-based evapotranspiration must be used with array-based stress &
          &package concentrations.  GWF Package ', trim(this%packNameFlow), &
          &' is being used with list-based SPC6 input.  Use array-based SPC6 &
          &input instead.'
        call store_error(errmsg)
        call store_error_filename(this%input_fname)
      end if
    case default
      if (this%readasarrays) then
        write (errmsg, '(a,a,a)') &
          'List-based packages must be used with list-based stress &
          &package concentrations.  GWF Package ', trim(this%packNameFlow), &
          &' is being used with array-based SPC6 input.  Use list-based SPC6 &
          &input instead.'
        call store_error(errmsg)
        call store_error_filename(this%input_fname)
      end if
    end select

Here is the call graph for this function:

get_value()

real(dp) function tspspcmodule::get_value	(	class(tspspctype)	this,
		integer(i4b), intent(in)	ientry,
		integer(i4b), intent(in)	nbound_flow
	)

Get the floating point value from the dblvec array.

Parameters

	this	TspSpcType object
[in]	ientry	index of the data to return
[in]	nbound_flow	size of bound list in flow package

Definition at line 188 of file TspSpc.f90.

    class(TspSpcType) :: this !< TspSpcType object
    integer(I4B), intent(in) :: ientry !< index of the data to return
    integer(I4B), intent(in) :: nbound_flow !< size of bound list in flow package
    real(DP) :: value
    integer(I4B) :: nu
    if (this%readasarrays) then
      ! -- Special handling for reduced grids and readasarrays.
      ! -- If flow and transport are in the same simulation, ientry is a user
      ! -- node number and corresponds to the correct position in dblvec.
      ! -- If flow and transport are not in the same simulation, ientry is a
      ! -- reduced node number, because the list of flows in the budget file
      ! -- does not include idomain < 1 entries. In that case, ientry must be
      ! -- converted to a user node number so that it corresponds to a user
      ! -- array, which includes idomain < 1 values.
      if (nbound_flow == this%maxbound) then
        ! -- flow and transport are in the same simulation or there
        ! -- are no idomain < 1 cells.
        value = this%dblvec(ientry)
      else
        ! -- flow and transport are in separate simulations; nbound_flow
        ! -- would equal ncpl if in the same simulation, but boundary cells
        ! -- with idomain < 1 are excluded from the binary budget file.
        nu = this%dis%get_nodeuser(ientry)
        value = this%dblvec(nu)
      end if
    else
      value = this%dblvec(ientry)
    end if

initialize()

subroutine tspspcmodule::initialize ( class(tspspctype)  this, class(disbasetype), intent(in), pointer  dis, integer(i4b), intent(in)  id, character(len=*), intent(in)  input_mempath, integer(i4b), intent(in)  iout, character(len=*), intent(in)  name_model, character(len=*), intent(in)  packNameFlow, character(len=*), intent(in)  dvn, character(len=*), intent(in)  input_fname  )

private

Initialize the SPC object using input context data.

Parameters

	this	TspSpcType
[in]	dis	discretization package
[in]	id	id number for this spc package
[in]	input_mempath	input memory path
[in]	iout	unit number for output
[in]	name_model	model name
[in]	packnameflow	name of corresponding flow package
[in]	dvn	dependent variable name (CONCENTRATION or TEMPERATURE)
[in]	input_fname	SPC input file name

Definition at line 73 of file TspSpc.f90.

    ! -- dummy variables
    class(TspSpcType) :: this !< TspSpcType
    class(DisBaseType), pointer, intent(in) :: dis !< discretization package
    integer(I4B), intent(in) :: id !< id number for this spc package
    character(len=*), intent(in) :: input_mempath !< input memory path
    integer(I4B), intent(in) :: iout !< unit number for output
    character(len=*), intent(in) :: name_model !< model name
    character(len=*), intent(in) :: packNameFlow !< name of corresponding flow package
    character(len=*), intent(in) :: dvn !< dependent variable name (CONCENTRATION or TEMPERATURE)
    character(len=*), intent(in) :: input_fname !< SPC input file name
    ! -- local
    integer(I4B), pointer :: maxbound_ptr
    integer(I4B) :: isize
    logical(LGP) :: found_print_input
    !
    write (this%packName, '(a,i0)') 'SPC-', id
    !
    call this%allocate_scalars()
    !
    this%name_model = name_model
    this%memoryPath = create_mem_path(this%name_model, this%packName)
    this%input_mempath = input_mempath
    this%input_fname = input_fname
    this%id = id
    this%iout = iout
    this%packNameFlow = packnameflow
    this%depvarname = dvn
    this%dis => dis
    !
    ! -- READASARRAYS determine array or list based input
    call get_isize('READASARRAYS', input_mempath, isize)
    this%readasarrays = (isize > 0)
    !
    ! -- set maxbound
    if (this%readasarrays) then
      this%maxbound = dis%get_ncpl()
    else
      call mem_setptr(maxbound_ptr, 'MAXBOUND', input_mempath)
      this%maxbound = maxbound_ptr
    end if
    !
    call this%allocate_arrays()
    !
    ! -- read PRINT_INPUT flag from input context
    call mem_set_value(this%iprpak, 'PRINT_INPUT', this%input_mempath, &
                       found_print_input)
    if (found_print_input) then
      write (this%iout, '(4x,a)') 'TIME-VARYING INPUT WILL BE PRINTED.'
    end if
    !
    ! -- check for idm managed active timeseries
    call get_isize('TS6_FILENAME', input_mempath, isize)
    if (isize > 0) this%ts_active = .true.
    call get_isize('TAS6_FILENAME', input_mempath, isize)
    if (isize > 0) this%ts_active = .true.
    !
    write (this%iout, '(4x,a,a,a,a,a)') 'USING SPC INPUT FILE ', &
      trim(input_fname), ' TO SET ', trim(dvn), &
      'S FOR PACKAGE '//trim(packnameflow)
    !
    if (count_errors() > 0) then
      call store_error_filename(this%input_fname)
    end if

Here is the call graph for this function:

spc_ad()

subroutine tspspcmodule::spc_ad ( class(tspspctype), intent(inout)  this, integer(i4b), intent(in)  nbound_flowpack, character(len=*), intent(in)  budtxt  )

private

Apply advanced input values at each time step.

Parameters

[in,out]

this

TspSpcType object

Definition at line 290 of file TspSpc.f90.

    ! -- dummy
    class(TspSpcType), intent(inout) :: this !< TspSpcType object
    integer(I4B), intent(in) :: nbound_flowpack
    character(len=*), intent(in) :: budtxt
    !
    ! -- no-op if timeseries inactive
    if (.not. this%ts_active) return
    !
    call this%apply_input_values()
    call this%check_flow_package(nbound_flowpack, budtxt)

spc_da()

subroutine tspspcmodule::spc_da ( class(tspspctype)  this )

private

Parameters

this	TspSpcType object

Definition at line 305 of file TspSpc.f90.

    ! -- modules
    use memorymanagermodule, only: mem_deallocate
    ! -- dummy variables
    class(TspSpcType) :: this !< TspSpcType object
    !
    nullify (this%dis)
    if (this%readasarrays) then
      call mem_deallocate(this%dblvec)
    else
      nullify (this%dblvec) ! input-context-owned alias, not package-allocated
    end if
    call mem_deallocate(this%id)
    call mem_deallocate(this%iout)
    call mem_deallocate(this%maxbound)
    call mem_deallocate(this%iprpak)
    call mem_deallocate(this%readasarrays)

spc_rp()

subroutine tspspcmodule::spc_rp ( class(tspspctype), intent(inout)  this, integer(i4b), intent(in)  nbound_flowpack, character(len=*), intent(in)  budtxt  )

private

Copies input period data into dblvec when new data has been loaded for this stress period.

Parameters

[in,out]

this

TspSpcType object

Definition at line 261 of file TspSpc.f90.

    ! -- dummy
    class(TspSpcType), intent(inout) :: this !< TspSpcType object
    integer(I4B), intent(in) :: nbound_flowpack
    character(len=*), intent(in) :: budtxt
    ! -- local
    integer(I4B), pointer :: iper
    ! -- formats
    character(len=*), parameter :: fmtlsp = &
      &"(1X,/1X,'REUSING ',A,'S FROM LAST STRESS PERIOD')"
    !
    call mem_setptr(iper, 'IPER', this%input_mempath)
    if (iper /= kper) then
      write (this%iout, fmtlsp) trim(ftype)
      return
    end if
    !
    ! -- spc_ad applies each time step
    if (this%ts_active) return
    !
    call this%apply_input_values()
    call this%check_flow_package(nbound_flowpack, budtxt)

Variable Documentation

ftype

character(len=lenftype) tspspcmodule::ftype = 'SPC'

private

Definition at line 26 of file TspSpc.f90.

  character(len=LENFTYPE) :: ftype = 'SPC'
