Particle track output module. More...

Data Types
type	particletrackfiletype
	Output file containing all or some particle pathlines. More...

type	particletrackeventselectiontype
	Selection of particle events. More...

type	particletrackstype
	Manages particle track output (logging/writing). More...

Functions/Subroutines
subroutine	init_file (this, iun, csv, iprp)
	Initialize a binary or CSV file. More...

subroutine	destroy (this)

subroutine	expand_files (this, increment)
	Grow the array of track files. More...

subroutine	select_events (this, release, cellexit, timestep, terminate, weaksink, usertime)
	Pick events to track. More...

logical function	is_selected (this, event_code)
	Check if a given event code is selected for tracking. More...

logical function	should_save (this, particle, file)
	Check whether a particle belongs in a given file i.e. if the file is enabled and its group matches the particle's. More...

subroutine, private	save_event (iun, particle, event, csv)
	Save an event to a binary or CSV file. More...

logical function	should_log (this)
	Log output unit valid? More...

subroutine, private	log_event (iun, particle, event)
	Print a particle event summary. More...

subroutine	handle_event (this, particle, event)
	Handle a particle event. More...

Variables
character(len= *), parameter, public	trackheader = 'kper,kstp,imdl,iprp,irpt,ilay,icell,izone,istatus,ireason,trelease,t,x,y,z,name'

character(len= *), parameter, public	trackdtypes = '<i4,<i4,<i4,<i4,<i4,<i4,<i4,<i4,<i4,<i4,<f8,<f8,<f8,<f8,<f8,\|S40'

Detailed Description

Each particle's track consists of events reported as the particle is advected through the model domain. Events are snapshots of particle state, along with optional metadata, at a particular moment in time.

Particles have no ID property. A particle can be uniquely identified by the unique combination of its release attributes (model, package, position, and time). This is possible because only one particle may be released from a given point at a given time.

This module consumes particle events and is responsible for writing them to one or more track files, binary or CSV, and for logging the events if requested. Each track file is associated with either a PRP package or with the full PRT model (there may only be 1 such latter).

Function/Subroutine Documentation

◆ destroy()

subroutine particletracksmodule::destroy ( class(particletrackstype) this )

Definition at line 112 of file ParticleTracks.f90.

113 class(ParticleTracksType) :: this

114 if (allocated(this%files)) deallocate (this%files)

◆ expand_files()

subroutine particletracksmodule::expand_files	(	class(particletrackstype)	this,
		integer(i4b), intent(in), optional	increment
	)

Definition at line 118 of file ParticleTracks.f90.

     ! dummy
     class(ParticleTracksType) :: this
     integer(I4B), optional, intent(in) :: increment
     ! local
     integer(I4B) :: inclocal
     integer(I4B) :: isize
     integer(I4B) :: newsize
     type(ParticleTrackFileType), allocatable, dimension(:) :: temp

     if (present(increment)) then
       inclocal = increment
     else
       inclocal = 1
     end if

     if (allocated(this%files)) then
       isize = size(this%files)
       newsize = isize + inclocal
       allocate (temp(newsize))
       temp(1:isize) = this%files
       deallocate (this%files)
       call move_alloc(temp, this%files)
     else
       allocate (this%files(inclocal))
     end if

◆ handle_event()

subroutine particletracksmodule::handle_event	(	class(particletrackstype), intent(inout)	this,
		type(particletype), intent(in), pointer	particle,
		class(particleeventtype), intent(in), pointer	event
	)

Definition at line 289 of file ParticleTracks.f90.

     ! dummy
     class(ParticleTracksType), intent(inout) :: this
     type(ParticleType), pointer, intent(in) :: particle
     class(ParticleEventType), pointer, intent(in) :: event
     ! local
     integer(I4B) :: i
     type(ParticleTrackFileType) :: file

     if (this%should_log()) &
       call log_event(this%iout, particle, event)

     if (this%is_selected(event%get_code())) then
       do i = 1, this%ntrackfiles
         file = this%files(i)
         if (this%should_save(particle, file)) &
           call save_event(file%iun, particle, event, csv=file%csv)
       end do
     end if

Here is the call graph for this function:

◆ init_file()

subroutine particletracksmodule::init_file	(	class(particletrackstype)	this,
		integer(i4b), intent(in)	iun,
		logical(lgp), intent(in), optional	csv,
		integer(i4b), intent(in), optional	iprp
	)

Definition at line 89 of file ParticleTracks.f90.

     ! dummy
     class(ParticleTracksType) :: this
     integer(I4B), intent(in) :: iun
     logical(LGP), intent(in), optional :: csv
     integer(I4B), intent(in), optional :: iprp
     ! local
     type(ParticleTrackFileType), pointer :: file

     if (.not. allocated(this%files)) then
       allocate (this%files(1))
     else
       call this%expand_files(increment=1)
     end if

     allocate (file)
     file%iun = iun
     if (present(csv)) file%csv = csv
     if (present(iprp)) file%iprp = iprp
     this%ntrackfiles = size(this%files)
     this%files(this%ntrackfiles) = file

◆ is_selected()

logical function particletracksmodule::is_selected	(	class(particletrackstype), intent(inout)	this,
		integer(i4b), intent(in)	event_code
	)

Definition at line 170 of file ParticleTracks.f90.

     class(ParticleTracksType), intent(inout) :: this
     integer(I4B), intent(in) :: event_code

     selected = (this%selected%release .and. event_code == 0) .or. &
                (this%selected%cellexit .and. event_code == 1) .or. &
                (this%selected%timestep .and. event_code == 2) .or. &
                (this%selected%terminate .and. event_code == 3) .or. &
                (this%selected%weaksink .and. event_code == 4) .or. &
                (this%selected%usertime .and. event_code == 5)

◆ log_event()

subroutine, private particletracksmodule::log_event	(	integer(i4b), intent(in)	iun,
		type(particletype), intent(in), pointer	particle,
		class(particleeventtype), intent(in), pointer	event
	)

private

Definition at line 259 of file ParticleTracks.f90.

     integer(I4B), intent(in) :: iun
     type(ParticleType), pointer, intent(in) :: particle
     class(ParticleEventType), pointer, intent(in) :: event
     ! local
     character(len=:), allocatable :: particlename

     particlename = trim(adjustl(particle%name))
     if (len_trim(particlename) == 0) particlename = 'anonymous'

     if (iun >= 0) &
       write (iun, '(*(G0))') &
       'Particle (Model: ', particle%imdl, &
       ', Package: ', particle%iprp, &
       ', Point: ', particle%irpt, ' [', particlename, ']', &
       ', Time: ', particle%trelease, &
       ') ', event%get_str(), &
       ' in (Layer: ', particle%ilay, &
       ', Cell: ', particle%icu, &
       ', Zone: ', particle%izone, &
       ') at (X: ', particle%x, &
       ', Y: ', particle%y, &
       ', Z: ', particle%z, &
       ', Time: ', particle%ttrack, &
       ', Period: ', event%kper, &
       ', Timestep: ', event%kstp, &
       ') with (Status: ', particle%istatus, ')'

Here is the caller graph for this function:

◆ save_event()

subroutine, private particletracksmodule::save_event	(	integer(i4b), intent(in)	iun,
		type(particletype), intent(in), pointer	particle,
		class(particleeventtype), intent(in), pointer	event,
		logical(lgp), intent(in)	csv
	)

private

Definition at line 193 of file ParticleTracks.f90.

     ! dummy
     integer(I4B), intent(in) :: iun
     type(ParticleType), pointer, intent(in) :: particle
     class(ParticleEventType), pointer, intent(in) :: event
     logical(LGP), intent(in) :: csv
     ! local
     real(DP) :: x, y, z
     integer(I4B) :: status

     ! Convert from cell-local to model coordinates if needed
     call particle%get_model_coords(x, y, z)

     ! Set status
     if (particle%istatus .lt. 0) then
       status = active
     else
       status = particle%istatus
     end if

     if (csv) then
       write (iun, '(*(G0,:,","))') &
         event%kper, &
         event%kstp, &
         particle%imdl, &
         particle%iprp, &
         particle%irpt, &
         particle%ilay, &
         particle%icu, &
         particle%izone, &
         status, &
         event%get_code(), &
         particle%trelease, &
         particle%ttrack, &
         x, &
         y, &
         z, &
         trim(adjustl(particle%name))
     else
       write (iun) &
         event%kper, &
         event%kstp, &
         particle%imdl, &
         particle%iprp, &
         particle%irpt, &
         particle%ilay, &
         particle%icu, &
         particle%izone, &
         status, &
         event%get_code(), &
         particle%trelease, &
         particle%ttrack, &
         x, &
         y, &
         z, &
         particle%name
     end if

Here is the caller graph for this function:

◆ select_events()

subroutine particletracksmodule::select_events	(	class(particletrackstype)	this,
		logical(lgp), intent(in)	release,
		logical(lgp), intent(in)	cellexit,
		logical(lgp), intent(in)	timestep,
		logical(lgp), intent(in)	terminate,
		logical(lgp), intent(in)	weaksink,
		logical(lgp), intent(in)	usertime
	)

Definition at line 147 of file ParticleTracks.f90.

     class(ParticleTracksType) :: this
     logical(LGP), intent(in) :: release
     logical(LGP), intent(in) :: cellexit
     logical(LGP), intent(in) :: timestep
     logical(LGP), intent(in) :: terminate
     logical(LGP), intent(in) :: weaksink
     logical(LGP), intent(in) :: usertime
     this%selected%release = release
     this%selected%cellexit = cellexit
     this%selected%timestep = timestep
     this%selected%terminate = terminate
     this%selected%weaksink = weaksink
     this%selected%usertime = usertime

◆ should_log()

logical function particletracksmodule::should_log ( class(particletrackstype), intent(inout) this )

Definition at line 253 of file ParticleTracks.f90.

254 class(ParticleTracksType), intent(inout) :: this

255 should_log = this%iout >= 0

◆ should_save()

logical function particletracksmodule::should_save	(	class(particletrackstype), intent(inout)	this,
		type(particletype), intent(in), pointer	particle,
		type(particletrackfiletype), intent(in)	file
	)

Definition at line 184 of file ParticleTracks.f90.

     class(ParticleTracksType), intent(inout) :: this
     type(ParticleType), pointer, intent(in) :: particle
     type(ParticleTrackFileType), intent(in) :: file
     save = (file%iun > 0 .and. &
             (file%iprp == -1 .or. file%iprp == particle%iprp))

Variable Documentation

◆ trackdtypes

character(len=*), parameter, public particletracksmodule::trackdtypes = '<i4,<i4,<i4,<i4,<i4,<i4,<i4,<i4,<i4,<i4,<f8,<f8,<f8,<f8,<f8,|S40'

Definition at line 38 of file ParticleTracks.f90.

   character(len=*), parameter, public :: TRACKDTYPES = &
     '<i4,<i4,<i4,<i4,<i4,<i4,<i4,<i4,&
     &<i4,<i4,<f8,<f8,<f8,<f8,<f8,|S40'

◆ trackheader

character(len=*), parameter, public particletracksmodule::trackheader = 'kper,kstp,imdl,iprp,irpt,ilay,icell,izone,istatus,ireason,trelease,t,x,y,z,name'

Definition at line 34 of file ParticleTracks.f90.

   character(len=*), parameter, public :: TRACKHEADER = &
     'kper,kstp,imdl,iprp,irpt,ilay,icell,izone,&
     &istatus,ireason,trelease,t,x,y,z,name'
