MODFLOW 6  version 6.7.0.dev2
USGS Modular Hydrologic Model
Data Types | Functions/Subroutines
imslinearmodule Module Reference

Data Types

type  imslineardatatype


Functions/Subroutines

subroutine imslinear_ar (this, NAME, IOUT, IPRIMS, MXITER, NEQ, matrix, RHS, X, linear_settings)
 @ brief Allocate storage and read data More...

subroutine imslinear_summary (this, mxiter)
 @ brief Write summary of settings More...

subroutine allocate_scalars (this)
 @ brief Allocate and initialize scalars More...

subroutine imslinear_da (this)
 @ brief Deallocate memory More...

subroutine imslinear_set_input (this, IFDPARAM)
 @ brief Set default settings More...

subroutine imslinear_ap (this, ICNVG, KSTP, KITER, IN_ITER, NCONV, CONVNMOD, CONVMODSTART, CACCEL, summary)
 @ brief Base linear accelerator subroutine More...


Function/Subroutine Documentation

◆ allocate_scalars()

subroutine imslinearmodule::allocate_scalars ( class(imslineardatatype), intent(inout)  this)
private

Allocate and initialize linear accelerator scalars

Parameters
[in,out]thisImsLinearDataType instance

Definition at line 456 of file ImsLinear.f90.

457  ! -- modules
458  use memorymanagermodule, only: mem_allocate
459  ! -- dummy variables
460  class(ImsLinearDataType), intent(inout) :: this !< ImsLinearDataType instance
461  !
462  ! -- allocate scalars
463  call mem_allocate(this%iout, 'IOUT', this%memoryPath)
464  call mem_allocate(this%ipc, 'IPC', this%memoryPath)
465  call mem_allocate(this%iacpc, 'IACPC', this%memoryPath)
466  call mem_allocate(this%niterc, 'NITERC', this%memoryPath)
467  call mem_allocate(this%niabcgs, 'NIABCGS', this%memoryPath)
468  call mem_allocate(this%niapc, 'NIAPC', this%memoryPath)
469  call mem_allocate(this%njapc, 'NJAPC', this%memoryPath)
470  call mem_allocate(this%epfact, 'EPFACT', this%memoryPath)
471  call mem_allocate(this%l2norm0, 'L2NORM0', this%memoryPath)
472  call mem_allocate(this%njlu, 'NJLU', this%memoryPath)
473  call mem_allocate(this%njw, 'NJW', this%memoryPath)
474  call mem_allocate(this%nwlu, 'NWLU', this%memoryPath)
475  !
476  ! -- initialize scalars
477  this%iout = 0
478  this%ipc = 0
479  this%iacpc = 0
480  this%niterc = 0
481  this%niabcgs = 0
482  this%niapc = 0
483  this%njapc = 0
484  this%epfact = dzero
485  this%l2norm0 = 0
486  this%njlu = 0
487  this%njw = 0
488  this%nwlu = 0
memorymanagermodule::mem_allocate
Definition: MemoryManager.f90:54

◆ imslinear_ap()

subroutine imslinearmodule::imslinear_ap ( class(imslineardatatype), intent(inout)  this,
integer(i4b), intent(inout)  ICNVG,
integer(i4b), intent(in)  KSTP,
integer(i4b), intent(in)  KITER,
integer(i4b), intent(inout)  IN_ITER,
integer(i4b), intent(in)  NCONV,
integer(i4b), intent(in)  CONVNMOD,
integer(i4b), dimension(convnmod + 1), intent(inout)  CONVMODSTART,
character(len=31), dimension(nconv), intent(inout)  CACCEL,
type(convergencesummarytype), intent(in), pointer  summary
)
private

Base linear accelerator subroutine that scales and reorders the system of equations, if necessary, updates the preconditioner, and calls the appropriate linear accelerator.

Parameters
[in,out]thisImsLinearDataType instance
[in,out]icnvgconvergence flag (1) non-convergence (0)
[in]kstptime step number
[in]kiterouter iteration number
[in,out]in_iterinner iteration number
[in]summaryConvergence summary report

Definition at line 618 of file ImsLinear.f90.

621  ! -- modules
622  USE simmodule
623  ! -- dummy variables
624  CLASS(ImsLinearDataType), INTENT(INOUT) :: this !< ImsLinearDataType instance
625  integer(I4B), INTENT(INOUT) :: ICNVG !< convergence flag (1) non-convergence (0)
626  integer(I4B), INTENT(IN) :: KSTP !< time step number
627  integer(I4B), INTENT(IN) :: KITER !< outer iteration number
628  integer(I4B), INTENT(INOUT) :: IN_ITER !< inner iteration number
629  ! -- convergence information dummy variables
630  integer(I4B), INTENT(IN) :: NCONV !<
631  integer(I4B), INTENT(IN) :: CONVNMOD !<
632  integer(I4B), DIMENSION(CONVNMOD + 1), INTENT(INOUT) :: CONVMODSTART !<
633  character(len=31), DIMENSION(NCONV), INTENT(INOUT) :: CACCEL !<
634  type(ConvergenceSummaryType), pointer, intent(in) :: summary !< Convergence summary report
635  ! -- local variables
636  integer(I4B) :: n
637  integer(I4B) :: innerit
638  integer(I4B) :: irc
639  integer(I4B) :: itmax
640  real(DP) :: dnrm2
641  !
642  ! -- set epfact based on timestep
643  this%EPFACT = ims_base_epfact(this%ICNVGOPT, kstp)
644  !
645  ! -- SCALE PROBLEM
646  IF (this%ISCL .NE. 0) THEN
647  CALL ims_base_scale(0, this%ISCL, &
648  this%NEQ, this%NJA, this%IA, this%JA, &
649  this%AMAT, this%X, this%RHS, &
650  this%DSCALE, this%DSCALE2)
651  END IF
652  !
653  ! -- PERMUTE ROWS, COLUMNS, AND RHS
654  IF (this%IORD /= 0) THEN
655  CALL dperm(this%NEQ, this%AMAT, this%JA, this%IA, &
656  this%ARO, this%JARO, this%IARO, &
657  this%LORDER, this%ID, 1)
658  CALL dvperm(this%NEQ, this%X, this%LORDER)
659  CALL dvperm(this%NEQ, this%RHS, this%LORDER)
660  this%IA0 => this%IARO
661  this%JA0 => this%JARO
662  this%A0 => this%ARO
663  ELSE
664  this%IA0 => this%IA
665  this%JA0 => this%JA
666  this%A0 => this%AMAT
667  END IF
668  !
669  ! -- UPDATE PRECONDITIONER
670  CALL ims_base_pcu(this%iout, this%NJA, this%NEQ, this%NIAPC, this%NJAPC, &
671  this%IPC, this%RELAX, this%A0, this%IA0, this%JA0, &
672  this%APC, this%IAPC, this%JAPC, this%IW, this%W, &
673  this%LEVEL, this%DROPTOL, this%NJLU, this%NJW, &
674  this%NWLU, this%JLU, this%JW, this%WLU)
675  !
676  ! -- INITIALIZE SOLUTION VARIABLE AND ARRAYS
677  IF (kiter == 1) then
678  this%NITERC = 0
679  summary%iter_cnt = 0
680  end if
681  irc = 1
682  icnvg = 0
683  DO n = 1, this%NEQ
684  this%D(n) = dzero
685  this%P(n) = dzero
686  this%Q(n) = dzero
687  this%Z(n) = dzero
688  END DO
689  !
690  ! -- CALCULATE INITIAL RESIDUAL
691  call ims_base_residual(this%NEQ, this%NJA, this%X, this%RHS, this%D, &
692  this%A0, this%IA0, this%JA0)
693  this%L2NORM0 = dnrm2(this%NEQ, this%D, 1)
694  !
695  ! -- CHECK FOR EXACT SOLUTION
696  itmax = this%ITER1
697  IF (this%L2NORM0 == dzero) THEN
698  itmax = 0
699  icnvg = 1
700  END IF
701  !
702  ! -- SOLUTION BY THE CONJUGATE GRADIENT METHOD
703  IF (this%ILINMETH == 1) THEN
704  CALL ims_base_cg(icnvg, itmax, innerit, &
705  this%NEQ, this%NJA, this%NIAPC, this%NJAPC, &
706  this%IPC, this%ICNVGOPT, this%NORTH, &
707  this%DVCLOSE, this%RCLOSE, this%L2NORM0, &
708  this%EPFACT, this%IA0, this%JA0, this%A0, &
709  this%IAPC, this%JAPC, this%APC, &
710  this%X, this%RHS, this%D, this%P, this%Q, this%Z, &
711  this%NJLU, this%IW, this%JLU, &
712  nconv, convnmod, convmodstart, &
713  caccel, summary)
714  !
715  ! -- SOLUTION BY THE BICONJUGATE GRADIENT STABILIZED METHOD
716  ELSE IF (this%ILINMETH == 2) THEN
717  CALL ims_base_bcgs(icnvg, itmax, innerit, &
718  this%NEQ, this%NJA, this%NIAPC, this%NJAPC, &
719  this%IPC, this%ICNVGOPT, this%NORTH, &
720  this%ISCL, this%DSCALE, &
721  this%DVCLOSE, this%RCLOSE, this%L2NORM0, &
722  this%EPFACT, this%IA0, this%JA0, this%A0, &
723  this%IAPC, this%JAPC, this%APC, &
724  this%X, this%RHS, this%D, this%P, this%Q, &
725  this%T, this%V, this%DHAT, this%PHAT, this%QHAT, &
726  this%NJLU, this%IW, this%JLU, &
727  nconv, convnmod, convmodstart, &
728  caccel, summary)
729  END IF
730  !
731  ! -- BACK PERMUTE AMAT, SOLUTION, AND RHS
732  IF (this%IORD /= 0) THEN
733  CALL dperm(this%NEQ, this%A0, this%JA0, this%IA0, &
734  this%AMAT, this%JA, this%IA, &
735  this%IORDER, this%ID, 1)
736  CALL dvperm(this%NEQ, this%X, this%IORDER)
737  CALL dvperm(this%NEQ, this%RHS, this%IORDER)
738  END IF
739  !
740  ! -- UNSCALE PROBLEM
741  IF (this%ISCL .NE. 0) THEN
742  CALL ims_base_scale(1, this%ISCL, &
743  this%NEQ, this%NJA, this%IA, this%JA, &
744  this%AMAT, this%X, this%RHS, &
745  this%DSCALE, this%DSCALE2)
746  END IF
747  !
748  ! -- SET IMS INNER ITERATION NUMBER (IN_ITER) TO NUMBER OF
749  ! IMSLINEAR INNER ITERATIONS (innerit)
750  in_iter = innerit
dnrm2
real(kind=8) function dnrm2(n, x, incx)
Definition: blas1_d.f90:388
simmodule
This module contains simulation methods.
Definition: Sim.f90:10
dvperm
subroutine dvperm(n, x, perm)
Definition: sparsekit.f90:62
dperm
subroutine dperm(nrow, a, ja, ia, ao, jao, iao, perm, qperm, job)
Definition: sparsekit.f90:354
Here is the call graph for this function:

◆ imslinear_ar()

subroutine imslinearmodule::imslinear_ar ( class(imslineardatatype), intent(inout)  this,
character(len=lensolutionname), intent(in)  NAME,
integer(i4b), intent(in)  IOUT,
integer(i4b), intent(in), target  IPRIMS,
integer(i4b), intent(in)  MXITER,
integer(i4b), intent(in), target  NEQ,
class(matrixbasetype), pointer  matrix,
real(dp), dimension(neq), intent(inout), target  RHS,
real(dp), dimension(neq), intent(inout), target  X,
type(imslinearsettingstype), pointer  linear_settings
)

Allocate storage for linear accelerators and read data

Parameters
[in,out]thisImsLinearDataType instance
[in]namesolution name
[in]ioutsimulation listing file unit
[in]iprimsprint option
[in]mxitermaximum outer iterations
[in]neqnumber of equations
[in,out]rhsright-hand side
[in,out]xdependent variables
linear_settingsthe settings form the IMS file

Definition at line 112 of file ImsLinear.f90.

114  ! -- modules
115  use memorymanagermodule, only: mem_allocate
116  use memoryhelpermodule, only: create_mem_path
117  use simmodule, only: store_error, count_errors, &
118  deprecation_warning
119  ! -- dummy variables
120  CLASS(ImsLinearDataType), INTENT(INOUT) :: this !< ImsLinearDataType instance
121  CHARACTER(LEN=LENSOLUTIONNAME), INTENT(IN) :: NAME !< solution name
122  integer(I4B), INTENT(IN) :: IOUT !< simulation listing file unit
123  integer(I4B), TARGET, INTENT(IN) :: IPRIMS !< print option
124  integer(I4B), INTENT(IN) :: MXITER !< maximum outer iterations
125  integer(I4B), TARGET, INTENT(IN) :: NEQ !< number of equations
126  class(MatrixBaseType), pointer :: matrix
127  real(DP), DIMENSION(NEQ), TARGET, INTENT(INOUT) :: RHS !< right-hand side
128  real(DP), DIMENSION(NEQ), TARGET, INTENT(INOUT) :: X !< dependent variables
129  type(ImsLinearSettingsType), pointer :: linear_settings !< the settings form the IMS file
130  ! -- local variables
131  character(len=LINELENGTH) :: errmsg
132  integer(I4B) :: n
133  integer(I4B) :: i0
134  integer(I4B) :: iscllen, iolen
135
136  !
137  ! -- DEFINE NAME
138  this%memoryPath = create_mem_path(name, 'IMSLINEAR')
139  !
140  ! -- SET pointers to IMS settings
141  this%DVCLOSE => linear_settings%dvclose
142  this%RCLOSE => linear_settings%rclose
143  this%ICNVGOPT => linear_settings%icnvgopt
144  this%ITER1 => linear_settings%iter1
145  this%ILINMETH => linear_settings%ilinmeth
146  this%ISCL => linear_settings%iscl
147  this%IORD => linear_settings%iord
148  this%NORTH => linear_settings%north
149  this%RELAX => linear_settings%relax
150  this%LEVEL => linear_settings%level
151  this%DROPTOL => linear_settings%droptol
152  !
153  ! -- SET POINTERS TO SOLUTION STORAGE
154  this%IPRIMS => iprims
155  this%NEQ => neq
156  call matrix%get_aij(this%IA, this%JA, this%AMAT)
157  call mem_allocate(this%NJA, 'NJA', this%memoryPath)
158  this%NJA = size(this%AMAT)
159  this%RHS => rhs
160  this%X => x
161  !
162  ! -- ALLOCATE SCALAR VARIABLES
163  call this%allocate_scalars()
164  !
165  ! -- initialize iout
166  this%iout = iout
167  !
168  ! -- DEFAULT VALUES
169  this%IPC = 0
170  !
171  this%IACPC = 0
172  !
173  ! -- PRINT A MESSAGE IDENTIFYING IMSLINEAR SOLVER PACKAGE
174  write (iout, 2000)
175 02000 FORMAT(1x, /1x, 'IMSLINEAR -- UNSTRUCTURED LINEAR SOLUTION', &
176  ' PACKAGE, VERSION 8, 04/28/2017')
177  !
178  ! -- DETERMINE PRECONDITIONER
179  IF (this%LEVEL > 0 .OR. this%DROPTOL > dzero) THEN
180  this%IPC = 3
181  ELSE
182  this%IPC = 1
183  END IF
184  IF (this%RELAX > dzero) THEN
185  this%IPC = this%IPC + 1
186  END IF
187  !
188  ! -- ERROR CHECKING FOR OPTIONS
189  IF (this%ISCL < 0) this%ISCL = 0
190  IF (this%ISCL > 2) THEN
191  WRITE (errmsg, '(A)') 'IMSLINEAR7AR ISCL MUST BE <= 2'
192  call store_error(errmsg)
193  END IF
194  IF (this%IORD < 0) this%IORD = 0
195  IF (this%IORD > 2) THEN
196  WRITE (errmsg, '(A)') 'IMSLINEAR7AR IORD MUST BE <= 2'
197  call store_error(errmsg)
198  END IF
199  IF (this%NORTH < 0) THEN
200  WRITE (errmsg, '(A)') 'IMSLINEAR7AR NORTH MUST >= 0'
201  call store_error(errmsg)
202  END IF
203  IF (this%RCLOSE == dzero) THEN
204  IF (this%ICNVGOPT /= 3) THEN
205  WRITE (errmsg, '(A)') 'IMSLINEAR7AR RCLOSE MUST > 0.0'
206  call store_error(errmsg)
207  END IF
208  END IF
209  IF (this%RELAX < dzero) THEN
210  WRITE (errmsg, '(A)') 'IMSLINEAR7AR RELAX MUST BE >= 0.0'
211  call store_error(errmsg)
212  END IF
213  IF (this%RELAX > done) THEN
214  WRITE (errmsg, '(A)') 'IMSLINEAR7AR RELAX MUST BE <= 1.0'
215  call store_error(errmsg)
216  END IF
217  !
218  ! -- INITIALIZE IMSLINEAR VARIABLES
219  this%NITERC = 0
220  !
221  ! -- ALLOCATE AND INITIALIZE MEMORY FOR IMSLINEAR
222  iscllen = 1
223  IF (this%ISCL .NE. 0) iscllen = neq
224  CALL mem_allocate(this%DSCALE, iscllen, 'DSCALE', trim(this%memoryPath))
225  CALL mem_allocate(this%DSCALE2, iscllen, 'DSCALE2', trim(this%memoryPath))
226  !
227  ! -- determine dimensions for preconditing arrays
228  call ims_calc_pcdims(this%NEQ, this%NJA, this%IA, this%LEVEL, this%IPC, &
229  this%NIAPC, this%NJAPC, this%NJLU, this%NJW, this%NWLU)
230  !
231  ! -- ALLOCATE BASE PRECONDITIONER VECTORS
232  CALL mem_allocate(this%IAPC, this%NIAPC + 1, 'IAPC', trim(this%memoryPath))
233  CALL mem_allocate(this%JAPC, this%NJAPC, 'JAPC', trim(this%memoryPath))
234  CALL mem_allocate(this%APC, this%NJAPC, 'APC', trim(this%memoryPath))
235  !
236  ! -- ALLOCATE MEMORY FOR ILU0 AND MILU0 NON-ZERO ROW ENTRY VECTOR
237  CALL mem_allocate(this%IW, this%NIAPC, 'IW', trim(this%memoryPath))
238  CALL mem_allocate(this%W, this%NIAPC, 'W', trim(this%memoryPath))
239  !
240  ! -- ALLOCATE MEMORY FOR ILUT VECTORS
241  CALL mem_allocate(this%JLU, this%NJLU, 'JLU', trim(this%memoryPath))
242  CALL mem_allocate(this%JW, this%NJW, 'JW', trim(this%memoryPath))
243  CALL mem_allocate(this%WLU, this%NWLU, 'WLU', trim(this%memoryPath))
244  !
245  ! -- GENERATE IAPC AND JAPC FOR ILU0 AND MILU0
246  IF (this%IPC == 1 .OR. this%IPC == 2) THEN
247  CALL ims_base_pccrs(this%NEQ, this%NJA, this%IA, this%JA, &
248  this%IAPC, this%JAPC)
249  END IF
250  !
251  ! -- ALLOCATE SPACE FOR PERMUTATION VECTOR
252  i0 = 1
253  iolen = 1
254  IF (this%IORD .NE. 0) THEN
255  i0 = this%NEQ
256  iolen = this%NJA
257  END IF
258  CALL mem_allocate(this%LORDER, i0, 'LORDER', trim(this%memoryPath))
259  CALL mem_allocate(this%IORDER, i0, 'IORDER', trim(this%memoryPath))
260  CALL mem_allocate(this%IARO, i0 + 1, 'IARO', trim(this%memoryPath))
261  CALL mem_allocate(this%JARO, iolen, 'JARO', trim(this%memoryPath))
262  CALL mem_allocate(this%ARO, iolen, 'ARO', trim(this%memoryPath))
263  !
264  ! -- ALLOCATE WORKING VECTORS FOR IMSLINEAR SOLVER
265  CALL mem_allocate(this%ID, this%NEQ, 'ID', trim(this%memoryPath))
266  CALL mem_allocate(this%D, this%NEQ, 'D', trim(this%memoryPath))
267  CALL mem_allocate(this%P, this%NEQ, 'P', trim(this%memoryPath))
268  CALL mem_allocate(this%Q, this%NEQ, 'Q', trim(this%memoryPath))
269  CALL mem_allocate(this%Z, this%NEQ, 'Z', trim(this%memoryPath))
270  !
271  ! -- ALLOCATE MEMORY FOR BCGS WORKING ARRAYS
272  this%NIABCGS = 1
273  IF (this%ILINMETH == 2) THEN
274  this%NIABCGS = this%NEQ
275  END IF
276  CALL mem_allocate(this%T, this%NIABCGS, 'T', trim(this%memoryPath))
277  CALL mem_allocate(this%V, this%NIABCGS, 'V', trim(this%memoryPath))
278  CALL mem_allocate(this%DHAT, this%NIABCGS, 'DHAT', trim(this%memoryPath))
279  CALL mem_allocate(this%PHAT, this%NIABCGS, 'PHAT', trim(this%memoryPath))
280  CALL mem_allocate(this%QHAT, this%NIABCGS, 'QHAT', trim(this%memoryPath))
281  !
282  ! -- INITIALIZE IMSLINEAR VECTORS
283  DO n = 1, iscllen
284  this%DSCALE(n) = done
285  this%DSCALE2(n) = done
286  END DO
287  DO n = 1, this%NJAPC
288  this%APC(n) = dzero
289  END DO
290  !
291  ! -- WORKING VECTORS
292  DO n = 1, this%NEQ
293  this%ID(n) = izero
294  this%D(n) = dzero
295  this%P(n) = dzero
296  this%Q(n) = dzero
297  this%Z(n) = dzero
298  END DO
299  DO n = 1, this%NIAPC
300  this%IW(n) = izero
301  this%W(n) = dzero
302  END DO
303  !
304  ! -- BCGS WORKING VECTORS
305  DO n = 1, this%NIABCGS
306  this%T(n) = dzero
307  this%V(n) = dzero
308  this%DHAT(n) = dzero
309  this%PHAT(n) = dzero
310  this%QHAT(n) = dzero
311  END DO
312  !
313  ! -- ILUT AND MILUT WORKING VECTORS
314  DO n = 1, this%NJLU
315  this%JLU(n) = izero
316  END DO
317  DO n = 1, this%NJW
318  this%JW(n) = izero
319  END DO
320  DO n = 1, this%NWLU
321  this%WLU(n) = dzero
322  END DO
323  !
324  ! -- REORDERING VECTORS
325  DO n = 1, i0 + 1
326  this%IARO(n) = izero
327  END DO
328  DO n = 1, iolen
329  this%JARO(n) = izero
330  this%ARO(n) = dzero
331  END DO
332  !
333  ! -- REVERSE CUTHILL MCKEE AND MINIMUM DEGREE ORDERING
334  IF (this%IORD .NE. 0) THEN
335  CALL ims_base_calc_order(this%IORD, this%NEQ, this%NJA, this%IA, &
336  this%JA, this%LORDER, this%IORDER)
337  END IF
338  !
339  ! -- ALLOCATE MEMORY FOR STORING ITERATION CONVERGENCE DATA
memoryhelpermodule::create_mem_path
character(len=lenmempath) function create_mem_path(component, subcomponent, context)
returns the path to the memory object
Definition: MemoryHelper.f90:22
simmodule::store_error
subroutine, public store_error(msg, terminate)
Store an error message.
Definition: Sim.f90:92
simmodule::count_errors
integer(i4b) function, public count_errors()
Return number of errors.
Definition: Sim.f90:59
simmodule::deprecation_warning
subroutine, public deprecation_warning(cblock, cvar, cver, endmsg, iunit)
Store deprecation warning message.
Definition: Sim.f90:256
Here is the call graph for this function:

◆ imslinear_da()

subroutine imslinearmodule::imslinear_da ( class(imslineardatatype), intent(inout)  this)

Deallocate linear accelerator memory.

Parameters
[in,out]thislinear datatype instance

Definition at line 496 of file ImsLinear.f90.

497  ! -- modules
498  use memorymanagermodule, only: mem_deallocate
499  ! -- dummy variables
500  class(ImsLinearDataType), intent(inout) :: this !< linear datatype instance
501  !
502  ! -- arrays
503  call mem_deallocate(this%dscale)
504  call mem_deallocate(this%dscale2)
505  call mem_deallocate(this%iapc)
506  call mem_deallocate(this%japc)
507  call mem_deallocate(this%apc)
508  call mem_deallocate(this%iw)
509  call mem_deallocate(this%w)
510  call mem_deallocate(this%jlu)
511  call mem_deallocate(this%jw)
512  call mem_deallocate(this%wlu)
513  call mem_deallocate(this%lorder)
514  call mem_deallocate(this%iorder)
515  call mem_deallocate(this%iaro)
516  call mem_deallocate(this%jaro)
517  call mem_deallocate(this%aro)
518  call mem_deallocate(this%id)
519  call mem_deallocate(this%d)
520  call mem_deallocate(this%p)
521  call mem_deallocate(this%q)
522  call mem_deallocate(this%z)
523  call mem_deallocate(this%t)
524  call mem_deallocate(this%v)
525  call mem_deallocate(this%dhat)
526  call mem_deallocate(this%phat)
527  call mem_deallocate(this%qhat)
528  !
529  ! -- scalars
530  call mem_deallocate(this%iout)
531  call mem_deallocate(this%ipc)
532  call mem_deallocate(this%iacpc)
533  call mem_deallocate(this%niterc)
534  call mem_deallocate(this%niabcgs)
535  call mem_deallocate(this%niapc)
536  call mem_deallocate(this%njapc)
537  call mem_deallocate(this%epfact)
538  call mem_deallocate(this%l2norm0)
539  call mem_deallocate(this%njlu)
540  call mem_deallocate(this%njw)
541  call mem_deallocate(this%nwlu)
542  call mem_deallocate(this%NJA)
543  !
544  ! -- nullify pointers
545  nullify (this%iprims)
546  nullify (this%neq)
547  nullify (this%nja)
548  nullify (this%ia)
549  nullify (this%ja)
550  nullify (this%amat)
551  nullify (this%rhs)
552  nullify (this%x)
memorymanagermodule::mem_deallocate
Definition: MemoryManager.f90:122

◆ imslinear_set_input()

subroutine imslinearmodule::imslinear_set_input ( class(imslineardatatype), intent(inout)  this,
integer(i4b), intent(in)  IFDPARAM
)

Set default linear accelerator settings.

Parameters
[in,out]thisImsLinearDataType instance
[in]ifdparamcomplexity option

Definition at line 560 of file ImsLinear.f90.

561  ! -- dummy variables
562  CLASS(ImsLinearDataType), INTENT(INOUT) :: this !< ImsLinearDataType instance
563  integer(I4B), INTENT(IN) :: IFDPARAM !< complexity option
564  ! -- code
565  SELECT CASE (ifdparam)
566  !
567  ! -- Simple option
568  CASE (1)
569  this%ITER1 = 50
570  this%ILINMETH = 1
571  this%IPC = 1
572  this%ISCL = 0
573  this%IORD = 0
574  this%DVCLOSE = dem3
575  this%RCLOSE = dem1
576  this%RELAX = dzero
577  this%LEVEL = 0
578  this%DROPTOL = dzero
579  this%NORTH = 0
580  !
581  ! -- Moderate
582  CASE (2)
583  this%ITER1 = 100
584  this%ILINMETH = 2
585  this%IPC = 2
586  this%ISCL = 0
587  this%IORD = 0
588  this%DVCLOSE = dem2
589  this%RCLOSE = dem1
590  this%RELAX = 0.97d0
591  this%LEVEL = 0
592  this%DROPTOL = dzero
593  this%NORTH = 0
594  !
595  ! -- Complex
596  CASE (3)
597  this%ITER1 = 500
598  this%ILINMETH = 2
599  this%IPC = 3
600  this%ISCL = 0
601  this%IORD = 0
602  this%DVCLOSE = dem1
603  this%RCLOSE = dem1
604  this%RELAX = dzero
605  this%LEVEL = 5
606  this%DROPTOL = dem4
607  this%NORTH = 2
608  END SELECT

◆ imslinear_summary()

subroutine imslinearmodule::imslinear_summary ( class(imslineardatatype), intent(inout)  this,
integer(i4b), intent(in)  mxiter
)

Write summary of linear accelerator settings.

Parameters
[in,out]thisImsLinearDataType instance
[in]mxitermaximum number of outer iterations

Definition at line 347 of file ImsLinear.f90.

348  ! -- dummy variables
349  class(ImsLinearDataType), intent(inout) :: this !< ImsLinearDataType instance
350  integer(I4B), intent(in) :: mxiter !< maximum number of outer iterations
351  ! -- local variables
352  CHARACTER(LEN=10) :: clin(0:2)
353  CHARACTER(LEN=31) :: clintit(0:2)
354  CHARACTER(LEN=20) :: cipc(0:4)
355  CHARACTER(LEN=20) :: cscale(0:2)
356  CHARACTER(LEN=25) :: corder(0:2)
357  CHARACTER(LEN=16), DIMENSION(0:4) :: ccnvgopt
358  CHARACTER(LEN=15) :: clevel
359  CHARACTER(LEN=15) :: cdroptol
360  integer(I4B) :: i
361  integer(I4B) :: j
362  ! -- data
363  DATA clin/'UNKNOWN ', &
364  &'CG ', &
365  &'BCGS '/
366  DATA clintit/' UNKNOWN ', &
367  &' CONJUGATE-GRADIENT ', &
368  &'BICONJUGATE-GRADIENT STABILIZED'/
369  DATA cipc/'UNKNOWN ', &
370  &'INCOMPLETE LU ', &
371  &'MOD. INCOMPLETE LU ', &
372  &'INCOMPLETE LUT ', &
373  &'MOD. INCOMPLETE LUT '/
374  DATA cscale/'NO SCALING ', &
375  &'SYMMETRIC SCALING ', &
376  &'L2 NORM SCALING '/
377  DATA corder/'ORIGINAL ORDERING ', &
378  &'RCM ORDERING ', &
379  &'MINIMUM DEGREE ORDERING '/
380  DATA ccnvgopt/'INFINITY NORM ', &
381  &'INFINITY NORM S ', &
382  &'L2 NORM ', &
383  &'RELATIVE L2NORM ', &
384  &'L2 NORM W. REL. '/
385  ! -- formats
386 02010 FORMAT(1x, /, 7x, 'SOLUTION BY THE', 1x, a31, 1x, 'METHOD', &
387  /, 1x, 66('-'), /, &
388  ' MAXIMUM OF ', i0, ' CALLS OF SOLUTION ROUTINE', /, &
389  ' MAXIMUM OF ', i0, &
390  ' INTERNAL ITERATIONS PER CALL TO SOLUTION ROUTINE', /, &
391  ' LINEAR ACCELERATION METHOD =', 1x, a, /, &
392  ' MATRIX PRECONDITIONING TYPE =', 1x, a, /, &
393  ' MATRIX SCALING APPROACH =', 1x, a, /, &
394  ' MATRIX REORDERING APPROACH =', 1x, a, /, &
395  ' NUMBER OF ORTHOGONALIZATIONS =', 1x, i0, /, &
396  ' HEAD CHANGE CRITERION FOR CLOSURE =', e15.5, /, &
397  ' RESIDUAL CHANGE CRITERION FOR CLOSURE =', e15.5, /, &
398  ' RESIDUAL CONVERGENCE OPTION =', 1x, i0, /, &
399  ' RESIDUAL CONVERGENCE NORM =', 1x, a, /, &
400  ' RELAXATION FACTOR =', e15.5)
401 02015 FORMAT(' NUMBER OF LEVELS =', a15, /, &
402  ' DROP TOLERANCE =', a15, //)
403 2030 FORMAT(1x, a20, 1x, 6(i6, 1x))
404 2040 FORMAT(1x, 20('-'), 1x, 6(6('-'), 1x))
405 2050 FORMAT(1x, 62('-'),/) !
406 ! -- -----------------------------------------------------------
407  !
408  ! -- initialize clevel and cdroptol
409  clevel = ''
410  cdroptol = ''
411  !
412  ! -- write common variables to all linear accelerators
413  write (this%iout, 2010) &
414  clintit(this%ILINMETH), mxiter, this%ITER1, &
415  clin(this%ILINMETH), cipc(this%IPC), &
416  cscale(this%ISCL), corder(this%IORD), &
417  this%NORTH, this%DVCLOSE, this%RCLOSE, &
418  this%ICNVGOPT, ccnvgopt(this%ICNVGOPT), &
419  this%RELAX
420  if (this%level > 0) then
421  write (clevel, '(i15)') this%level
422  end if
423  if (this%droptol > dzero) then
424  write (cdroptol, '(e15.5)') this%droptol
425  end if
426  IF (this%level > 0 .or. this%droptol > dzero) THEN
427  write (this%iout, 2015) trim(adjustl(clevel)), &
428  trim(adjustl(cdroptol))
429  ELSE
430  write (this%iout, '(//)')
431  END IF
432
433  if (this%iord /= 0) then
434  !
435  ! -- WRITE SUMMARY OF REORDERING INFORMATION TO LIST FILE
436  if (this%iprims == 2) then
437  DO i = 1, this%neq, 6
438  write (this%iout, 2030) 'ORIGINAL NODE :', &
439  (j, j=i, min(i + 5, this%neq))
440  write (this%iout, 2040)
441  write (this%iout, 2030) 'REORDERED INDEX :', &
442  (this%lorder(j), j=i, min(i + 5, this%neq))
443  write (this%iout, 2030) 'REORDERED NODE :', &
444  (this%iorder(j), j=i, min(i + 5, this%neq))
445  write (this%iout, 2050)
446  END DO
447  END IF
448  end if
